Summary of Contents for Power Acoustik BAMF-1200/4

  • Page 2 ************* OWNER'S MANUAL BAMF800/2 BAMF1250/2 BAMF1800/2 BAMF2200/2 BAMF2600/2 BAMF1200/4 BAMF1600/4 BAMF2000/1D BAMF4000/1D BAMF5500/1D...
  • Page 4 In the interest of safety, Power Acoustik recommends listening at lower volume levels while driving.
  • Page 5: Table Of Contents

    TABLE OF CONTENTS PLANNING YOUR SYSTEM ... WIRING CONNECTION ... PANEL LAYOUT ... CONTROL FUNCTIONS ... SPEAKER CONNECTION MONO CHANNEL ... TROUBLE SHOOTING GUIDE ... SPECIFICATION ... WARNING ... PLANNING YOUR SYSTEM Before beginning the installation, consider the following: 1. Do you plan to add additional mobile electronics equipment in the future? If you plan to expand your system by adding other components sometime in the future, ensure adequate space is left and cooling requirements are met.
  • Page 6 CONNECTING THE POWER (Fig.1,2) CAUTION: AS A PRECAUTION, DISCONNECT THE POWER WIRE FROM THE BATTERY WHILE MAKING THE POWER AND GROUND CONNECTIONS TO THE AMPLIFIER. 4/8 GAUGE(Thicker if planning for additional Amplifiers) wire is recommended for both the power and ground wires. 12 Gauge, for the remote turn-on wire. Both types are available at most Mobile Audio Dealers or Installation Shop.
  • Page 7 - 5 -...
  • Page 8: Panel Layout

    PANEL LAYOUT - 6 -...
  • Page 9: Panel Layout

    PANEL LAYOUT - 7 -...
  • Page 10: Control Functions

    BAMF2000/1D, 4000/1D, 55001D : The boost can be adjusted between 0dB to 18dB. 7. Auxiliary outputs The Auxiliary outputs offer Power Acoustik amplifiers easy, unlimited system expansion. Route RCA's from the line out of the first amplifier to the line input of a second amplifier when using a single source output.
  • Page 11 CONTROL FUNCTIONS 8. SUBSONIC BAMF1250/2, 1800/2, 22200/2, 2600/2 : The frequency can be adjusted between 15Hz and 50Hz. BAMF2000/1D, 4000/1D, 5500/1D : The frequency can be adjusted between 20Hz and 50Hz. 9. REMOTE Controls the subwoofer amplifier gain, from a remote location for ease of adjustment during listening.
  • Page 12: Control Functions

    CONTROL FUNCTIONS 16. FUSE These fuses protect the amplifier against internal electrical damage and are meant to protect the amplifier only. All other power connections should be fused at the source. BAMF800/2 : 25A X 1 BAMF1250/2 : 20A X 2 BAMF2200/2 : 20A X 4 BAMF2600/2 : 25A X 4 BAMF1200/4 : 25A X 2...
  • Page 13 MASTER MODE CONFIGURATION FIG. 2 BAMF 2000/1D, BAMF 4000/1D 1.Lowest Recommended Impedance is 1ohm mono. 2.RCA Inputs are connected to both Left and Right channels 3.Gain controls to be set match input source 4.Line Output configured for stereo operation - 11 -...
  • Page 14 STRAPPED CONFIGURATION FIG. 3 BAMF 2000/1D, BAMF 4000/1D STRAPPED CONFIGURATION 2-4ohms 1.Lowest Recommended Impedance is 2ohm Stereo 2.RCA Inputs are connected to both Left and Right channels 3.Gain controls to be set match input source 4.Line Output is configured summed bridged which is ideal for subwoofer applications - 12 -...
  • Page 15 FIG. 4 MASTER MODE CONFIGURATION BAMF5500/1D 1. Lowest recommended impedance is 1 Ohm Mono. 2. RCA Inputs are connected to both left and right cnannels. 3. Gain control is to be set to match input source. - 13 -...
  • Page 16 FIG. 5 SLAVE MODE CONFIGURATION BAMF5500/1D STRAPPED CONFIGURATION 2-4ohms 1. All of the controls can be adjusted only in "MASTER" mode amplifier. 2. Lowest recommended impedance is 2 Ohm Mono. 3. RCA Inputs are connected to both left and right cnannels. 4.
  • Page 17: Channel

    FIG. 4 2 CHANNEL STEREO CONFIGURATION BAMF 800/2, 1250/2, 1800/2, 2200/2, 2600/2 1.Lowest Recommended Impedance is 2ohm Stereo 2.RCA Inputs are connected to both Left and Right channels 3.Gain controls to be set match input source 4.Line Output configured for stereo operation FIG.
  • Page 18: Channel

    FIG. 6 2CHANNEL TRI MODE CONFIGURATION BAMF 800/2, 1250/2, 1800/2, 2200/2, 2600/2 1.Lowest Recommended Impedance is 4ohm Stereo 2.RCA Inputs are connected to both Left and Right channels 3.Output configured for stereo operation - 16 -...
  • Page 19: Channel

    FIG. 7 4CHANNEL STEREO CONFIGURATION BAMF 1200/4, BAMF 1600/4 1.Lowest Recommended Impedance is 2ohm Stereo 2.RCA Inputs are connected to both Left and Right channels 3.Gain controls to be set match input source 4.Line Output configured for stereo operation - 17 -...
  • Page 20 FIG. 8 4CHANNEL BRIDGED CONFIGURATION BAMF 1200/4, BAMF 1600/4 1.Lowest recommended impedance is 4ohm bridged mono 2.RCA Inputs are connected to both Left &Right channels 3.Line Output configured forstereo operation - 18 -...
  • Page 21: Channel

    FIG. 9 4CHANNEL TRI MODE CONFIGURATION BAMF 1200/4, BAMF 1600/4 WOOFER 4-8 Ohms 4-8 Ohms 1.Lowest Recommended Impedance is 4ohm Stereo 2.RCA Inputs are connected to both Left and Right channels 3.Output configured for stereo operation 4-8 Ohms 4-8 Ohms WOOFER - 19 -...
  • Page 22: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE SYMPTOMS CHECK POINTS Is the power NO SOUND LED illuminated? No power to power wire AMP NOT No power to remote SWITCHING wire with receiver on Fuse broken Check speaker leads NO SOUND Check audio input IN ONE leads CHANNEL Check speaker load...
  • Page 23: Specification

    SPECIFICATIONS MODEL# BAMF800/2 MAXIMUM POWER OUTPUT 800W POWER OUTPUT @4Ohm 150W x 2CH POWER OUTPUT @2Ohm 180W x 2CH BRIDGED POWER 360W x 1CH 0.02% FREQUENCY RESPONSE -1.0dB 10Hz-30kHz 50Hz~500Hz 30Hz~250Hz SUBSONIC FILTER BASS EQ 0dB ~ 12dB ADJUSTABLE SENSITIVITY RANGE 0.2V~6V INPUT IMPEDANCE (LOW LEVEL)
  • Page 24: Warning

    Investigate the layout of your automobile throughly before drilling or cutting any holes. Take care when to work near the gas tanks, lines, or hydraulic lines, and electrical wiring. Don't use power amplifier unmounted. Attach this system securely to the automobile to prevent damage, particularly in the event of an accident.
