19-pin Color Display Signal Cable*

PIN No.
Description
1
TMDS Data2+
3
TMDS Data2–
5
TMDS Data1 Shield
7
TMDS Data0+
9
TMDS Data0–
11
HDMI_DET
13
Reserved (N.C. on device)
15
SCL
17
DDC/CEC Ground
19
Hot Plug Detect
* only for certain models

DisplayPort Connector

Pin
20-pin Side of the
Number
Connected Signal Cable
1
ML3(n)
2
GND
3
ML3(p)
4
ML2(n)
5
GND
6
ML2(p)
7
ML1(n)
8
GND
9
ML1(p)
10
ML0(n)
PIN No.
2
TMDS Data2 Shield
4
TMDS Data1+
6
TMDS Data1–
8
TMDS Data0 Shield
10
TMDS Clock+
12
TMDS Clock–
14
Reserved (N.C. on device)
16
SDA
18
+5V Power
Pin
Number
11
12
13
14
15
16
17
18
19
20
EN-10
19
17
15
13
11
9
7
5
3
1
18
16
14
12
10
8
6
4
2
Description
of the
20-pin Side of the
Signal Cable
Connected Signal Cable
GND
ML0(p)
CONFIG1
CONFIG2
AUX(p)
GND
AUX(n)
HPD
Return
DP_PWR
