Dell PowerEdge VRTX Owner's Manual

Poweredge m620 systems owner's manual.
Hide thumbs

Advertisement

Dell PowerEdge M620 Systems (For Dell PowerEdge
VRTX Enclosure)
Owner's Manual
Regulatory Model: HHB
Regulatory Type: HHB003

Advertisement

Troubleshooting

   Related Manuals for Dell PowerEdge VRTX

   Summary of Contents for Dell PowerEdge VRTX

  • Page 1

    Dell PowerEdge M620 Systems (For Dell PowerEdge VRTX Enclosure) Owner's Manual Regulatory Model: HHB Regulatory Type: HHB003...

  • Page 2

    CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. © 2013 Dell Inc. Trademarks used in this text: Dell , the Dell logo, Dell Boomi , Dell Precision , OptiPlex...

  • Page 3: Table Of Contents

    Contents 1 About Your System........................7 ................................7 Introduction ........................8 Front-Panel Features And Indicators ......................8 Using USB Diskette Or USB DVD/CD Drives ..............................8 Hard-Drive Features ..........................9 Other Information You May Need 2 Using The System Setup And Boot Manager...............11 ..........................

  • Page 4

    3 Installing Server Module Components.................. 25 .............................. 25 Recommended Tools ......................25 Installing And Removing A Server Module ..........................25 Removing A Server Module ..........................27 Installing A Server Module .......................27 Opening And Closing The Server Module ..........................27 Opening The Server Module ..........................28 Closing The Server Module ............................

  • Page 5

    .......................62 Troubleshooting The NVRAM Backup Battery 5 Using System Diagnostics....................... 63 ............................63 Dell Online Diagnostics ........................63 Dell Embedded System Diagnostics ..................63 When To Use The Embedded System Diagnostics ....................64 Running The Embedded System Diagnostics ..............64 Running Embedded System Diagnostics From An External Media ..........................

  • Page 6

    ............................142 Diagnostic Messages ..............................142 Alert Messages 9 Getting Help..........................143 ..............................143 Contacting Dell...

  • Page 7: About Your System

    This document provides information on the Dell PowerEdge M620 server module that is specifically configured for the PowerEdge VRTX enclosure, and can be identified by a label marked PCIe on the server module. NOTE: This server module is not supported on the Dell PowerEdge M1000e enclosure with the PowerEdge VRTX mezzanine card.

  • Page 8: Front-panel Features And Indicators

    DVD/CD drive, keyboard, or mouse. The USB drives can be used to configure the server module. NOTE: Your server module supports only Dell-branded USB 2.0 drives. Use the optional external drive storage tray to support the drive while in use.

  • Page 9: Other Information You May Need

    NOTE: The server module must have a hard drive or a hard-drive blank installed in each hard-drive bay. Figure 3. Hard-Drive Indicators 1. hard-drive activity indicator (green) 2. hard-drive status indicator (green and amber) NOTE: If the hard drive is in Advanced Host Controller Interface (AHCI) mode, the status LED (on the right side) does not function and remains off.

  • Page 10

    NOTE: Always check for updates on dell.com/support/manuals and read the updates first because they often supersede information in other documents.

  • Page 11: Using The System Setup And Boot Manager

    Description <F2> Enters the System Setup. <F10> Enters System Services, which opens the Dell Lifecycle Controller 2 (LC2). The Dell LC2 allows you to access utilities such as embedded system diagnostics. For more information, see the Dell LC2 documentation. <F11>...

  • Page 12: Entering System Setup

    NOTE: Operating systems must be UEFI-compatible to be installed from the UEFI boot mode. DOS and 32-bit operating systems do not support UEFI and can only be installed from the BIOS boot mode. NOTE: For the latest information on supported operating systems, see dell.com/support. Entering System Setup Turn on or restart your system.

  • Page 13: System Setup Main Screen

    System Setup Main Screen NOTE: Press <Alt><F> to reset the BIOS or UEFI settings to their default settings. Menu Item Description System BIOS This option is used to view and configure BIOS settings. iDRAC Settings This option is used to view and configure iDRAC settings. Device Settings This option is used to view and configure device settings.

  • Page 14: Memory Settings Screen

    Menu Item Description System Service Tag Displays the system Service Tag. System Manufacturer Displays the name of system manufacturer. System Manufacturer Displays the contact information of the system manufacturer. Contact Information Memory Settings Screen Menu Item Description System Memory Size Displays the amount of memory installed in the system.

  • Page 15: Sata Settings Screen

    Menu Item Description Virtualization Allows you enable or disable the additional hardware capabilities provided for virtualization. By Technology default, the Virtualization Technology option is set to Enabled. Adjacent Cache Line Allows you to optimize the system for applications that require high utilization of sequential Prefetch memory access.

  • Page 16: Boot Settings Screen

    Boot Settings Screen Menu Item Description Boot Mode Allows you to set the boot mode of the system. CAUTION: Switching the boot mode may prevent the system from booting if the operating system is not installed in the same boot mode. If the operating system supports UEFI, you can set this option to UEFI.

  • Page 17: Serial Communications Screen

    NOTE: Use this option only for troubleshooting purposes. If one or more of the PCIe mezzanine card slots are disabled, an error message is displayed during system startup. For proper operation, make sure that the server module has two Dell PCIe mezzanine cards installed and both cards are set to Enabled.

  • Page 18: System Profile Settings Screen

    Custom. By default, the System Profile option is set to Performance Per Watt Optimized (DAPC). DAPC is Dell Active Power Controller. NOTE: The following parameters are available only when the System Profile is set to Custom.

  • Page 19: System Security Screen

    BIOS updates, it is recommended to set this field to Limited. By default, the Local BIOS Update Support option is set to Unlocked. NOTE: BIOS updates using Dell Update Package is not affected by this option. Power Button Allows you to enable or disable the power button on the front of the system.

  • Page 20: System And Setup Password Features

    Menu Item Description Asset Tag Displays the asset tag and allows you to modify it for security and tracking purposes. Keyboard NumLock Allows you to set whether the system boots with the NumLock enabled or disabled. By default the Keyboard NumLock is set to On. NOTE: This field does not apply to 84-key keyboards.

  • Page 21: Using Your System Password To Secure Your System

    In the System Security screen, verify that Password Status is Unlocked. Select System Password , enter your system password, and press <Enter> or <Tab>. Use the following guidelines to assign the system password: – A password can have up to 32 characters. –...

  • Page 22: Operating With A Setup Password Enabled

    Select System Password, alter or delete the existing system password and press <Enter> or <Tab>. Select Setup Password, alter or delete the existing setup password and press <Enter> or <Tab>. NOTE: If you change the System and/or Setup password a message prompts you to re-enter the new password.

  • Page 23: Boot Manager Screen

    Displays a list of the drivers installed on the system and their health status. Launch System Setup Enables you to access the System Setup. System Utilities Enables you to access the BIOS Update File Explorer, run the Dell Diagnostics program, and reboot the system. UEFI Boot Menu...

  • Page 24: Idrac Settings Utility

    Enable a LAN Platform Event Trap (PET) destination • Attach or detach the Virtual Media devices For more information on using iDRAC7, see the iDRAC7 User's Guide, at dell.com/supoort/manuals. Entering The iDRAC Settings Utility Turn on or restart the managed system.

  • Page 25: Installing Server Module Components

    Wrist grounding strap Installing And Removing A Server Module NOTE: Server modules that are specifically configured for the PowerEdge VRTX enclosure, can be identified by a label marked PCIe on the server module. NOTE: Ensure that you have downloaded the latest BIOS on the server module(s) from dell.com/support.

  • Page 26

    Figure 4. Removing and Installing the I/O Connector Cover 1. I/O connector cover Figure 5. Removing and Installing a Server Module...

  • Page 27: Installing A Server Module

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 28: Closing The Server Module

    Figure 6. Opening and Closing the Server Module 1. I/O connector cover 2. server module cover 3. release button 4. cover alignment pins and notches Closing The Server Module Ensure that no tools or parts are left inside the server module. Align the notches in the edges of the chassis with the cover alignment pins on the inner sides of the cover.

  • Page 29: Inside The Server Module

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 30: Installing The Cooling Shroud

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 31

    Memory bus operating frequency can be 1600 MT/s, 1333 MT/s, 1066 MT/s, or 800 MT/s depending on: • DIMM type (UDIMM, RDIMM, or LRDIMM) • DIMM configuration (number of ranks) • maximum frequency of the DIMMs • number of DIMMs populated per channel •...

  • Page 32: General Memory Module Installation Guidelines

    Figure 9. Memory Socket Locations Memory channels are organized as follows: Processor 1 channel 0: memory sockets A2, A6, and A10 channel 1: memory sockets A1, A5, and A9 channel 2: memory sockets A4, A8, and A12 channel 3: memory sockets A3, A7, and A11 Processor 2 channel 0: memory sockets B2, B6, and B10 channel 1: memory sockets B1, B5, and B9...

  • Page 33: Mode-specific Guidelines

    • Up to three LRDIMMs can be populated regardless of rank count. • Up to two quad-rank RDIMMs and up to three dual- or single-rank RDIMMs can be populated per channel. When a quad-rank RDIMM is populated in the first slot with white release levers, the third DIMM slot in the channel with green release levers cannot be populated.

  • Page 34: Sample Memory Configurations

    Advanced ECC (Lockstep) Advanced ECC mode extends SDDC from x4 DRAM based DIMMs to both x4 and x8 DRAMs. This protects against single DRAM chip failures during normal operation. Memory installation guidelines: • Memory modules must be identical in size, speed, and technology. •...

  • Page 35

    Table 2. Memory Configurations – Single Processor System Capacity DIMM Size (in Number of Organization and DIMM Slot Population (in GB) DIMMs Speed 1R x8, 1333 MT/s 1R x8, 1600 MT/s 1R x8, 1333 MT/s A1, A3 1R x8, 1600 MT/s 1R x8, 1333 MT/s A1, A2, A3, A4 1R x8, 1600 MT/s...

  • Page 36

    Table 3. Memory Configurations – Two Processors System Capacity (in DIMM Size (in Number of Organization and DIMM Slot Population DIMMs Speed 1R x8, 1333 MT/s A1, A2, A3, A4, B1, B2, B3, B4 1R x8, 1600 MT/s 1R x8, 1333 MT/s A1, A2, A3, A4, A5, A6, A7, A8, B1, B2, B3, B4, B5, B6, B7, B8 2R x8, 1333 MT/s...

  • Page 37: Removing Memory Modules

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 38: Installing Memory Modules

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 39: Pcie Mezzanine Cards

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 40: Installing A Pcie Mezzanine Card

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 41: Management Riser Card

    Close the server module. Install the server module in the enclosure. Management Riser Card The management riser card provides two SD card slots and a USB interface dedicated for the embedded hypervisor. This card offers the following features: • Internal Dual SD interface — maintains a mirrored configuration using SD cards in both slots and provides redundancy.

  • Page 42: Internal Usb Key

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 43: Sd Vflash Card

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 44: Installing The Network Daughter Card/lom Riser Card

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 45: Processors

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 46

    Figure 16. Installing and Removing a Heat Sink 1. screws (4) 2. heat sink Use a clean, lint-free cloth to remove any thermal grease from the surface of the processor shield. CAUTION: The processor is held in its socket under strong pressure. Be aware that the release lever can spring up suddenly if not firmly grasped.

  • Page 47

    Figure 17. Processor Shield Opening and Closing Lever Sequence 1. OPEN 1st label 4. close first lever 2. open first lever 5. CLOSE 1st label 3. processor Hold the tab on the processor shield and rotate it upward and out of the way. 10.

  • Page 48

    Figure 18. Installing and Removing a Processor 1. socket-release lever 2 6. socket-release lever 1 2. pin-1 corner of processor 7. pin-1 corner on system board 3. tabs (2) 8. processor 4. processor shield 5. socket protective cap...

  • Page 49: Installing A Processor

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 50: Hard Drives

    b) Place the heat sink onto the processor. c) Tighten the four screws to secure the heat sink to the server module board. NOTE: Do not over-tighten the heat sink retention screws when installing the heat sink. To prevent over- tightening, tighten the retention screw until resistance is felt, and stop once the screw is seated.

  • Page 51: Installing A Hard Drive/ssd

    Figure 19. Removing and Installing a Hard Drive/SSD 1. release button 2. hard drive/SSD 3. hard-drive/SSD connector (on backplane) 4. hard-drive/SSD carrier handle Installing A Hard Drive/SSD CAUTION: When a replacement hot-swappable hard drive/SSD is installed and the server module is powered on, the drive automatically begins to rebuild.

  • Page 52: Configuring The Boot Drive

    If you need to power off the server module to service a hard drive, wait 30 seconds after the server module’s power indicator turns off before removing the hard drive. Otherwise, the hard drive may not be recognized after it is reinstalled and the server module is powered on again.

  • Page 53: Hard-drive/ssd Backplane

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 54: Installing The Hard-drive/ssd Backplane

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 55: Installing The System Board

    Figure 22. Removing and Installing the System Board 1. I/O connector cover 4. tabs on system chassis 2. retention latch 5. slots in system board tray 3. system board Installing The System Board Transfer the following components to the new system board: –...

  • Page 56: Nvram Backup Battery

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 57: Storage Controller Card

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 58: Installing The Storage Controller Card

    Figure 24. Removing and Installing the Storage Controller Card 1. storage controller card 2. screws (2) 3. tab 4. connector Installing The Storage Controller Card Holding by its edges, position the storage controller card so that the card-connector aligns with the system board connector.

  • Page 59: Troubleshooting Your System

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 60: Troubleshooting Hard Drives

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 61: Troubleshooting An Internal Sd Card

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 62: Troubleshooting The Nvram Backup Battery

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 63: Using System Diagnostics

    Dell Online Diagnostics Dell Online Diagnostics, a stand-alone suite of diagnostic programs or test modules, allows you to run diagnostic tests on the systems in a production environment, and helps you ensure maximum uptime of your systems. Online Diagnostics allows you to run diagnostic tests on chassis and storage components such as hard drives, physical memory, and network interface cards (NICs).

  • Page 64: Running The Embedded System Diagnostics

    As the system boots, press <F11>. Use the up and down arrow keys to select System Utilities → Launch Dell Diagnostics . The ePSA Pre-boot System Assessment window is displayed, listing all devices detected in the system. The diagnostics starts executing the tests on all the detected devices.

  • Page 65: Jumpers And Connectors

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 66: System Board Connectors

    System Board Connectors Figure 25. System Board Connectors Table 5. System Board Connectors Item Connector Description BATTERY Connector for the 3.0 V coin cell battery CPU2 Processor socket 2 B3, B7, B11, B4, B8, B12 Memory module sockets (for processor 2) A1, A5, A9, A2, A6, A10 Memory module sockets (for processor 1) CPU1...

  • Page 67: Disabling A Forgotten Password

    Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

  • Page 69: Technical Specifications

    Technical Specifications Processor Processor type One or two Intel Xeon processor E5-2600 product family Memory Architecture 1600 MT/s, 1333 MT/s, 1066 MT/s, or 800 MT/s DDR3 and LV-DDR3 DIMMs Memory module sockets Twenty-four 240-pin Memory module capacities RDIMMs 2 GB (single-rank), 4 GB (single- and dual-rank), 8 GB (dual-rank), 16 GB (dual-rank), and 32 GB (quad-rank) UDIMMs 2 GB (single-rank) and 4 GB (dual-rank)

  • Page 70

    CR 2032 3.0 V Lithium coin cell Environmental NOTE: For additional information about environmental measurements for specific system configurations, see dell.com/environmental_datasheets. Storage temperature –40 °C to 65 °C (–40 °F to 149 °F) with a maximum temperature gradation of 20 °C per hour.

  • Page 71

    Dell PowerEdge RAID Controller (PERC) H710/H710P cards (in dual-processor configurations) • When populating the server module slots in the PowerEdge VRTX enclosure with only PowerEdge M620 server modules: – Install only 97 mm wide heat sink(s). – Dual-processor server modules with PERC H310 cards cannot be mixed with single-processor server modules.

  • Page 73: System Messages
