ATCOM AX4G Quick Start Manual

With elastix2.4.0
Hide thumbs Also See for AX4G:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
AX4G Quick Start Guide
with Elastix2.4.0
Version: 2.0
2013-07-12

Advertisement

Table of Contents
loading

Related Manuals for ATCOM AX4G

Summary of Contents for ATCOM AX4G

  • Page 1 AX4G Quick Start Guide with Elastix2.4.0 Version: 2.0 2013-07-12...
  • Page 2 AX4G Quick Start Guide Release note Version Changed note Editor Date First Release Release the Quick start Guide Deniel 2013-07-12 www.atcom.cn Email: support@atcomemail.com...

  • Page 3: Table Of Contents

    AX4G Quick Start Guide Content 1． Install ax2g4a/ax4g driver ......................1 1) Download the driver from ATCOM download center ............1 2) Load the files via the U-flash ....................1 3) Install the driver ........................1 4) Compatibility with the driver ....................2 2．...

  • Page 4: Contact Atcom

    Contact ATCOM The Introduction of ATCOM ATCOM is the leading VoIP hardware manufacturer in global market. We have been keeping innovating with customer’s needs oriented , working with partners to establish a total solution for SMB VoIP with IP phone , IP PBX and Asterisk cards.
  • Page 5 AX4G Quick Start Guide Test Environment Elastix2.4.0 OS Asterisk-1.8.20 Dahdi-linux-complete-2.6.2+2.6.2 www.atcom.cn Email: support@atcomemail.com...

  • Page 6: Install Ax2G4A/Ax4G Driver

    AX4G Quick Start Guide 1．Install ax2g4a/ax4g driver Download the driver from ATCOM download center Notice: Users should download the latest drivers for the GSM card from ATCOM download center: http://www.atcom.cn/download.html For example, users can get the driver with the command. wget http://www.atcom.cn/cn/download/cards/ax4g/ax2g4a_ax4g_elastix2.4.0.tar.gz...

  • Page 7: Compatibility With The Driver

    Compatibility with the driver When users install the driver correctly, it will be compatible with all the atcom asterisk cards. It means users need not install drivers for other atcom cards. For examples:...

  • Page 8: How To Configure Your Pbx

    AX4G Quick Start Guide 2．How to configure your PBX 2.1. Log into the Elastix webpage Please open the browser and input the server IP address, And then clink on the submit button as the following illustration. 2.2.Detect the hardware Users can click the “Hardware Detection” button to detect the hardware by the system automatically.

  • Page 9: Configurate Your Pbx

    AX4G Quick Start Guide For example, if users have install the drivers for AX4G card firstly, users will get the following illustration. 2.3. Configurate your PBX 2.3.1 Configure the PBX Click the PBX button to jump into the pbx configuration page.
  • Page 10 AX4G Quick Start Guide Then , Click the “Apply Configuration Changes Here” bar in the top of the screen. www.atcom.cn Email: support@atcomemail.com...

  • Page 11: Add A Zap/Dahdi Trunk

    AX4G Quick Start Guide 2.3.3 Add a ZAP/DAHDI Trunk a) Choose the “Add Zap Trunk (DAHDI compatibility) ”button. b) Set the Trunk Description: enter the name what you have set. Then choose the Dial Rules Identifier：g0. click on submit in the following illustration.

  • Page 12: Add An Incoming Route

    AX4G Quick Start Guide 2.3.4 Add an Incoming Route Add an incoming route, it will help you get incoming calls. a) Click on “Inbound Routes” bar. b) Input incom9 in the textbox of Description as the following screen: c) Click the Extensions textbox, choose an extension number from the drop down selection box.
  • Page 13 AX4G Quick Start Guide b) Input out_route9 in the textbox of Description as the following screen: c) In the Dial Patterns , please input “9|.” , it will help you get calls before you called number. Please refer to the following illustration: d) Choose the Trunk Sequence: ZAP/g0 ,Then click submit.

  • Page 14: Appendix: The Parameter For Billing

    AX4G Quick Start Guide 3．Appendix: the parameter for billing 1．Two kinds of configuration for the billing. 1) If users need the GSM modules for billing, but the FXO needn't, please edit the configuration files like the following: a. Make sure the parameters is disabled in the “/etc/asterisk/chan_dahdi.conf” file.
  • Page 15 AX4G Quick Start Guide 2) If users need the GSM and FXO billing simultaneously, please edit the billing parameters like the following. [root@centos6 ~]# vi /etc/asterisk/chan_dahdi.conf answeronpolarityswitch=yes polarityonanswerdelay= 300 Notice: If user need the FXO module billing, please apply for your SP(Server Provider) who will enable the billing signal to FXO module.
