8. If "Yes" was selected in step 2, now with the modem power OFF, set the dip switches to the settings
shown below and then click on OK. For a description of "DIP" switch functions, refer to the table below.
9. After modem setup is complete, the screen below appears verifying a successful setup.

MENU OPTIONS

PRINT
The print option allows the system to provide a hard-copy verification of how the system is programmed.
To print, the PC must be connected to a printer via the RS-232 serial printer port (DB9 connector).
Dip Switch
Number
SW1 Override DTR
SW2 Verbal Result Codes
SW3 Suppress Result Codes
SW4 Echo Offline Commands
SW5 Auto Answer on Ring
SW6 Carrier Detect Normal
SW7 Load NVRAM Defaults on Power-up
SW8 Smart Mode
21
Description
