Operation Manual
MODEL: ECW-300/360
Safety Instructions .................................................................................................. 2
Name of Parts ......................................................................................................... 4
Operating the Range Hood ..................................................................................... 4
How to Use ............................................................................................................. 5
Care and Maintenance ............................................................................................ 6
Disassembling .................................................................................................... 7
Cleaning ............................................................................................................. 7
Re-assembling ................................................................................................... 8
Replacing the Light Bulb ......................................................................................... 8
Requesting Service ................................................................................................. 9
Prior to Requesting Service ............................................................................... 9
Inspection Label ................................................................................................. 9
Specifications ........................................................................................................ 10
Circuit Diagram ..................................................................................................... 10
Parts List ............................................................................................................... 11
Limited Product Warranty ...................................................................................... 12
READ AND SAVE THESE INSTRUCTIONS.
Keep this manual in a convenient place for future reference.
RANGE HOOD
ECW-360
TABLE OF CONTENTS
FUJI INDUSTRIAL CO., LTD.
ECW-300
1U02 1481
Advertisement
Table of Contents
Related Manuals for Fujioh ECW-360
Summary of Contents for Fujioh ECW-360
-
Page 1: Table Of Contents
Circuit Diagram ... 10 Parts List ... 11 Limited Product Warranty ... 12 READ AND SAVE THESE INSTRUCTIONS. Keep this manual in a convenient place for future reference. RANGE HOOD ECW-360 TABLE OF CONTENTS FUJI INDUSTRIAL CO., LTD. ECW-300 1U02 1481... -
Page 2: Safety Instructions
SAFETY INSTRUCTIONS Before installation and operation, read these instructions carefully and use this product only in the manner described by the manufacturer in the operation manual. The signal words shown below are used to alert you to potential personal injury and property damage hazards. There are three hazard classifications based on potentially dangerous situations. - Page 3 1. For general ventilating use only. Do not use to exhaust hazardous or explosive material and vapors. 2. To reduce the risk of fire and to properly exhaust air, be sure to duct air outside. Do not vent exhaust air into spaces within walls, ceilings or into attics, crawl spaces or garages. 3.
-
Page 4: Name Of Parts
name of parts Control Switches Control Switches Pilot Lamp OFF Switch operating the Range Hood The range hood has five control switch buttons on its front cover. Push one of the switches ( , , The fan will start rotating. (Low) (Medium) (High) -
Page 5: How To Use
how to use Before operation, make sure that the rectifier baffle panel and filters are attached securely. CAUTION • During cooking, do not touch the rectifier baffle panel or its screws. If the rectifier baffle panel is attached incorrectly, it may become detached and fall down. -
Page 6: Care And Maintenance
care and maintenance Clean the range hood as many times as possible (especially, clean the filter once a month) as it becomes dirty and deteriorates in function if it’s left unclean. For a family size of 4 to 5 people and cooking twice a day, clean the filter once every two weeks to avoid grease contamination and grease build-up, which is difficult to clean. -
Page 7: Disassembling
disassembling Rectifier Baffle Panel After loosening 2 screws fixing the rectifier baffle panel, slide the panel to dislocate the keyholes from the screws. Then, open the panel a little and pull it to remove from the catches. NOTE: As the rectifier baffle panel may have grease built-up, be careful about oil-drips when removing it. -
Page 8: Re-Assembling
re-assembling Filter Place the filter in the groove, hold it upward and turn the knob clockwise to fix it securely. Rectifier Baffle Panel With holding the rectifier baffle panel by both hands, place it on the catches. Push the panel upward and slide it to engage the keyholes with 2 screws, then tighten the screws to fix the panel firmly. -
Page 9: Requesting Service
requesting service prior to requesting service Prior to requesting service, do the following check by yourself for common errors. Situation Range Hood does not operate. Range Hood is noisier than usual or vibrating. Lamp does not turn on. NOTE • Service parts are kept at the manufacturer for a maximum of six years after ceasing the production of this model. -
Page 10: Specifications
Refer to the following table. Voltage Model ECW-300 ECW-360 NOTE FUJI INDUSTRIAL CO., LTD. has measured airflow under HVI-916 and noise levels under Japanese Industrial Standard (JIS) C9603 items 8.8 and 8.9. circuit diagram ECW-300 Black 120V 60Hz White... -
Page 11: Parts List
Figure Screw M4 × 10 Two(2) Pieces Screw M5.1 × 45 Four(4) Pieces Wood Screw M4.5 × 45 Two(2) Pieces ECW-360 Parts Name Enclosure Front Panel Back Panel Fan Unit Case Motor Sirocco Fan Bellmouth Earth Wire Unit Switch Box Unit... -
Page 12: Limited Product Warranty
The Fujioh product warranty is to the original purchaser (consumer) of its products only and is not transferable. Fujioh warrants that its products will be free from defects in materials or workmanship for a period of three years from the date of original purchase. THERE ARE NO...
