TROUBLE SHOOTING GUIDE

SYMPTOMS CHECK POINTS
In the power
LED illuminated?
NO SOUND
Is the Diagnosis
LED illuminated?
No power to power wire
No power to remote
AMP NOT
wire with receiver on
SWITCHING
ON
Fuse broken
Check Speaker Leads
NO SOUND
IN ONE
CHANNEL
Check Audio Leads
AMP
TURNING OFF
Check Speaker load
MEDIUM/HIGH
impedance
VOLUME
PROTECTION Temperature shutdown
LED ON (RED)
Speaker wires short circuit
11
CURE
Check fuses in amplifier.
Be sure Turn-on lead is connected
Check signal leads. Check gain
control.
Check Tuner/Deck volume level.
Clean contacts on fuse holders.
Check for speaker short or
amplifier overheating.
Repair power wire or connections.
Check connections to radio.
Check fuse
Inspect for short circuit or an
open connection.
Reverse Left and Right RCA inputs
to determine if it is occurring
before the amp.
Be sure proper speaker load
impedance recommendations
are observed.
(If you use an ohmmeter to check
speaker resistance, please
remember that DC resistance and
AC impedance may not be the
same. )
Turn radio down
Separate speaker wires and insulate

WARNING

Investigate the Layout of you automobile thoroughly before drilling or cutting any
holes. Take care when you work near the thanks, lines, or hydraulic lines, and
electrical wiring. Don't mount this system so that the wire connections ate
unprotected are subject to pinching or damage from nearby objects.
The +12V DC power wire must be fused at the battery positive terminal connection.
Before making or breaking power connections at this system power terminals,
disconnect the +12V wire at the battery end.
Cofirm your radio/cassette player and/or other equip is turned off while connecting
the input jacks and speaker terminals.
If yiu need to replace the power fuse, replace it only with a fuse identical to that
supplied with the system. Using a fuse of differenct type ot rating may result in
damage to this system which isn't covered by the warranty.
SPECIFICATIONS
MODEL NO REACT4-900 REACT1-700
CH 4CH
MAX Power
900W
RMS @4 O hm
70W x 4
RMS @2 O hm 100W x 4
T.H.D 0.02%
S/N Ratio 98dB
Frequency
20Hz-20KHz 50Hz-150Hz
Response ( 1dB)
Fuse 25A x 2
Dimension(inches)
2.3X11.7X10CM 2.3X11.7X6.5CM
BASS Knob
No
FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
Power Acoustik
REACT1-1100 REACT1-1800
1CH 1CH 1CH
700W 1100W 1800W
175WX1 300WX1 500WX1
250WX1 400WX1 700WX1
0.02% 0.02% 0.02%
98dB 98dB 98dB
50Hz-150Hz 50Hz-150Hz
25A 40A 25A x 2
2.3X11.7X7.3CM 2.3X11.7X11CM
Yes Yes Yes
12
