Acer AL1516W User Manual

Acer car video system - lcd monitor user manual
Hide thumbs

Advertisement

TABLE OF CONTENTS

Special notes on LCD monitors ................................................................. 1
Introduction ................................................................................................ 2
Features ..................................................................................................... 2
Unpacking .................................................................................................. 3
Attaching/Removing the base .................................................................... 4
Screen position adjustment ......................................................................... 4
Connecting the power cord ........................................................................ 5
Safety precaution ....................................................................................... 5
Cleaning your monitor ................................................................................ 5
Preset modes ............................................................................................. 6
Power saving ............................................................................................. 7
DDC .......................................................................................................... 7
Installation .................................................................................................. 8
User controls .............................................................................................. 9
Troubleshooting .........................................................................................13
Specification ..............................................................................................15
For more information and help in recycling, please visit the following websites:
Worldwide: http://global.acer.com/about/sustainability.htm

Advertisement

Table of Contents
loading

  Also See for Acer AL1516W

  Related Manuals for Acer AL1516W

  Summary of Contents for Acer AL1516W

  • Page 1: Table Of Contents

    Cleaning your monitor ... 5 Preset modes ... 6 Power saving ... 7 DDC ... 7 Installation ... 8 User controls ... 9 Troubleshooting ...13 Specification ...15 For more information and help in recycling, please visit the following websites: Worldwide: http://global.acer.com/about/sustainability.htm...
  • Page 2: Special Notes On Lcd Monitors

    A Japanese regulatory requirement, defined by specification JIS 0950, 2005. mandates that manufactures provide Material Content Declarations for certain categories of electronic products offered for sale after July 1, 2006. To view the JIS C 0950 material declaration for this product. Visit http://global.acer.com/about/sustainability.htm EN-1 AL1516W...
  • Page 3: Introduction

    FEATURES The AL1516W is a 15-inch TFT LCD monitor that is intelligent, microprocessor-based and ergonomically designed display, compatible with most analog RGB (Red, Green, Blue) and Digital display standards, including PS/V, PS/2, optional for Apple Macintosh Centris, Quadra, and Macintosh II family signals.
  • Page 4: Unpacking

    · LCD Monitor · DVI Cable (Only Dual-Input Model) · User Manual · AC Power Cord · D-SUB Cable · Quick Start Guide AL1516W LCD Monitor EN-3 AL1516W...
  • Page 5: Attaching/Removing The Base

    The monitor can be adjusted to 15 degrees up or 5 degrees down as indicated by arrow below. Remove: Depress the four hooks as indicated first before removing the base and follow the arrow direction to remove it. EN-4 AL1516W...
  • Page 6: Connecting The Power Cord

    WWW.EIAE.ORG. FOR LAMP SPECIFIC DISPOSAL INFORMATION CHECK WWW.LAMPRECYCLE.ORG. CLEANING YOUR MONITOR Please carefully follow the below guidelines when cleaning the monitor. · Always unplug the monitor before cleaning. · Use a soft cloth to wipe the screen and cabinet front and sides. EN-5 AL1516W...
  • Page 7: Preset Modes

    VESA 1024 x 768 VESA 1024 x 768 CVT-RB 1280 x 800 H. Freq. Band Width (KHz) 70.1 31.47 59.94 Hz 31.47 37.5 60.3 37.88 46.88 48.36 60.02 59.91 Hz 49.31 EN-6 AL1516W Polarity (MHz) 28.33 25.18 31.5 49.5 78.75...
  • Page 8: Power Saving

    AL1516W POWER SAVING The monitor will be driven into “Power Saving” mode by the control signal from the display controller, as indicated by the amber-color power LED. Power State LED Light Consumption Normal Green Power Saving Mode <2 W Amber The power saving states will be kept until a control signal has been detected or the keyboard or mouse is activated.
  • Page 9: Installation

    3. Power-ON Monitor and Computer Power-ON the monitor first, then power-ON the computer. This sequence is very important. 4. If the monitor still does not function properly, please refer to the troubleshooting section to diagnose the problem. Please don’t open the cover EN-8 AL1516W...
  • Page 10: User Controls

    AL1516W USER CONTROLS Front Panel Controls 1. Power Switch: To turn ON or OFF the power. 2. Power LED: Lights up to indicate the power is turned ON. 3. Empowering / Exit: 1) When OSD menu is in active status, this button will act as EXIT-KEY (EXIT OSD menu).
  • Page 11: To Adjust A Setting

    II. Digital Signal Input Description Adjusts the contrast between the foreground and background of the screen image. Adjusts the background brightness of the screen image. Adjusts picture Focus. (available in Analog mode only) Adjusts picture Clock. (available in Analog mode only) EN-10 AL1516W...
  • Page 12 Description Adjust the horizontal position. (available in Analog mode only) Adjust the vertical position. (available in Analog mode only) Set the color temperature to warm white. Set the color temperature to cool white. Adjusts Red/Green/Blue intensity. Multi-language selection. EN-11 AL1516W...
  • Page 13 Select input signal from digital (DVI) Turn ON/OFF DDC/CI support Show the resolution, H/V frequency and input port of current input timing. Clear each old status of Auto-configuration and set the color temperature to Cool. Save user adjustment and OSD disappear. EN-12 AL1516W...
  • Page 14: Troubleshooting

    Using OSD, in case of missing full-screen image, please select other resolution or other vertical refresh timing. · Wait for a few seconds after adjusting the size of the image before changing or disconnecting the signal cable or powering OFF the monitor. EN-13 AL1516W...
  • Page 15 Check the power switch. · Check if AC power cord is properly connected to the monitor. · Check if video signal cable is properly connected at the back of monitor. · Check if the power of computer system is ON. EN-14 AL1516W...
  • Page 16: Specification

    262K Colors 83.5MHz 1280 x 800 @60Hz VESA DDC CI/DDC2B <20W < 1W D-Sub DVI-D 24pin (Only Dual-Input Model) Analog:0.7Vp-p(standard), 75 OHM, Positive Digital signal (Only Dual-Input Model) Horizontal : 331.2 mm Vertical : 207 mm 100-240VAC, 50/60Hz, 0.5A EN-15 AL1516W...
  • Page 17 Auto configuration (only Analog input model) Input signal Selection (only Dual input model) (Warm) Color (Cool) Color RGB Color temperature Reset OSD position . timeout Display information Exit 20 Watts CUL, FCC, VCCI, CCC, MPR II, CE, TUV/GS, UL, ISO13406-2 EN-16 AL1516W...
