RCA RC250BK User Manual

v5.0 (1.0.5.0) (EN/E/F)
Product registration
Thank you for purchasing an RCA product. We pride ourselves on the
quality and reliability of all our electronic products, but if you ever
need service or have a question our customer service staff stands
ready to help. Contact us at www.rcaaudiovideo.com. PURCHASE
REGISTRATION: Registering Online will allow us to contact you in
the unlikely event a safety notifi cation is required under the Federal
Consumer Safety Act. Register Online at:
WWW.RCAAUDIOVIDEO.COM. Click on Product Registration and
Fill Out the Brief Questionnaire.
Enregisregistro del productotrement du produit
Gracias por comprar un producto RCA. Nos enorgullece la calidad y
fi abilidad de todos nuestros productos electrónicos, pero si alguna vez necesita servicios técnicos o si tiene alguna pregunta,
nuestro personal de atención al cliente está a su disposición para ayudarle. Comuníquese con nosotros en
www.rcaaudiovideo.com. REGISTRO DE COMPRA: El registro en línea nos permitirá comunicarnos con usted en el caso de tener
que enviarle algún aviso de seguridad en virtud de la Ley Federal de Seguridad del Consumidor. Registre el producto en línea
en: WWW.RCAAUDIOVIDEO.COM. Haga clic en Registro del producto y responda al cuestionario.
Enregistrement du produit
Merci d'avoir acheté un produit RCA. Nous sommes fi ers de la qualité et de la fi abilité de tous nos produits électroniques,
mais en cas de nécessité de réparation ou pour toute question le personnel de notre service clientèle est prêt à vous aider.
Contactez-nous sur www.rcaaudiovideo.com. ENREGISTREMENT D'ACHAT: Enregistrer votre produit en ligne nous permettra
de communiquer avec vous pour tout avis de sécurité au sujet du produit en vertu du Federal Consumer Safety Act (Loi fédérale
de protection du consommateur). Enregistrez votre produit en ligne sur: WWW.RCAAUDIOVIDEO.COM. Cliquez sur
Enregistrement produit et remplissez le court questionnaire.
EN/E/F
It is important to read this user manual prior to using your new product for the fi rst time.
Es importante leer este manual antes de usar por vez primera su equipo.
Nous vous recommandons de lire ce manuel d'instructions avant d'utiliser votre nouveau produit pour la première fois.
General controls Soundfl ow
Clock Tuning – Select radio frequencies; when setting
• Soundfl ow works with any smartphone or
clock or alarm time, press to decrease time, or press and hold
music player with an external speaker. No
to decrease time rapidly.
wires or cables are required.
•
If you are using your phone's built in
Clock Tuning
– Select radio frequencies; when setting
alarm or your favorite application to wake up,
clock or alarm time, press to increase time, or press and hold
make sure Soundfl ow is on before you go to sleep.
to increase time rapidly.
Store – Store a radio station.
Radio
FM / Recall – Turn on the radio; recall stored radio stations.
Snooze/Sleep – Turn off the alarm function momentarily Turning on/off the Radio
(9 minutes); activate sleep function.
In clock mode, press FM / Recall to turn on the radio. Press
Off to turn off the radio.
Clock
Tuning the radio
Press Clock Tuning or Clock Tuning
The fi rst time you plug in your device it will radio frequency. Press and hold
automatically be in clock setting mode. Use the
or Clock Tuning
Clock Tuning or Clock Tuning buttons
for the next available station.
to set the time.
Built-in AFC
Setting clock manually
The Built In Automatic Frequency Control (AFC) helps to
1. In clock mode, press and hold Set Clock until the
reduce drift on FM reception and keeps the radio locked in
clock fl ashes to enter the clock setting mode.
on the FM station to which it is tuned.
2. Press Clock Tuning or Clock Tuning to set the
time.
This unit is equipped with an FM antenna at the back. Uncoil
• Press and hold Clock Tuning or
the antenna to its full length for best reception. Tape the
Clock • Tuning to decrease or increase the time
end of the antenna onto the wall if possible to improve
value quickly.
reception.
• The clock time is displayed in 12 hour format. The PM
indicator appears to show PM time.
Station presets
3. Press Set Clock to confi rm and exit clock setting
mode.
To store a station as preset:
1. Tune to a radio station.
2. Press Store. Preset location
Soundfl ow
Press Vol – / Vol + to select desired preset number, then
press Store again to save the station to that preset.
• This unit can store up to 20 stations. Your presets are
Playback with Soundfl ow
stored one by one from
1. Place your smartphone with audio playing on the top
To recall a preset station:
of the dock.
1. While the radio is playing, press FM / Recall. The
2. Press Soundfl ow On / Off to enable Soundfl ow audio
current preset station number shows on the display.
playback.
2. Press FM / Recall repeatedly to select a desired preset
3. The SOUNDFLOW indicator appears and the dock
station.
amplifi es your audio automatically.
Español
IMPORTANTE INSTRUCCIONES DE SEGURIDAD
FAVOR DE GUARDAR ESTO PARA UNA REFERENCIA FUTURA
• Use solamente con el carro, soporte,
English
IMPORTANT SAFETY INSTRUCTIONS
user manual
manual de usuario
guide de l'utilisateur
RC250BK
RC250WH
Some of the following information may not apply to your
particular product; however, as with any electronic product,
precautions should be observed during handling and use.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
• Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifi ers) that produce heat.
• Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If
the provided plug does not fi t into your outlet, consult
an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
• Only use attachments/accessories specifi ed by the
manufacturer.
• Use only with the cart, stand,
tripod, bracket, or table specifi ed
by the manufacturer, or sold with
the apparatus. When a cart is used,
use caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
Setting alarms
Setting alarm time
This unit allows two alarms to be set.
1. Before setting the time, make sure no audio is playing
through the FM radio or Soundfl ow by pressing the Off
button, then press and hold Set Al 1 to Set Alarm 1.
2. Press Clock Tuning or Clock Tuning
alarm time. Press and hold
Tuning to decrease or increase the time value
quickly.
3. To confi rm this alarm time, press Set Al 1.
4. Follow steps 1 through 3 to Set Alarm 2.
Selecting alarm source
You may choose radio or alarm as your alarm source.
• In clock mode, press Set Al 1 repeatedly to select
desired alarm source (beep, radio, or off).
BEEP – Wake to beep tone.
RADIO – Wake to radio. (You will wake up to your
to adjust the
most recently tuned radio station.)
Clock Tuning
• After setting Alarm 1, press Set Al 2 repeatedly to
for two seconds to automatically search
select alarm source for Alarm 2.
Tune to a valid desired station before you
select wake to Radio.
Wake to radio
To set wake radio station:
1. Turn on the radio and tune to the desired station.
2. Turn off the radio and press Set Al 1 to set the alarm
mode to radio, then press and hold Set Al 1 to adjust
the alarm time.
3. After pressing Set Al 1 to store the alarm time you will
be prompted to set the radio alarm volume.
4. Press Clock Tuning or Clock Tuning
desired volume level.
5. Press Set Al 1 to commit your selection.
P01 P01 fl ashes on the display.
The audio source must be turned off before
setting alarm mode and time.
to .
P01 P01 P20 P20
Ways to turn off alarm
• To silence the alarm function momentarily, press
Snooze/Sleep. The BEEP or RADIO alarm mode
indicator will be fl ashing during the snooze period.
The alarm or radio will turn on again when the snooze
period (9 minutes) is over.
• To turn off the alarm, press Off. The alarm or radio will
activate again the next day.
• Ninguna fuente de fl ama abierta, tal como velas
PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualifi ed service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
has been damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
ADDITIONAL SAFETY INFORMATION
• The AC/DC adapter supplied with this product is
intended to be correctly oriented in a vertical or fl oor
mount position.
• Apparatus shall not be exposed to dripping or splashing
and no objects fi lled with liquids, such as vases, shall be
placed on the apparatus.
• Always leave suffi cient space around the product for
ventilation. Do not place product in or on a bed, rug,
bookcase or cabinet that may prevent air fl ow through
vent openings.
• Do not place lighted candles, cigarettes, cigars, etc. on
the product.
• Care should be taken so that objects do not fall into the
product.
• Do not attempt to disassemble the cabinet. This product
does not contain customer serviceable components.
• The marking information is located at the bottom of
the apparatus.
• To completely disconnect the power input, the AC/DC
adapter of the apparatus should be disconnected from
the mains.
• AC/DC adapter is a disconnect device. The AC/DC
adapter should not be obstructed OR should be easily
accessed during intended use.
• The ventilation should not be impeded by covering
the ventilation openings with items such as newspaper,
table-cloths, curtains, etc.
• No naked fl ame sources such as lit candles should be
placed on the apparatus.
• Batteries should be properly disposed of.
Electrical power information
]
AC/DC Adapter:
Input: 100 - 240 V ~ AC 50/60 Hz
Output: 5.0 V---DC 1.2 A
Portable Cart Warning
Setting alarms
• To disable the alarm function completely, from clock
mode press Set Al 1 or Set Al 2 repeatedly until no
alarm mode indicator shows on the display.
Sleep function
to set the
Clock Tuning or Clock
In sleep mode, the unit will turn off automatically after a
specifi ed time (up to 90 minutes).
1. Press Snooze/Sleep repeatedly to cycle through the
available durations for Sleep Mode (90, 80, 70, 60, 50,
40, 30, 20, 10, or 0 minutes.) Note that the radio will
automatically turn on when initiating SLEEP mode,
and it will stay on for the duration of the selected
Sleep time.
2. To view remaining time in sleep mode, press Snooze/
Sleep.
3. To cancel the sleep function, press Off or press
Snooze/Sleep repeatedly to select OFF.
USB charging
Use the USB charging port on the left of the dock to charge
your smartphone or to power USB powered devices such as
a USB type lamp or fan.
To connect your cell phone for charging:
Use a USB cable (not included) to connect your cell phone
to the USB connector of the dock. Your cell phone should
start charging.
to select the
Charging function may not be supported for
all phones or electronic devices.
Antes de comenzar
Colección a la fuente de suministro
• Conecte el adaptador de corriente a una toma
FCC Information Before you begin
• Normal operation will resume after AC power is
Note: This equipment has been tested and found to comply
restored so you will not have to reset the time and
with the limits for a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to provide alarms.
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
To install the batteries:
can radiate radio frequency energy and, if not installed and
1. Remove battery compartment door (located at the
used in accordance with the instructions, may cause harmful
bottom of the device) by applying thumb pressure to
interference to radio communications.
the tab on battery door and then lift the door out and
off the cabinet.
However, there is no guarantee that interference will not
2. Insert 2 AA batteries (not included) to the battery
occur in a particular installation. If this equipment does cause
compartment.
harmful interference to radio or television reception, which
3. Replace the compartment door.
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one
or more of the following measures: Power failure indicator
• Reorient or relocate the receiving antenna.
If you have not installed 2 AA batteries (not included) in the
• Increase the separation between the equipment and
product, or the batteries run out while power is interrupted,
receiver.
all the settings (clock and alarm) will be lost. After AC power
• Connect the equipment into an outlet on a circuit
is restored, the digital display will fl ash to indicate that
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician power was interrupted and you should readjust the time and
for help. alarm settings.
Changes or modifi cations not expressly approved by VOXX
Note: It is recommended to replace the batteries at least
Accessories Corporation could void the user's authority to
once per year even if no power failures have occurred.
operate the equipment.
General controls
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
Before you begin
Plugging in for power
• Connect the power adapter to a convenient wall outlet.
• Once connected to power, the clock display fl ashes.
Top view
Refer to the Clock section for instructions on properly
setting the Clock.
Vol –/Set Al 1 – Set Alarm 1 alarm source (beep/radio/off) or
decrease volume; press and hold to Set Al 1 alarm time.
Battery back-up operation
Vol +/Set Al 2 – Set Alarm 2 alarm source (beep/radio/off) or
• This clock is equipped with a timekeeping system that
increase volume; press and hold to Set Al 2 alarm time.
can be powered with 2 AA batteries (not included). The
power failure protection circuit will not operate unless
Off/Set Clock – Press to turn off audio or alarms; press and
batteries are installed.
hold to set clock time.
• When normal household power is interrupted, the
batteries will power the clock to keep track of time and
Soundfl ow On / Off – Press to switch the Soundfl ow audio
alarm settings programmed into memory.
feature on and off.
Warranty information
12 Month Limited Warranty assume for the Company any liability other than expressed
Applies to RCA Clock Radios herein in connection with the sale of this product.
VOXX Accessories Corporation (the Company) warrants to Some states do not allow limitations on how long an implied
the original retail purchaser of this product that should warranty lasts or the exclusion or limitation of incidental or
this product or any part thereof, under normal use and consequential damage so the above limitations or exclusions
conditions, be proven defective in material or workmanship may not apply to you. This Warranty gives you specifi c legal
within 12 months from the date of original purchase, such
rights and you may also have other rights which vary from
defect(s) will be repaired or replaced with reconditioned
state to state.
product (at the Company's option) without charge for parts
and repair labor. Recommendations before returning your product for a
warranty claim:
To obtain repair or replacement within the terms of this • Properly pack your unit. Include any remotes, memory
Warranty, the product is to be delivered with proof of cards, cables, etc. which were originally provided with
warranty coverage (e.g. dated bill of sale), specifi cation of the product. However DO NOT return any removable
defect(s), transportation prepaid, to the Company at the batteries, even if batteries were included with the
address shown below. original purchase. We recommend using the original
carton and packing materials. Ship to the address shown
This Warranty does not extend to the elimination of
below.
externally generated static or noise, to correction of antenna
• Note that product will be returned with factory default
problems, loss/interruptions of broafast or internet service,
settings. Consumer will be responsible to restore any
to costs incurred for installation, removal or reinstallation of
personal preference settings.
product, to corruptions caused by computer viruses, spyware
or other malware, to loss of media, fi les, data or content, Audiovox Return Center
or to damage to tapes, discs, removable memory devices or Attn: Service Department.
cards, speakers, accessories, computers, computer peripherals, 150 Marcus Blvd.
other media players, home networks or vehicle electrical Hauppauge N.Y. 11788
systems.
1-800-645-4994
This Warranty does not apply to any product or part thereof
which, in the opinion of the Company, has suffered or
For Canada Customers, please ship to:
been damaged through alteration, improper installation,
Audiovox Return Centre
mishandling, misuse, neglect, accident, or by removal or
c/o Genco
defacement of the factory serial number/bar code label(s). 6685 Kennedy Road,
THE EXTENT OF THE COMPANY'S LIABILITY UNDER THIS Unit#3, Door 16,
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT Mississuaga, Ontario
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE L5T 3A5
COMPANY'S LIABILITY EXCEED THE PURCHASE PRICE PAID BY
PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or
liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE
LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY.
ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY
MUST BE BROUGHT WITHIN A PERIOD OF 24 MONTHS
FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL
THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER
WARRANTY. No person or representative is authorized to
Reloj
Controles generales
La primera vez que usted conecte su dispositivo
este estará automaticamente en modo de
