If replacement parts are needed for your dryer, contact the source where you purchased your dryer, or call Frigidaire at
1-866-738-1640.
For coin box parts, call 1-800-221-0982, Greenwald Industries.
Destroy the carton and plastic bags after the washer is unpacked. Children might use them for play. Cartons covered
with rugs, bedspreads, or plastic sheets can become airtight chambers causing suffocation. Place all materials in a garbage container
or make materials inaccessible to children.
The instructions in this manual and all other literature included with this washer are not meant to cover every possible
condition and situation that may occur. Good safe practice and caution MUST be applied when installing,operating and maintaining
any appliance.
Maximum benefits and enjoyment are achieved when all the Safety and Operating instructions are understood and practiced
as a routine with your laundering tasks.
ITEM
REQ'D
PART NO
1
2
00-7185
2
1
76-6009-*
3
1
76-1037
4
1
76-5014
5
1
76-2033
6
1
00-8149
7
3
00-7070
8
2
76-5013
9
1
00-8003
10
1
76-1036
11
1
76-5017
12
1
76-2003
13
1
59-204
14
1
76-5012
15
1
76-5010
16
1
00-7055
17
1
00-7047
Parts List for series 7682 "Quick-Change" Start Mechanism
DESCRIPTION
#4-40 SELF-TAPPING SC.
TIMER MOTOR ASS'Y
SWITCH & BRACKET SUB-ASS'Y
DRIVE SELEEVE
SLEEVE
TORSION SPRING
RETAINING RING
DRIVE BUSHING
SPRING
RACTHET ARM & PAWL ASS'Y
RACHET WHEEL
WASHER
SPRING
CAM
ADJUSTER TAB
SPRING WASHER
WASHER
R
EPLACEMENT PARTS
ITEM
REQ'D
18
1
19
2
20
2
21
1
22
1
23
1
24
1
25
1
26
2
27A
1
27B
1
28
1
29
1
30
1
10
10
Item 27A: Models 76-1030-21 (115v-60Hz),
76-1030-22 (230v-60Hz)
Item 27B: Models 76-1030-11 (115v-60Hz),
76-1030-12 (230v-60Hz)
PART NO
DESCRIPTION
76-2026
DRIVE SHAFT
00-7458
#4-40 3/16 PAN HD SC.
00-7097
#4 SPLIT LOCKWASHER
00-6189
SNAP SWITCH
00-6190
SNAP SW. & LEVER ARM ASS'Y
76-5009
SWITCH INSULATOR
76-2035
NUT PLATE
76-6000
WIRE HARNESS ASS'Y
02-0810-00
#8-32x5/16 SEMS SCREW
76-2059
MOUNTING BRACKET
76-2027
MOUNTING BRACKET
59-0314
CABLE TIE
58-172-*
GROUND WIRE
00-7558
WASHER
