USER CONTROLS
Power Switch / Power LED:
To turn the monitor ON or OFF.
Lights up to indicate the power is
turned ON.
Using the Shortcut Menu
Press the function button to open
the shortcut menu. The shortcut
menu lets you quickly select the
most commonly accessed settings.
MENU OSD functions
Press this botton to activate the OSD menu.
INPUT Input Key
Use Input key to select from different video sources that may be connected to
your monitor.
(a)
DVI input
As you cycle through the sources you will see the following messages on right top
side of screen to indicate currently selected input source. It may take 1 or 2
seconds for the image to appear.
or
DVI
or H DMI
If either
DVI or HDM
are not connected, a floating dialog box indicates:
"No Cable Connect" or "No Signal"
AUTO Auto Adjust:
Press this button to activate the Auto Adjustment function. The Auto Adjustment
function is used to set the HPos, VPos, Clock and Focus.
Volume
Up / Down
Press to adjust volume (Only Audio-Input Model)(Optional)
Empowering:
Press the Empowering Key to open the Acer eColor Management OSD and access
the scenario modes.
(b)
HDMI input
DP
or
DP
n i
p
u
i t
(c)
DP input
s s
l e
c e
e t
d
b ,
t u
h t
EN-13
M E N U
I N P U T
A U T O
V o l u m e
e
D
I V
a
n
d
H
D
M
I and DP
E m p o w e r i n g
cables
