OPERATING MANUAL

MODE D'EMPLOI
MANUAL DE FUNCIONAMIENTO

AIR CONDITIONER

CASSETTE TYPE
KEEP THIS MANUAL FOR FUTURE REFERENCE
CONSERVEZ CE MODE D'EMPLOI AFIN DE POUVOIR VOUS Y RÉFÉRER ULTÉRIEUREMENT
GUARDE ESTE MANUAL PARA PODERLO CONSULTAR EN EL FUTURO
P/N9368987060-01
9368987060-01_OM_cover1.p65
1
2/4/10, 4:44 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P/N9368987060-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Friedrich P/N9368987060-01

Summary of Contents for Friedrich P/N9368987060-01

  • Page 1: Operating Manual

    MODE D’EMPLOI MANUAL DE FUNCIONAMIENTO AIR CONDITIONER CASSETTE TYPE KEEP THIS MANUAL FOR FUTURE REFERENCE CONSERVEZ CE MODE D'EMPLOI AFIN DE POUVOIR VOUS Y RÉFÉRER ULTÉRIEUREMENT GUARDE ESTE MANUAL PARA PODERLO CONSULTAR EN EL FUTURO P/N9368987060-01 9368987060-01_OM_cover1.p65 2/4/10, 4:44 PM...

  • Page 2: Table Of Contents

    G When moving, consult authorized service personnel for disconnection and installation of the unit. G Do not become over-exposed to cold air by staying in the direct path of the air flow of the air conditioner for extended periods of time.

  • Page 3: Name Of Parts

    NAME OF PARTS Remote controller 1 Start/Stop Button 2 Set Temperature Button 3 Master Control Button 4 Fan Control Button 5 THERMO SENSOR Button 6 ENERGY SAVE Button 7 Timer Mode (CLOCK ADJUST) Button 8 DAY (DAY OFF) Button 9 SET BACK Button 0 Set Time Button A DELETE Button B SET Button...

  • Page 4: Preparatory Operation

    Monday, 10:00 A.M. Press the start/stop button. Operation lamp Air conditioner ON: Lit brightly Air conditioner OFF: Not lit Press the master control button to set the operation mode. If DRY is selected, the fan speed will be set to AUTO.
  • Page 5 If any button is pressed during the part lock, the 9368987060-01_OM_en.p65 Press the ENERGY SAVE button to start or stop the energy-sav- ing air conditioner operation. For details on the function, refer to page 9. display flashes. Indoor unit...

  • Page 6: Timer Functions

    TIMER FUNCTIONS OFF timer (See page 5.) Use this timer function to stop air conditioner operation. The timer operates and air conditioner operation stops after the set time has passed. The timer can be set up to 24 hours in advance.

  • Page 7: Weekly Timer

    WEEKLY TIMER Weekly timer setting CLOCK ADJUST Press the timer mode button to select the weekly timer. G Day of the week setting DAY OFF Press the DAY button to select the day of the week, and then press the SET button to confirm the setting.
  • Page 8 WEEKLY TIMER WEEKLY timer operation G To start CLOCK ADJUST When the weekly timer is selected, the timer starts automatically. NOTES (1) PRECAUTIONS DURING WEEKLY TIMER SETUP Setup is not possible in the following cases, so amend the time. • Be sure to set the ON time first, then the OFF time. If either the ON time or the OFF time is not set correctly, the timer will not operate properly.

  • Page 9: Temperature Set Back Timer

    NOTES (1) The SET BACK timer only changes the set temperature, it cannot be used to start or stop air conditioner operation. (2) The SET BACK timer can be set to operate up to two times per day but only one temperature setting can be used.

  • Page 10: Operating Tips

    • If you turn off the air conditioner while in the conservation mode, the mode will be shut off. • The temperature set on the remote controller will not change if the energy save mode is used.
  • Page 11 Multi-type Air conditioner This indoor unit can be connected to a multi-type outdoor unit. The multi-type air conditioner allows multiple indoor units to be operated in multiple locations. The indoor units may be operated simultaneously, in accordance with their respective output.

  • Page 12: Adjusting The Direction Of Air Circulation

    Downward airflow 4 During Heating mode: • During AUTO mode, the airflow direction will be set to horizontal airflow 1 for the first minute of air conditioner opera- tion. The airflow direction cannot be changed during this time. • Always use the remote controller vertical airflow direction and swing button to adjust the vertical airflow direction louvers.

  • Page 13: Care And Maintenance

    CARE AND MAINTENANCE G Before cleaning the unit, be sure to stop the unit and power supply. (Turn off the electrical breaker) G A fan operates at high speed inside the unit, and personal injury could result. Cleaning the air filter Push the intake grille pushbuttons (two places) and open the intake grille.

  • Page 14: Self-Diagnosis

    When the error indication “E:EE” is displayed, inspection of the air conditioning system is necessary. Please consult author- ized service personnel. Stop the air conditioner operation. Press the set temperature buttons simultaneously for 5 seconds or more to stop the self-diagnosis.

  • Page 15: Troubleshooting

    G During operation and immediately after stopping the unit, the sound of water flowing in the air conditioner’s piping may be heard. Also, noise may be particularly noticeable for about 2 to 3 minutes after starting operation (sound of coolant flowing).
  • Page 16 G Has a fuse blown out, or a circuit breaker been tripped? G Is the timer operating? G Is the air filter dirty? G Are the air conditioner’s intake grille or outlet port blocked? G Did you adjust the room temperature settings (thermostat) cor- rectly?
  • Page 17 9368987060-01_OM_es.p65 2/4/10, 4:48 PM...
  • Page 18 Friedrich Air Conditioning Co. 4200 N. Pan Am San Antonio, Texas 78218 USA Tel. (210) 357-4400 Fax (210) 357-4490 Visit us at www. friedrich. com 9368987060-01_OM_es.p65 2/4/10, 4:48 PM...
