The Frigidaire side burner is designed to be installed as a built-in side burner, in conjunction with
a Frigidaire & Frigidaire Gallery grills. If installed as a built-in Grill, the Grill surround must be
constructed of Non-combustible material.

PLANNING AND DESIGN

Start by identifying the number and size of components you want to include in your outdoor cooking
center. Countertops must be constructed of non-combustible, outdoor-safe materials. Consider out-
door lighting to illuminate after-dark grilling. For assistance in designing and building your outdoor
cooking center, contact a landscape architect or general contractor. Review the drawings on the following
pages to determine the exact dimensions and items needed for an outdoor cooking center. Keep in mind
that the gas line hook-up is on the right hand side of the main built in-grill. The structure, grill and support
items must be kept level throughout the installation to ensure proper operation.
LOCATION
Take into account convenience and visual impact as well as traffic flow, wind exposure, and the
site's structural suitability. The grill should never be placed in an enclosed area without an approved
ventilation system, or beneath a combustible overhang. Because the grill exhausts to the rear, it
should never be located in front of a window or less than 12" from hard-to-clean surfaces. We rec-
ommend keeping your gas supply lines as short as possible for best performance. To ensure a per-
fect fit, we strongly recommend that you have all components on hand prior to final construction.

CLEARANCE TO NON-COMBUSTIBLE CONSTRUCTION

For your safety a minimum of 3" clearance from the back of the grill to non-combustible construction
is required. You should allow at least 6" side clearance to non-combustible construction. The side
vents on this unit can be covered for built in installations without danger of fire or without impairing
the operation of the grill.
UTILITIES
For natural gas grills, consult your local gas utility company for hook-up requirements. All gas connections
should be made by a certified technician or a gas supply company. For natural gas installation, the supply
line must be at least 1/2" diameter. The rotisserie requires a 110/120 volt electric supply and GFI
receptacle. (6.5 amp min.) that should be installed by a qualified electrical technician. If your plan
includes a sink, arrange for a certified plumbing technician to run a water line to the site.

Built-In Instructions
