RedBoot 0xA8000000 0xA8000000 0x00030000 0x00000000
rootfs 0xA8030000 0xA8030000 0x006F0000 0x00000000
vmlinux.bin.l7 0xA8720000 0x80041000 0x000B0000 0x80041000
FIS directory 0xA87D0000 0xA87D0000 0x0000F000 0x00000000
RedBoot config 0xA87DF000 0xA87DF000 0x00001000 0x00000000
The fix is to flash the system via Redboot with the correct layout and follow the
instructions here:
http://wiki.villagetelco.org/index.php?title=Mesh_Potato_HOWTOs#Reflash_t
he_firmware_from_RedBoot.

5. Appendix

5.1

Appendix A - MP01 Features

Feature
Integrated WiFi and ATA
in a single box
Mesh, Client or AP mode
WiFi
One-IP configuration
Web GUI or Phone UI
UV-resistant,
weather-proof enclosure
Built in mounting points
Rugged design
Power supply
Power efficient
Power over Ethernet
(PoE) and Power over
Benefit
Low power consumption, ease of setup, fewer
cables, fewer points of failure, and low cost.
Can be a component in Mesh WiFi networks or
connect to existing WiFi networks
Set one IP and the device is ready to make a
receive phone calls. Quickly build voice and IP
networks and roll out a Wireless PBX in minutes.
Configure via a web interface or telephone IVR
menu. With Phone UI no laptop is required for
on-site installation.
Long life outdoors, no need to purchase a separate
enclosure for outdoor use.
Simple and low cost outdoor installation.
Withstands abuse that would destroy other
products such as power surges, brownouts,
reverse DC, over-voltage DC, and static electricity.
Runs on 24VDC voltage, or any AC voltage from
110 to 250VAC via wall-plug type power supply. A
solar panel can be directly connected – saving
money on a solar regulator.
Consumes just 3W (DC). Can run on a 10W solar
panel.
Just one cable run for both power and telephone.
PoE and PoTL injectors included.
39
