Discovery Dialog Area

The area at the right of the Subnets Table is where all dialog boxes open.
This area can be resized by dragging the vertical splitter bar with the
mouse. When a dialog box opens, it replaces the current dialog box open
in the Dialog Area. When no dialog box is open, the Dialog Area
disappears and the Subnets Table expands to take its place.

Discovery Log Area

The area under the Subnets Table is where the Discovery Log opens. This
area can be resized by dragging the horizontal splitter bar with the
mouse. When the Discovery Log is closed, the Log Area disappears and
the Subnets Table expands to take its place.

Discovery Status Bar

The Discovery Status Bar provides information about the current
Discovery including:

Closing the Discovery Window

To close the Discovery window, select
closes.
Avaya Network Management Console User Guide
• Current Discovery Phase - The phase of the current Discovery.
Possible phases are:
— Ready - There is no Discovery in progress.
— Discovering Devices - Discovery is searching for subnets
and routers.
• Devices - The total number of devices found in the current
Discovery.
• Entries in the Log - If there are entries in the Discovery Log, the
letter ' L ' appears in the Status Bar. For information on viewing
the Discovery Log, refer to
• Changes Found - If Discovery found subnets and/or nodes that
are not in the current Network File, the letter ' D ' appears in the
Status Bar.
Introduction to the Discovery Window
"Using the Discovery Log" on page
File > Exit . The Discovery window
82.
