BeFore setting surFace controls

locations oF tHe gas surFace
Burners
The SIMMER burner is best used for simmering delicate
sauces, etc. This burner is located at the right rear burner
position.
The STANDARD sized burners are used for most surface
cooking needs. This burner is located at the left rear
positions on the 30" & 36" cooktop (and there is one
more standard burner located at the right front position
on the 36" cooktop models).
The POWER burner is best used for bringing large
quantities of liquid rapidly up to temperature or when
preparing larger quantities of food. Those burners are
located at the right and left front positions on the 30"
cooktop (and there is another power burner located at
the center position on the 36" cooktop).
Figure 1 - 30" Model
(your model may not look exactly like this one)
Figure 2 - 36" Model
(your model may not look exactly like this one)
6
assemBlY oF tHe surFace Burner
Burner caPs and Burner grates
It is very important to make sure that all of the Surface
Burner Caps and Surface Burner Grates are installed
correctly and at the correct locations.
1 Remove all packing material from cooktop area.
2 Discard all packing material (if applicable).
3 Unpack Burner Grates and position on the cooktop
(see Figure 3 or 4).
REMEMBER — do not alloW sPills, Food,
cleaning agents or anY otHer material
to enter tHe gas oriFice Holder oPening.
Always keep the Burner Caps and Burner Heads in place
whenever the surface burners are in use.
Figure 3 - 30" Model
Figure 4 - 36" Model
