A Series
ASW 650, ASW 250
subwoofers
español
Subwoofers Boston
A Series
Manual del Propietario /
Instrucciones de Seguridad /
Información de Cumplimiento
français
Caissons de graves Boston A
Series / Guide de l'utilisateur
/ Instructions de sécurité /
Informations relatives à la
conformité
Italiano
Subwoofers
Manuale dell'utente /
Istruzioni di sicurezza /
Informazioni sulla conformità
svenska
Subwoofrar / Bruksanvisning
/ Säkerhetsanvisningar /
Information om
överensstämmelse
Deutsch
Subwoofers
/ Sicherheitshinweise /
Konformitätserklärung

Advertisement

Table of Contents
loading

Summary of Contents for Boston Acoustics ASW 650

  • Page 1 A Series ASW 650, ASW 250 subwoofers español Italiano Deutsch Subwoofers Boston Subwoofers Subwoofers A Series Manuale dell’utente / / Sicherheitshinweise / Manual del Propietario / Istruzioni di sicurezza / Konformitätserklärung Instrucciones de Seguridad / Informazioni sulla conformità Información de Cumplimiento français...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNINg! To reduce the risk of fire or electrical shock, This symbol found on the apparatus indicates hazards arising from dangerous voltages. do not expose this apparatus to rain or moisture. This symbol found on the apparatus indicates the user should read all safety statements found in the user This symbol found on the apparatus indicates that manual.
  • Page 3: Specifications

    Boston A Series Subwoofers Thank you for choosing Boston Acoustics. The A Series subwoofers incorporate high-quality components that produce the legendary Boston Sound. The subwoofers are ideally suited for use in a high-quality 5.1 channel home theater or stereo music system.
  • Page 4: Unpacking The System

    Keep the shipping carton and packing materials for future use. Be sure to keep your purchase receipt in a safe place, as it may be required for warranty purposes. ASW 650 and ASW 250 subwoofers Placement Options Place the subwoofer next to a wall or in a corner near your main speakers. The sound is typically best when the subwoofer is within 15 feet (4.5m) of the main speakers.
  • Page 5 Connections After your speakers are properly placed, you are ready to wire your system. NOTE: Power is always supplied to the subwoofer electronics unless it is unplugged or switched to the Mute position using the Audio On switch located on the rear panel. The auto-on circuitry only activates or deactivates the power amplifier. Make sure your subwoofer and receiver are unplugged when making the connection (All models include a main power switch which turns off all power to the subwoofer).
  • Page 6: Operation

    Connecting to Electronics Without a Subwoofer Output If the receiver in your system does not have a subwoofer or LFE output you can connect the subwoofer to a preamp output. Use a stereo RCA cable (not included) to connect the preamp outputs to the “L” and “R” Line Level inputs. Adjusting the Crossover Control When using the Line Level inputs (not the LFE input) the subwoofer’s built-in crossover is engaged.
  • Page 7: Maintenance And Service

    Limited Warranty Boston Acoustics warrants to the original purchaser of an A Series subwoofer that it will be free of defects in materials and workmanship in its mechanical parts for a period of 5 years from the date of purchase. The warranty period for the electrical components is 1 year.
  • Page 8 INSTRUCCIONES DE SEgURIDAD IMPORTANTES ñ ¡ADVERTENCIA! Para reducir el riesgo de incendio o Este símbolo que se encuentra en el aparato indica peligros derivados de niveles de energía peligrosos. descarga eléctrica, no exponga este aparato a la lluvia o la humedad. Este símbolo que se encuentra en el aparato indica que el usuario debería leer todas las declaraciones de Este símbolo que se encuentra en el aparato indica que...
  • Page 9: Especificaciones

    Subwoofers Boston Acoustics Serie A Gracias por escoger Boston Acoustics. Los subwoofers Serie A incorporan componentes de alta calidad que producen el legendario sonido de Boston. Los subwoofers son ideales para el uso en un sistema musical estéreo o home theater de 5.1 canales de alta calidad.
  • Page 10: Desembalaje Del Sistema

    / o servicio de entrega. Conserve la caja de cartón del envío y los materiales de embalaje para uso futuro. Asegúrese de conservar su recibo de compra en un lugar seguro, dado que puede necesitarlo para hacer uso de la garantía. Subwoofers ASW 650, y ASW 250 Opciones de colocación Ponga el subwoofer al lado de una pared o en una esquina cerca de sus altavoces principales.
  • Page 11 Conexiones Tras colocar sus altavoces de la forma adecuada, estará listos para disponer el cableado de su sistema. NOTA: alimentación al sistema electrónico del subwoofer a no ser que esté desenchufado o desconectado en la posición “Mute” utilizando el interruptor Audio encendido de alimentación situado en el panel trasero. Los circuitos de activación automática sólo activan o desactivan el amplificador de potencia.
  • Page 12: Control De Volumen

    Conexión al sistema electrónico sin una salida de subwoofer Si el sistema electrónico en su sistema no tiene una salida de subwoofer o LFE (BF), puede conectar las subwoofer CPS a una salida de pre-amplificador. Utilice un cable RCA estéreo (no incluido) para conectar las salidas de pre-amplificador a las entradas line level “L”...
  • Page 13: Mantenimiento Y Servicio

    Garantía Limitada Boston Acoustics garantiza al comprador original de nuestros altavoces de la A Series que éstos no cuentan con defectos en los materiales y ofrece una garantía de mano de obra por sus piezas mecánicas por un periodo de 5 años a partir de la fecha de compra.
  • Page 14 ç INSTRUCTIONS IMPORTANTES RELATIVES À LA SÉCURITÉ ATTENTION ! Afin de réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil à la Ce symbole rencontré sur l’appareil indique les risques pluie ou à l’humidité. résultant des tensions dangereuses. Ce symbole rencontré...
  • Page 15: Spécifications

    Caissons de graves Boston Acoustics de série A Merci d’avoir choisi Boston Acoustics. Les caissons de graves de la série A incorporent des composants de haute qualité qui produisent le célèbre son (Légendaire) de Boston. Ces caissons de graves sont idéaux pour une utilisation dans le cadre d’un système de Home cinéma de haute qualité...
  • Page 16 Veillez à conserver soigneusement votre ticket d’achat dans un endroit sûr, car il pourrait vous être demandé dans le cadre de la garantie. Caissons de graves ASW 650 et ASW 250 avec pieds escamotables Options de positionnement Placez le caisson de graves à...
  • Page 17 Connexions Une fois que vos haut-parleurs sont correctement positionnés, vous êtes prêt à connecter votre système. REMARQUE : L’électronique du caisson de graves est toujours alimentée en courant électrique à moins que celui-ci ne soit débranché ou que l’interrupteur situé sur le panneau arrière ne soit en position d’arrêt (Mute). Le circuit ‘auto-on’ a pour seule fonction d’activer ou de désactiver l’amplificateur de puissance.
  • Page 18: Contrôle Du Volume

    Connexion à l’électronique sans sortie de caisson de graves Si l’électronique de votre système n’est pas équipée d’une sortie de caisson de graves ou LFE, vous pouvez connecter les unités de caisson de graves CPS Wi à une sortie pre-amp. Utilisez un câble RCA stéréo (non fourni) pour connecter les sorties pré-amp aux entrées de niveau de ligne (Line Level) de gauche (L) et de droite (R).
  • Page 19: Entretien Et Service

    Bostonacoustics.com pour une liste des distributeurs dans votre région. Garantie limitée Boston Acoustics garantit à l’acheteur d’origine que ses haut-parleurs de la série A ne comportent aucun défaut de pièce et de main d’œuvre pendant une période de 5 ans à partir de la date d’achat.
  • Page 20 IMPORTANTI ISTRUZIONI DI SICUREZZA AVVERTENZA! Per ridurre il rischio di incendio o di Questo simbolo riportato sull’apparecchio indica pericoli derivanti da voltaggi pericolosi. scossa elettrica, non esporre l’apparecchio alla pioggia o all’umidità. Questo simbolo riportato sull’apparecchio indica l’obbligo da parte dell’utente di leggere tutte le istruzi- Questo simbolo riportato sull’apparecchio indica che oni di sicurezza illustrate nel manuale per l’uso.
  • Page 21 Subwoofer A Series di Boston Acoustics Grazie per aver scelto Boston Acoustics. I subwoofer A Series incorporano componenti di alta qualità che producono il leggendario suono Boston. I subwoofer sono l’ideale per l’uso in una soluzione canale 5.1 in un impianto home theater o stereo musicale di alta qualità.
  • Page 22: Disimballaggio Del Sistema

    Conservare la ricevuta d’acquisto in un luogo sicuro in quanto può essere richiesta ai fini della garanzia.. ASW 650 E ASW 250 subwoofer Opzioni di collocazione Collocare il subwoofer vicino a un muro o in un angolo in prossimità degli altoparlanti principali. Solitamente, il suono è...
  • Page 23 Connessioni Dopo aver debitamente collocato gli altoparlanti, è possibile cablare l’impianto. NOTA BENE: i dispositivi elettronici del subwoofer sono sempre alimentati, a meno che questo non sia scollegato dalla presa di rete o impostato su Mute tramite l’interruttore Audio On situato a livello del pannello posteriore. La circuiteria di at- tivazione automatica attiva o disattiva unicamente l’amplificatore di alimentazione.
  • Page 24: Funzionamento

    Connessione ad elettronica priva di un’uscita subwoofer Se il ricevitore in vostro possesso non è dotato di un’uscita subwoofer o LFE, è possibile collegare il CPS Wi subwoofer ad un’uscita preamp. Servirsi di un cavo stereo RCA (non in dotazione) per collegare le uscite preamp agli ingressi a livello di linea “L”...
  • Page 25: Garanzia Limitata

    Boston Acoustics. Questa garanzia è limitata al prodotto Boston Acoustics e non copre i danni di alcun dispositivo associato. Questa garanzia non copre i costi di rimozione o reinstallazione. Questa garanzia non è valida in mancanza del numero di serie del dispositivo.
  • Page 26 VIKTIg SÄKERHETSINFORMATION Symbolen som återfinns på apparaten indikerar att fara VARNINg! För attminska risken för eldsvåda eller kan uppstå på grund av farlig spänning. elektriska stötar, ska denna apparat inte utsättas för regn eller fukt. Symbolen som återfinns på apparaten indikerar att användaren bör läsa alla säkerhetsmeddelanden som Denna symbol som återfinns på...
  • Page 27 Inledning Subwoofrar i Boston Acoustics A-serie Tack för att du valde Boston Acoustics. A-seriens subwoofrar, har komponenter av hög kvalitet som ger det legendariska Boston-ljudet. Subwoofrarna är perfekt lämpade att använda i en 5,1-kanals hemmabio eller ett stereomusiksystem av hög kvalitet.
  • Page 28: Packa Upp Systemet

    Behåll kartongen och förpackningsmaterialet för framtida användning. Se till att du sparar inköpskvittot på ett säkert ställe, det kan behövas för orsaker relaterade till garantin. ASW 650 och ASW 250 subwoofrars Placeringsalternativ Placera subwoofern intill en vägg eller i ett hörn i närheten av huvudhögtalarna. Ljudet är normalt bäst när subwoofern befinner sig 4,5 m (15 fot) från huvudhögtalarna.
  • Page 29 Anslutningar När högtalarna är på plats kan du ansluta systemet. OBS: Strömmen går alltid till subwoofern såvida den inte är frånkopplad eller ändras till läget Mute med Audio On strömbry- tarens Audio On, som finns på den bakre panelen. Auto-on-kretsen aktiverar eller avaktiverar endast strömförstärkaren. Se till att subwoofern och receivern är frånkopplade när du gör anslutningen (230v-modeller har en huvudströmbrytare som slår ifrån all ström till subwoofern).
  • Page 30 Ansluta till elektroniken utan subwooferutgång Om elektroniken i ditt system inte har en subwoofer- eller LFE-utgång kan du ansluta CPS Wi-subwoofer till en förförstärka- rutgång. Använd en stereo-RCA-kabel (ingår ej) för att koppla förförstärkarutgångarna till ingångarna “L” och ”R” Line Level- ingångarna.
  • Page 31: Underhåll Och Service

    över återförsäljare i ditt område. Begränsad garanti Boston Acoustics garanterar förste köparen av en subwoofer ur A-serien, att den är fri från defekter vad beträffar material och utförande under en period av 5 år från inköpsdatumet. Garantiperioden för de elektriska komponenterna är 1 år.
  • Page 32 WICHTIgE SICHERHEITSANWEISUNgEN WARNUNg! Um die Gefahr von Brand oder Dieses am Gerät angebrachte Symbol weist auf die Gefahren durch Stromspannung hin. Elektroschock zu reduzieren, halten Sie dieses Gerät von Regen und Feuchtigkeit fern. Dieses am Gerät angebrachte Symbol weist den Benutzer darauf hin, alle Sicherheitsanweisungen in Dieses am Gerät angebrachte Symbol weist darauf diesem Handbuch genau durchzulesen.
  • Page 33: Spezifikationen

    Einführung Subwoofer der A-Serie von Boston Acoustics Vielen Dank, dass Sie Boston Acoustics gewählt haben. Die Subwoofer der A-Serie umfassen qualitativ hochwertige Komponenten, die den legendären Boston-Sound liefern. Die Subwoofer eignen sich perfekt für den Einsatz in einem 5.1-Kanal Qualitätsheimkino oder -musiksystem. Sie verfügen über ein erstaunlich kompaktes Gehäuse und produzieren beeindruckend tiefe Bässe und einen hohen Output.
  • Page 34: Auspacken Des Systems

    Wiederverwendung auf. Achten Sie darauf, die Rechnung an einem sicheren Ort aufzubewahren, da Sie sie eventuell für Garantiezwecke später benötigen. ASW 650 und ASW 250 Subwoofer Aufstellungsoptionen Stellen Sie den Subwoofer neben eine Wand oder in eine Ecke in der Nähe Ihrer Hauptlautsprecher. Der Klang ist für gewöhnlich dann am besten, wenn der Subwoofer sich innerhalb eines 15-Feet (4,5 m)-Radius um die Hauptlautsprecher befindet.
  • Page 35 Anschlüsse Nachdem Ihre Lautsprecher ordentlich platziert worden sind, können Sie Ihr System nun verkabeln. HINWEIS: Die Elektronik des Subwoofers wird immer mit Strom versorgt, wenn er nicht ausgesteckt ist oder der Audio-On/ Ein-Schalter an der Rückseite auf Mute/Stumm gestellt ist. Die Auto-On/Ein-Schaltung aktiviert und deaktiviert lediglich den Leistungsverstärker.
  • Page 36: Betrieb

    Anschluss an ein elektronisches gerät ohne Subwoofer-Ausgang Wenn der Receiver in Ihrem System keinen Subwoofer- oder LFE-Ausgang hat, können Sie den CSP Wi Subwoofer an einen Preamp-Ausgang anschließen. Verwenden Sie ein Stereo-RCA-Kabel (nicht im Lieferumfang enthalten), um die Preamp- Ausgänge an die Line-Level-Eingängen anzuschließen, die mit den Buchstaben “L” und “R” markiert sind. Receiver Einstellung des Crossover-Reglers Wenn Sie die Line-Level-Eingänge (nicht den LFE-Eingang) verwenden, wird der im Subwoofer eingebaute...
  • Page 37: Wartung Und Kundendienst

    Ihrer Nähe finden. Eingeschränkte Garantie Boston Acoustics garantiert dem Erstkäufer eines Subwoofers der A-Serie für einen Zeitraum von 5 Jahren ab Kaufdatum, dass dessen mechanische Teile frei sind von Materialfehlern und Verarbeitungsmängeln. Die Garantiedauer für die elektrischen Komponenten beträgt 1 Jahr.
  • Page 40 300 Jubilee Drive, Peabody, MA 01960 USA www.bostonacoustics.com © 2010. All rights reserved. Boston, Boston Acoustics, the B/A ellipse symbol, Play Smart, BassTrac, and Deep Channel are registered trademarks of Boston Acoustics, Inc. Specifications are subject to change without notice. 142-003930-1...
