User's Manual
SSCF- - 200/300
SSCF
200/300
One Port RS-422/485 Serial
CompactFlash Card
QUATECH, INC.
5675 Hudson Industrial Parkway
Hudson, Ohio 44236
TEL: (330) 655-9000
FAX: (330) 655-9010
http://www.quatech.com.
CompactFlash Card
User's Manual P/N: 940-0190-110
Version 1.10, 02.05.04

Advertisement

Table of Contents
loading

Related Manuals for Quatech SSCF-200

Summary of Contents for Quatech SSCF-200

  • Page 1 User’s Manual SSCF- - 200/300 SSCF 200/300 One Port RS-422/485 Serial CompactFlash Card QUATECH, INC. 5675 Hudson Industrial Parkway Hudson, Ohio 44236 TEL: (330) 655-9000 FAX: (330) 655-9010 http://www.quatech.com. CompactFlash Card User’s Manual P/N: 940-0190-110 Version 1.10, 02.05.04...
  • Page 2 The authors have taken due care in the preparation of this document and every attempt has been made to ensure its accuracy and completeness. In no event will Quatech, Inc. be liable for damages of any kind, incidental or consequential, in regard to or arising out of the performance or form of the materials presented herein or in any software program(s) that may accompany this document.

  • Page 3: Table Of Contents

    SSCF-200/300 Table of contents 1. Overview --------------------------------------------------------------------------------------------------- 4 2. About The SSCF-200/300------------------------------------------------------------------------------ 4 3. Installing The SSCF-200/300 ------------------------------------------------------------------------- 5 3.1 Windows CE, PocketPC------------------------------------------------------------------------- 5 3.2 Windows 95, 98, Me, 2000, XP ---------------------------------------------------------------- 5 3.3 DOS & Windows 3.x ----------------------------------------------------------------------------- 5 4.

  • Page 4: Overview

    PC or PDA. The CF+ specification extends the earlier memory-only CompactFlash interface to enable the use of I/O devices and to provide the extra power required by I/O cards. The SSCF-200/300 is an I/O type device and therefore requires a CF+ capable slot.

  • Page 5: Quatech Compactflash Card User's Manual Sscf

    4. SSCF-200/300 Register Interface For reference, the SSCF-200/300 behaves as a 5V card to the host system because Vs1 and Vs2 pins are not connected. This is to make the host default to 5V when possible, giving the highest RS- 422/485 output signals and therefore the best noise margins.

  • Page 6: Hardware Specification

    5. Hardware Specification 5.1 PINOUT The SSCF-200/300 is supplied with a 300mm long Type 46 cable that terminates with a DB9 Male connector with female screwlocks (to match the port at the back of a PC) The pin-out below applies to both the SSCF-200/300 card and the DB9 male connector on the supplied cable (the cable is pinned one-to-one).

  • Page 7: Electrical

    SSCF-200/300 5.2 ELECTRICAL All figures quoted are typical parameters @ 25°C ESD PROTECTION: All RS-422/485 signal lines on the SSCF-200/300 card are protected against electrostatic discharge (ESD) >1kv – IEC1000-4-4 UART CLOCK SPEED: x1: UART CLOCK is 1.8432MHz ->115.2KBaud max x8: UART CLOCK is 14.7456MHz->921.6KBaud max...

  • Page 8: Notes On Serial Data Throughput

    Quatech CompactFlash Card User’s Manual SSCF-200/300 5.6 NOTES ON SERIAL DATA THROUGHPUT The maximum serial baud rate of 921KBits/sec does not imply that the maximum sustained throughput rate of the serial port will be as high. The actual throughput rate that can be achieved depends on many factors including the host PC speed, the serial data source’s data block size and...

  • Page 9: Using The Sscf-200/300

    6.3 TXD AND RTS DRIVERS The RTS signal driver on the SSCF-200/300 is always enabled, regardless of the mode in which the card is to be used. The SSCF-200/300 incorporates an auto-tristate feature on the TXD signal driver. The driver is enabled only when data is in the process of being transmitted.

  • Page 10: Rs-422 Operation

    6.5 RS-485 OPERATION The SSCF-200/300 can be used for both half-duplex (one twisted pair) and full-duplex (two twisted pairs) arrangements, however for half-duplex mode, the link between the TXD and RXD signals must be made externally on the DB9 connector. Also, it should be noted that the transmitted characters will always be received in this mode.

  • Page 11: Warranty

    7. Warranty Information 7. Warranty Information Quatech, Inc. warrants the SSCF-200/300 to be free of defects for five (5) years from the date of purchase. Quatech, Inc. will repair or replace any board that fails to perform under normal operating conditions and in accordance with the procedures outlined in this document during the warranty period.

This manual is also suitable for:

Sscf-300
