LAN Group Configuration

LAN Group Configuration allows you to configure settings for each LAN group. Notice that
you can also view the status of advanced services that can be applied to a LAN group.
Green indicates that the service is enabled, while red indicates that the service is
disabled.
LAN Group Configuration
Category
Unmanaged
Obtain an IP address
automatically
PPP IP Address
Use the following Static IP
Page 38 of 93
Field Description
Unmanaged is a state when the LAN group is not
configured and no IP address has been assigned to the
bridge.
When this function is enabled, your router acts like a
client and requests an IP address from the DHCP server
on the LAN side.
IP Address You can retrieve/renew an IP address from the DHCP
server using the Release and Renew buttons.
Netmask The subnet mask of your router.
Enables/disables PPP unnumbered feature.
IP Address The IP address should be different but within the same
subnet as the WAN-side IP address.
This field enables you to change the IP address of the
