Chapter 5 Test - ATCOM AX-4G Product Manual

1. Please check the status of the cell phone card plugged in the ax4g.
Please type the following command three times, the result of the third time is correct:
cat /proc/dahdi/ax4g_sta_card_1
You can get one line with the following information:
S0:4, S1:4, S2:4, S3:2
The S0, S1, S2, S3 stand for the four modules on the ax4g orderly, and different numbers
behind colon stand for different status of cell phone card.
a: it means that the cell phone card is sending SMS.
1: it means that the module2 is powered off.
2: it means that the cell phone card is still searching for GSM network.
3: it means that the cell phone card has registered successfully before, but now it failed.
4: it means that the cell phone card has found GSM network successfully, and it is in idle
status (not used by calling or sending SMS).
5: it means that after a communication, one side hangs up the phone, but the other side has not
hang up.
6: it means that the cell phone card is dialing-out.
7: it means that somebody from outside is calling the channel, but no extension answers the
phone, the extension is ringing.
8: it means that an extension answers an incoming call, but the communication has not yet
established, at this moment, the called party hangs up, then the caller do not need to be paid
for this call, because this call has not been established really.
9: it means that the channel is in communication status, and the call has been established
really.
2. Please check the network signal of the cell phone card plugged in the ax4g, type the following
command three times, the result of the third time is correct:
cat /proc/dahdi/GSM_signal_card_1
you can get one line with the following information:
SQ0 = 31, SQ1 = 30, SQ2 = 18, SQ3 = 28
The SQ0, SQ1, SQ2, SQ3 stand for the four modules on the ax4g orderly, and different
numbers behind equality sign stand for the network signal of the cell phone card, the numbers
0 and 99 mean no signal, for other numbers, the bigger the number is, the stronger the signal
is.
3. Check when the called party answers the call, when you dial-out through AX-4G.
Please use dmesg command to detect if the called party answers the call when you dail-out
through AX-4G, if the called party has answered the call, after running dmesg command, you
can get one line with
customer to do billing accurately.
www.atcom.cn

Chapter 5 Test

GX PR, X stands for the channel number. This feature will help
12
