R-202M/R-201M O/M&C/B

OVEN AND ACCESSORIES

3b
1 Control panel
2 Oven lamp
3a Door opening button (R-201M)
3b Door opening handle (R-202M)
4 Waveguide cover (DO NOT REMOVE)
5 Seal packing
6 Oven cavity
7 Door seals and sealing surfaces
8 Door latches
9 Ventilation openings
10 Outer cabinet
11 Power cord
ACCESSORIES:
Check to make sure the following accessories
are provided:
12 Turntable 13 Roller stay 14 Seal packing
Place the roller stay in the seal packing on the base
of the cavity, then place the turntable on to the roller
stay.
To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
9/1/01 2:27 pm Page 2
7
8
11
6 5 4
2
1
2
3a
9
10
12
13
14
