Washer-Extractors
Cabinet Hardmount Operating Instructions
CHM166C
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Part No. F232145R7EN
www.comlaundry.com
December 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F232145R7EN and is the answer not in the manual?

Questions and answers

Related Manuals for Alliance Laundry Systems F232145R7EN

Summary of Contents for Alliance Laundry Systems F232145R7EN

  • Page 1 Washer-Extractors Cabinet Hardmount Operating Instructions CHM166C Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. F232145R7EN www.comlaundry.com December 2007...

  • Page 3: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. F232145 (EN) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 4: Safety Information

    7. Before the washer is removed from service or discarded, remove the door to the washing compartment. 8. Do not reach into the washer if the wash drum is moving. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 5 If this occurs, have washer checked by a qualified manufacturer. service person. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 6: Specifications And Dimensions

    (180) (231.6) Perforation size, in. (mm) 0.188 0.188 0.188 0.188 0.188 0.188 (4.76) (4.76) (4.76) (4.76) (4.76) (4.76) Perforation open area, % 17.5 Table 1 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 7 Centrifugal Force Data Wash/reverse centrifugal force, Gs 0.85 0.90 0.75 0.82 0.82 0.825 High extract centrifugal force, Gs 82.1 86.8 78.4 82.3 82.3 86.3 Table 1 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 8 (11.1) (13.6) (15.2) (21.6) (22.4) (28.9) (28.9) Electrical Heating (Optional) Total electrical heating capacity, 15.6 15.6 23.4 23.4 Electrical heating elements Electrical heat element size, kW © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 9: Gap Setting For Vibration Switch

    NOTE: The standard position of the switch is open, or non-tripped. 3. Tighten nuts on switch extension after adjusting the gap. Measure the gap distance to verify accurate setting. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 10: Variable-Speed And Fixed-Speed Models

    (451) (737) Power Consumption Average power used per cycle, kW-hr 0.05 0.07 0.20 0.34 0.37 0.21 0.40 0.60 Average HVAC load, Btu/hr 1200 Table 3 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 11 23.4 31.2 15.6 Electrical heating elements Electrical heat element size, kW * Refer to Gap Setting for Vibration Switch (Variable-Speed and Fixed-Speed Models) section for specifications. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 12 Installation/Operation Supplement For 18, 20, 25, 27, 30 and 35 Pound Capacity Machines CHM1995N CHM1995N Sump Vibration Switch Gap Distance Switch Extension Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 13 Installation/Operation Supplement For 40 and 50 Pound Capacity Variable-Speed and Fixed-Speed Machines CHM2000N Sump Vibration Switch Gap Distance Switch Extension Figure 2 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 14 Installation/Operation Supplement For 60 Pound Capacity Variable-Speed and Fixed-Speed Machines CHM1999N CHM1999N Lower Bracket Balance Bolt Upper Bracket Lock Nut Vibration Switch Gap Distance Figure 3 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 15 Installation/Operation Supplement For 80 Pound Capacity Machines CAB1998N CHM1998N Switch Extension Vibration Switch Gap Distance Figure 4 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 16 Installation/Operation Supplement For 125 Pound Capacity Machines CHM1993N Vibration Switch Switch Extension Gap Distance Figure 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 17: Dimensional Clearances

    (305 mm) (305 mm) (305 mm) (610 mm) (610 mm) *For 80 pound models intended for standard mounting, clearance should be 6 in. (150 mm). Table 4 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 18: Dimensions

    Extra Inlet Valve External Chemical Supply Signal Terminal Strip External Chemical Supply Inlet (OPL only) (OPL only) Vacuum Breaker Cold Water Inlet Drain Outlet Figure 7 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 19 3 in. 3 in. 3 in. 3 in. (76 mm) (76 mm) (76 mm) (76 mm) (76 mm) (76 mm) (76 mm) (76 mm) Table 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 20: 125 Model

    25 mm (1 in.) 1622 mm (63.88 in.) 1791 mm (70.5 in.) 1648 mm (64.88 in.) 1130 mm (44.5 in.) 1692 mm (66.63 in.) Table 6 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 21: Electrical Specifications

    208 – 240 208 – 240 Variable-Speed Models 200 – 240 50/60 NOTE: Wire sizes shown are for copper, THHN, 90° conductor per NEC article 310. Table 8 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 22 200 – 240 50/60 1 or 3 2 or 3 11/11 NOTE: Wire sizes shown are for copper, THHN, 90° conductor per NEC article 310. Table 10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 23 1 or 3 2 or 3 6.3/6.3 2x2.5 3x2.5 NOTE: Wire sizes shown are for copper, THHN, 90° conductor per NEC article 310. *Coin models only. Table 11 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 24 50/60 10.0 380-415 50/60 10.0 200-240 50/60 16.0 200-240 50/60 NOTE: Wire sizes shown are for copper, THHN, 90° conductor per NEC article 310. Table 12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 25 440 – 480 50/60 380 – 415 50/60 200 – 240 50/60 NOTE: Wire sizes shown are for copper, THHN, 90° conductor per NEC article 310. Table 14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 26: Operation

    Reduced Spin Start (∨ ) keypad CHM2003N CHM2003N CHM502N CHM502N Extra Wash Edit Up (∧) keypad CHM2004N CHM503N CHM2004N CHM503N Table 15 (Continued) Table 15 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 27 Cold CHM1985N Hand Wash/Edit Up CHM1986N CHM1986N Gentle Wash/Edit Down Cold CHM1987N CHM1987N Time CHM1988N CHM1988N Start/Enter/ Wash Temperature Display CHM1989N CHM1989N Vend Price/Actuation CHM1990N CHM1990N © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 28: Instructions For Edc Control

    OVERLOAD. Refer to Figure 10. INSERT WASH COIN/CARD PERM NORMAL SPECIAL CLOSE PRESS DELICATE RINSE DOOR WASH SPIN WARM BLEACH COLD B148R Figure 12 U003IE1A Figure 10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 29 C LO B LE R IN Bleach START Softener B155R Figure 15 B155R 11. Cycle is complete when display reads “:00”. Detergent Bleach Softener Figure 14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 30: Instructions For Mechanical Timer

    UNLOCK button on the left side of the control panel while performing the above step. Refer to Figure 17. U005IE1B U005IE1B Figure 19 DOOR UNLOCK U135R U135R Figure 17 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 31 7. For coin models: Insert required number of coins to start machine. Refer to Figure 21. ADD BLEACH WHEN LIT B158R B159R Detergent Bleach Softener Figure 23 B157R B157R Detergent Bleach Softener Figure 21 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 32: Instructions For S, P And V Series Microcomputers

    UNLOCK button on the left side of the control panel while performing the above step. Refer to Figure 25. U005IE1B U005IE1B Figure 27 DOOR UNLOCK U135R U135R Figure 25 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 33 Start key. Detergent Bleach Softener Figure 28 8. For non-coin models: Press the Start key. Refer to Figure 29. CYCLE SELECTION B159R Down Start Stop Figure 29 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 34: Instructions For B Series Microcomputer

    OVERLOAD. Refer to Figure 32. WARM SPIN HEAVY SOIL UNIFORMS ST ART DOOR CLEAN FILTER STAINED DELICATE COLD CHM522N CHM522N U003I Figure 32 CHM1764C Figure 34 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 35 Figure 35 8. If the machine is a coin operated unit, add coins. As each coin is added, the display counts down to the amount remaining. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 36: Instructions For A Series Microcomputer

    U001I U001I Figure 36 3. Load to capacity whenever possible. DO NOT OVERLOAD. Refer to Figure 37. U003I Figure 37 CHM1759C Figure 39 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
  • Page 37 As each coin is added, the display counts down to the amount remaining. 9. If the machine is a card operated unit, insert and remove card per card system instructions. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)

  • Page 38: Disposal Of Unit

    MIX1N purchased. Figure 41 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232145 (EN)
