Configure Mp01 By Web Gui; How To Access The Web-Based Utility - ATCOM MP01 Administrator's Manual

ln -s /etc/init.d/udhcpd /etc/rc.d/S99udhcpd
ln -s /etc/init.d/batmand /etc/rc.d/S90batmand
ln -s /etc/init.d/create-batman-status-page.sh
/etc/rc.d/S99create-batman-status-page.sh
echo "meshclientgw" > /etc/app-profile
echo "Done. Rebooting now."
reboot
2) Make this script executable.
chmod +x meshclientgw.sh
3) Run the script.
/bin/meshclientgw.sh
4) The MP01 will reboot after running the script. Connect your computer to
MP01 through Ethernet port and set computer to DHCP. After the computer
obtains a IP address from MP01, it should be able to access the Internet
through MP01.

3. Configure MP01 by Web GUI

This section describes each web page of the utility and each page‟s key
functions. You can access the utility via web browser on a computer connected
to the MP01.The web-based utility has these main tabs: Overview, Status,
System, Services and Network. Additional tabs will be available after you click
one of the main tabs.
3.1

How to access the Web-Based Utility

To access the web-based utility, launch the web browser on your computer, and
enter the MP01‟s default IP address 192.168.1.20 in the Address field. Then,
press Enter. You will see a login screen as below. Leave the Password field blank.
(You can set a new password from the System => Admin Password screen.)
Click Login to continue.
Login screen
12
