  • Page 1 Installation & Operation Manual Portable Air Conditioner Model P-09 Rev 6-07...
  • Page 2: Table Of Contents

    Foreword Table of Contents Thank you for purchasing the new Friedrich ZoneAire Portable ® Introduction................2 Air Conditioner. We are confi dent that you will fi nd this unit a quiet and effi cient example of Friedrich reliability. Unit Identifi cation ..............3 Operation of Remote Control ...........5...
  • Page 3 Unit Identification and Function Front Back Condensate Pump Hose connection...
  • Page 4 Unit Identification and Function Control Panel SWING Button Choose either TIMER Button auto-swing or Set the time fixed direction for switch-on, TEMP Buttons FAN SPEED Button mode switch-off or to Adjust Choose high, medium MODE Button clear the timer temperature or low fan speed Press this button up or down...
  • Page 5 Remote Control Identification and Function This button is used to set the room temperature. Each pressing of the "+" or "-" button increases or decreases the temperature by 1°. Press this button to choose high, medium or low-speed of air delivery Pressing this button will select among cool, dry or fan modes.
  • Page 6: Control Panel Unit Operation

    LCDI power cord information In order to improve the cooling effi ciency: All Friedrich portable air conditioners are shipped from the a) If your room is directly exposed to the sun, draw the cur- factory with a Leakage Current Detection Interrupter (LCDI) tains.
  • Page 7: Maintenance/Service

    Condensation Handling Draining Water Your ZoneAire Portable Air Conditioner is designed to evapo- The water can be drained from the unit either by removing the ® rate the condensation removed from the interior space through base stopper and letting the water drain by gravity. Or the con- the exhaust hose.
  • Page 8: Preparation For Storage

    Maintenance /Service Cleaning the air conditioner Preparation for storage 1. Turn off the air conditioner, disconnect the power. Clean the surface of the unit with a damp cloth, then dry using a duster or similar. 2. Perform proper maintenance to the air fi lter and other parts. CAUTION 3.
  • Page 9: Installation

    Troubleshooting Failure code Diagnosis of Malfunction Room Temperature sensor failure Self diagnosis function Coils sensor failure The following error codes are pre-programmed into each unit to Unit malfunction help identify possible unit conditions. Water level exceeded capacity Installation Selection of installation location Instructions to install hose Put the portable air conditioner in a fl...
  • Page 10: Window Kit Installation

    Instructions to install hose cont'd Window kit installation Your window kit has been designed to fi t most standard “verti- If the air exhaust requires bending, see below: cal” and “horizontal” window applications. However, it may be necessary for you to improvise/modify some aspects of the in- stallation procedures for certain types of windows.
  • Page 11: Accessories

    Water drainage hose installation Fit the drainage hose to the drainage hole in the back of the unit. Installation accessories Flexible exhaust hose with adapters... 2/set Stretches from 19 ½" (50cm) up to 78 ¾" (200 cm) overall Window exhaust adapter (fl at mouth )..1pc Adjustable window slider kit......
  • Page 12 FIRST YEAR ANY PART: If any part supplied by FRIEDRICH fails because of a defect in workmanship or material within twelve months from date of original purchase, FRIEDRICH will repair the product at no charge, provided the product is transported to a Friedrich Authorized Service Center for repair.
