Installing an Oracle Internet Directory Replica
Table 6–1 (Cont.) Installing an Oracle Internet Directory Replica with a New Database
Screen
3. Specify Port
Configuration Options
4. Select High Availability
or Replication Option
5. Select Oracle Internet
Directory Replication
Mode
Specify Oracle Internet
6.
Directory Master Node
7. Specify Master Oracle
Internet Directory Login
8. Specify Namespace in
Internet Directory
9. OCA screens
6-6 Oracle Application Server Installation Guide
Action
If you want to use default ports for the components, select Automatic.
If you do not want to use the default ports, and you have created a staticports.ini
file, select Manual and enter the fullpath to your staticports.ini file in the provided
field.
Click Next.
This screen is required to install a replica. This screen appears only if you selected
High Availability and Replication in the Select Configuration Options screen.
Select Replication, and click Next.
Select One-way LDAP Replication if you want to use fan-out replication in one
direction.
Select Two-way LDAP Replication if you want to use fan-out replication in both
directions.
Select Advanced Replication if you want multimaster replication.
Click Next.
Hostname: Enter the name of the computer running the master Oracle Internet
Directory.
Port: Enter the port at which the master Oracle Internet Directory is listening.
Do not select Use only SSL connections with this Oracle Internet Directory. If
you want Oracle Internet Directory to run in SSL-only mode, you can make this
configuration change after installation. See the Oracle Application Server
Administrator's Guide for details.
Click Next.
Username: Enter cn=orcladmin because you have to connect to the master
Oracle Internet Directory as the superuser.
Password: Enter the password for the superuser.
Click Next.
Select the suggested namespace, or enter a custom namespace for the location of
the default Oracle Identity Management realm.
Ensure the value shown in Suggested Namespace meets your deployment needs.
If not, enter the desired value in Custom Namespace. See
Enter in the "Specify Namespace in Internet Directory"
Click Next.
If you selected Oracle Application Server Certificate Authority (OCA) in the
Select Configuration Options screen, the installer displays screens for configuring
OCA. See Section 4.30, "Install Fragment: OCA Screens"
Section 4.16, "What Do I
Screen?".
for details.
