Power Acoustik REACT1-1100 Owner's Manual

65-C5009-MA Model No.:
Owner's Manual
SRX-D0504; SRX-D1501; SRX-D2501; SRX-D4001
INTRODUCTION
Amplifiers provide high-performance sound reinforcement for your mobile audio equipment.
It s versatility enables compatibility with optional Equalizers, Frequency Dividing Network
Crossovers, and other audio processors in a customized system. The Multi-Mode bridging
Capabilities allow flexibility in hosting several different speaker configurations.
To achieve optimum performance, it is highly recommended that you read this Owner's
Manual before beginning installation.
FEATURES
PWM Power Supply
3 Stage Protection Circuit
SMD Technology
MIL-Spec Fiberglass Circuit Board
True Digital Switching
High Rail Voltage
2 Ohm Stable
Compact Chassis
Full MOSFET Circuitry
High Level Input
Line Output
Bass Boost @45Hz +6 dB or +12 dB(Sub woofer Amplifier)
18 dB Crossover Centered at 80 Hz(Sub woofer Amplifier)
Selectable HPF/LPF @ 80Hz crossover(Full Rang e Amplifier)
WARNING
High powered audio systems in a vehicle are capable of generating Live Concert high
levels of sound pressure, Continual exposure to excessively high volume sound levels may
cause hearing loss or damage. Also, operation of a motor vehicle while listening to audio
equipments at high volume levels may impair your ability to hear external sounds such as;
horns, warning signals, or emergency vehicles, thus constituting to a potential traffic hazard.
In the interest of safety, Consumer Electronics recommends listening at lower volume levels
While driving.
