AX2G4A Quick Start Guide
with Elastix2.4.0
Version: 2.0
2013-06-03

Advertisement

Table of Contents
loading

Related Manuals for ATCOM AX2G4A

Summary of Contents for ATCOM AX2G4A

  • Page 1 AX2G4A Quick Start Guide with Elastix2.4.0 Version: 2.0 2013-06-03...
  • Page 2 AX2G4A Quick Start Guide Release note Version Changed note Editor Date First Release Release the Quick start Guide Daniel 2013-06-03 www.atcom.cn Email: support@atcomemail.com...

  • Page 3: Table Of Contents

    AX2G4A Quick Start Guide Content 1． INSTALL AX2G4A/AX4G DRIVER..................... 1 Install the driver with Elastix2.4.0....................1 1) Download the driver........................1 2) Install the driver..........................1 3) Compatibility with the driver......................1 2． HOW TO CONFIGURE YOUR PBX.................... 2 2.1. Log into the Elastix webpage......................2 2.2.

  • Page 4: Contact Atcom

    Contact ATCOM The Introduction of ATCOM ATCOM is the leading VoIP hardware manufacturer in global market. We have been keeping innovating with customer’s needs oriented , working with partners to establish a total solution for SMB VoIP with IP phone , IP PBX and Asterisk cards.

  • Page 5: Install Ax2G4A/Ax4G Driver

    [root@localhost src]# cd ax2g4a_elastix2.4.0 [root@localhost elastix_ax2g4a_driver]# ./ax4g_install.sh Compatibility with the driver When users install the driver correctly, it will be compatible with all the atcom asterisk cards. It means users need not install drivers for other atcom cards. For examples: Card named...

  • Page 6: How To Configure Your Pbx

    AX2G4A Quick Start Guide 2．How to configure your PBX The Trixbox2.8.0.4 configuration webpage is the same as the Elastix2.0.3 configure webpage. So the following instruction will be an example to Elastix OS. 2.1. Log into the Elastix webpage Please open the browser and input the server IP address, And then clink on the submit button as the following illustration.

  • Page 7: Configurate Your Pbx

    AX2G4A Quick Start Guide For example, if users have install the drivers for AX4G card firstly, users will get the following illustration. 2.3. Configurate your PBX 1) Configure the PBX Click the PBX button to jump into the pbx configuration page.
  • Page 8 AX2G4A Quick Start Guide Then , Click the “Apply Configuration Changes Here” bar in the top of the screen. www.atcom.cn Email: support@atcomemail.com...

  • Page 9: Add Azap/Dahdi Trunk

    AX2G4A Quick Start Guide 3) Add a ZAP/DAHDI Trunk a) Choose the “Add Zap Trunk (DAHDI compatibility) ”button. b) Set the Trunk Description: enter the name what you have set. Then choose the Dial Rules Identifier：g0. click on submit in the following illustration.

  • Page 10: Add An Incoming Route

    AX2G4A Quick Start Guide 4) Add an Incoming Route Add an incoming route, it will help you get incoming calls. a) Click on “Inbound Routes” bar. b) Input incom9 in the textbox of Description as the following screen: c) Click the Extensions textbox, choose an extension number from the drop down selection box.
  • Page 11 AX2G4A Quick Start Guide b) Input out_route9 in the textbox of Description as the following screen: c) In the Dial Patterns , please input 9|. , it will help you get calls before you called number. Please refer to the following illustration: d) Choose the Trunk Sequence: ZAP/g0 ,Then click submit.
