Campbell IRTS-P Instruction Manual

Precision infrared temperature sensor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IRTS-P Precision Infrared

Temperature Sensor

Revision: 9/06
C o p y r i g h t
©
2 0 0 2 - 2 0 0 6
C a m p b e l l
S c i e n t i f i c ,
I n c .
A p o g e e
I n s t r u m e n t s ,
I n c .

Advertisement

Table of Contents
loading

Related Manuals for Campbell IRTS-P

Summary of Contents for Campbell IRTS-P

  • Page 1: Temperature Sensor

    IRTS-P Precision Infrared Temperature Sensor Revision: 9/06 C o p y r i g h t © 2 0 0 2 - 2 0 0 6 C a m p b e l l S c i e n t i f i c , I n c .
  • Page 2 Warranty and Assistance The IRTS-P PRECISION INFRARED TEMPERATURE SENSOR is warranted by CAMPBELL SCIENTIFIC, INC. to be free from defects in materials and workmanship under normal use and service for twelve (12) months from date of shipment unless specified otherwise. Batteries have no warranty.

  • Page 3: Table Of Contents

    Adobe Acrobat® bookmarks tab for links to specific sections. 1. General Description.............1 2. Specifications ..............1 3. Installation..............2 4. Wiring................3 5. Example Programs ............3 6. Maintenance ...............11 Figures 3-1. IRTS-P on UT018 Crossarm ..............2 3-2. Mounting IRTS-P to UT018 Crossarm ...........2 Tables 5-1. Wiring for Example Programs ..............4...
  • Page 4 This is a blank page.

  • Page 5: General Description

    The IRTS-P is an infrared temperature sensor calibrated to output the signal for the target temperature with the same output voltage as if a Type K thermocouple were sensing the target temperature.

  • Page 6: Installation

    The IRTS-P can be mounted to a Campbell Scientific tripod or tower with the UT018 Crossarm (Figure 3-1.) A mounting kit (Stainless steel bolt, 2 washers, and 2 nuts PN 14475) is included with the IRTS-P that can be used to attach the sensor to the crossarm (Figure 3-2.) FIGURE 3-1.

  • Page 7: Wiring

    IRTS-P Precision Infrared Temperature Sensor 4. Wiring The IRTS-P has two thermocouple outputs. Each output is a pair of red and yellow wires. The pair labeled “Target” on the jacket near the wires is the output from the detector. The pair labeled “Body” is a thermocouple measuring the temperature of the sensor body.

  • Page 8: Wiring For Example Programs

    IRTS-P Precision Infrared Temperature Sensor ⋅ ⋅ 9092 59237 00558 ⋅ − ⋅ 2828 4248 00077 − ⋅ ⋅ 0705 3816 Sensor Body Temperature The three example programs measure the sensor once a second and output average sensor and target temperatures once an hour. In an actual installation the measurement and output intervals, and channels used may be changed to accommodate the other measurements and outputs.
  • Page 9 IRTS-P Precision Infrared Temperature Sensor 2: Thermocouple Temp (DIFF) (P14) 1: 1 Reps 2: 21 2.5 mV 60 Hz Rejection Range 3: 2 DIFF Channel 4: 3 Type K (Chromel-Alumel) 5: 1 Ref Temp (Deg. C) Loc [ RefTemp ]...
  • Page 10 IRTS-P Precision Infrared Temperature Sensor ;Calculate correction factor (SEC) 7: Z=1/X (P42) ; {1/Psb} 1: 4 X Loc [ Psb 2: 4 Z Loc [ Psb 8: Z=X*F (P37) ; {.25/Psb} 1: 4 X Loc [ Psb 2: 0.25 3: 4 Z Loc [ Psb 9: Z=X-Y (P35) ;...
  • Page 11 IRTS-P Precision Infrared Temperature Sensor *Table 2 Program 02: 0.0000 Execution Interval (seconds) *Table 3 Subroutines End Program -Input Locations- 1 RefTemp 1 2 1 2 AppTargT 1 2 1 3 SenBodyT 1 3 1 4 Psb 1 3 3...
  • Page 12 IRTS-P Precision Infrared Temperature Sensor ;Calculate P, H, & K Coefficients 4: Polynomial (P55) 1: 1 Reps 2: 3 X Loc [ SenBodyT ] 3: 4 F(X) Loc [ Psb 4: 49.9092 5: 0.59237 6: 0.00558 7: 0.0 8: 0.0 9: 0.0...
  • Page 13 IRTS-P Precision Infrared Temperature Sensor 11: Z=X-Y (P35) ; {subtract Ksb} 1: 5 X Loc [ Hsb 2: 6 Y Loc [ Ksb 3: 6 Z Loc [ Ksb 12: Z=X*Y (P36) ; {calculate SEC} 1: 4 X Loc [ Psb...
  • Page 14 Average(1,ATT_C,IEEE4,0) Average(1,CTT_C,IEEE4,0) EndTable BeginProg Scan(1,Sec,1,0) 'Wiring Panel Temperature measurement PTemp_C: PanelTemp(PTemp_C,_60Hz) 'IRTS-P Precision Infrared Temperature Sensor measurements ATT_C and CTT_C: 'Measure apparent target temperature with IRTS-P. TCDiff(ATT_C,1,mV2_5C,1,TypeK,PTemp_C,True,0,_60Hz,1,0) 'Measure IRTS-P sensor body temperature. TCDiff(SB,1,mV2_5C,2,TypeK,PTemp_C,True,0,_60Hz,1,0) 'Calculate Psb, Hsb, & Ksb coefficients. Psb=49.9092+(0.59237*SB)-(0.00558*SB^2) Hsb=4.2828+(0.4248*SB)-(0.00077*SB^2)

  • Page 15: Maintenance

    IRTS-P Precision Infrared Temperature Sensor CR5000 Example Program Public RefT, TargetCorrT, TC(2), SensorCorr, Psb, Hsb, Ksb Alias TC(1) = TargetApparentT Alias TC(2) = SensorBodyT DataTable (AllDat,1,-1) DataInterval (0,60,Min,10) Average (1,RefT,FP2,0) Average (2,TC(),IEEE4,0) Average (1,TargetCorrT,IEEE4,0) EndTable BeginProg Scan (1,Sec,3,0) PanelTemp (RefT,250) TCDiff (TC(),2,mV20C ,1,TypeK,RefT,True ,0,_60Hz,1.0,0)
  • Page 16 IRTS-P Precision Infrared Temperature Sensor This is a blank page.
  • Page 17 This is a blank page.
