ATEN UH-152 Installation Manual

Features:
Super-Compact Slim Shape - Can Be Stored in the PCMCIA/PC-Card Slot* - Extra
Convenient for Mobile Users
Connecting Cable Tucks Away Into Its Own Compartment
Provides 2 additional USB Ports to existing USB Systems
Supports USB Spec. 1.1 - Data Transfer Rate of Up to 12 Mbps
Supports All USB Devices
Easy Installation - Plug and Play for Windows 95 OSR2.1 / 98 / 2000 / ME; and Mac OS 8.1 /
8.6 / 9.0
Installation:
1. Make sure that the device you are connecting to is powered off
2. Flip open the UH-152's cable compartment cover and pull out the USB connecting cable
3. Plug the UH-152's USB cable into the device's USB Port
4. Power on the device. Under Windows, the hub will automatically be detected. If the
necessary USB drivers haven't been installed already, Windows will install them.
5. Plug your USB peripherals into any available UH-152 port.
*
Make sure that the square end is facing in and the storage compartment end (with the tabs) is
facing out when inserting the hub into the slot.
Uh-152
2001-04-20
