Layer 3
Egress Layer 3 enables you to map CoS to ToS so that the priority marking of outgoing
packets can be carried over to the IP network.
Layer 3
Field
Description
Interface
Select the WAN interface to configure the QoS for outgoing packets; LAN interface
cannot be selected as VLAN is currently supported on the WAN side only.
Default Non-IP
Locally generated packets (such as ARP packets) do not have a CoS marking. You can
define the CoS for all unclassified outgoing packets on layer 3 using this field. The
selections are in the order of descending priority): CoS1, CoS2, CoS3, CoS4, CoS5, and
CoS6. The default value is CoS1 (recommended).
Class of Service
The selections are (in the order of descending priority): CoS1, CoS2, CoS3, CoS4, CoS5,
and CoS6.
Translated TOS
The Type of Service field takes values from 1 to 255. The selections are 0, 1, 2, 3, 4,
5, 6, and 7.
User Manual
Page 59 of 93
