ATEN CS231 Specification

CS231
Computer Sharing Device (USB)
The CS-231 is a powerful, micro-processor controlled computer sharing device. It is a multi-user, single-tasking device
that enables two users to share the use of a single computer - each from their own consoles (monitor, keyboard, and
mouse). The CS-231 supports USB consoles and both PS/2 and USB computers.
Diagram
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Features
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
• Single computer shared by two USB consoles
• Supports USB and PS/2 computers
• Multiplatform Support (Windows, Mac, Unix and Linux)
• Manual or Auto console selection
• Control the system with Hotkeys
• Firmware upgradable
• Private Mode for a privileged user
• Screen Saver function
• Choose from four Timeout settings
• Supports VGA, SVGA, and MultiSync monitors
• No software required
Headquarters
ATEN International CO., Ltd.
3F, No.125, Sec. 2, Datung Rd. Sijhih City, Taipei 221, Taiwan
Tel: 886-2-8692-6789
© Copyright 2006 ATEN® International Co., Ltd. All brand names and trademarks are the registered property of their respective owners.

Rear View

Specifi cations
Function
Computer Connections
Console Connections
Console Selection
Connectors
Switches
LEDs
Video
Timeout Settings
Power Consumption
Environment
Physical
Properties
* The specifi cations and pictures are subject to change without notice.
Fax: 886-2-8692-6767 E-mail : online@aten.com.tw
- - - - - - - - - - - - - - - - - - - - - - - - - -
CS-231
1
2
Pushbutton, Hotkey
Keyboard 2 x USB Type A Female (White)
Console Ports Video 2 x HDB-15 Female (Blue)
Mouse 2 x USB Type A Female (White)
Computer Port 1 x SPHD-15/18 Female (Green)
F/W Upgrade 1 x RJ-11 Female (Black)
Power 1 x DC Jack (Black)
Mode Selection 1 x Pushbutton
Reset 1 x Semi-recessed Pushbutton
DIP 1 x 4 pin
Mode 1 (Orange)
Selected 2 (Green)
1920x1440@60Hz, DDC2B
5, 60, 125, 255 Seconds
DC5.3V, 2.2 W (Max.)
Operating Temp. 0-50˚C
Storage Temp. -20-60˚C
Humidity 0-80% RH, Non-condensing
Housing Metal
Weight 0.56 kg
Dimensions (L x W x H) 14.30 x 8.70 x 5.50 cm
2006. Version 1.0
