Summary of Contents for Patton electronics Access Server

Page 1 Access Server Administrator’s Reference Guide Sales Ofﬁce: +1 (301) 975-1000 Technical Support: +1 (301) 975-1007 E-mail: support@patton.com WWW: www.patton.com Document Number: 107001U Rev. B Part Number: O7MDAS-ARG-B Revised: March 12, 2001...
Page 2 Patton Electronics Company, Inc. 7622 Rickenbacker Drive Gaithersburg, MD 20879 USA Voice: +1 (301) 975-1000 Fax: +1 (301) 869-9293 Technical Support: +1 (301) 975-1007 Technical Support e-mail: support@patton.com WWW: www.patton.com Copyright © 2000, 2001, Patton Electronics Company. All rights reserved. The information in this document is subject to change without notice.
Page 3: Table Of Contents
Contents About this guide ..............................25 Audience................................25 Structure................................25 Typographical conventions used in this document....................26 General conventions ............................26 Mouse conventions ............................27 1 Introduction ..............................29 Introduction ................................30 Logging into the HTTP/HTML Administration Pages ..................30 HTTP/HTML and SNMP Object Format ......................30 Saving HTTP/HTML Object Changes .........................31 2 Home................................
Page 4 Contents Access Server Administrators’ Reference Guide Generate Alarm ............................44 Clear Alarm ...............................44 Modify Response—Configuring the alarm response system...................45 Minor Alarm Syslog Priority (minSyslogPriority) ....................45 Major Alarm Syslog Priority (majorSyslogPriority) ..................45 Minor Alarm Trap IP (minorTrapIp) ......................45 Major Alarm Trap IP (majorTrapIp) ......................45 Modify Alarms—Configuring alarm severity levels ....................46...
Page 5 Access Server Administrators’ Reference Guide Contents Service (suService) ............................55 Service IP (suServiceIP) ...........................57 Service Port (suServicePort) ..........................57 Filter ID (suFilterId) ............................57 6 DAX ................................59 Introduction ................................60 Configuring the DAX............................60 Circuit Type (daxClockMode) ........................60 Main Reference (daxClockMainRef) .......................61 Fallback Reference (daxClockFallbackRef) ......................61 Clock Status (daxClockFailure) ........................62...
Page 6 Contents Access Server Administrators’ Reference Guide Secondary WINS (diSecondaryWINS) ......................74 Modify Attempts .............................75 Failure Banner (diFailureBanner) ......................75 Login Attempts Allowed (diAllowAttempts) ....................75 Modify Configuration .............................75 Link Compression (diLinkCompression) ....................76 Default Max Receive Unit (diConfigInitialMRU) ..................76 Allow Magic Number Negotiation (diConfigMagicNumber) ..............76 Frame Check Sequence Size (diConfigFcsSize) ..................76...
Page 7 Access Server Administrators’ Reference Guide Contents IP Address (diactIP) ..........................83 Port # on Remote Machine (diactPort) .....................83 Session ................................83 Start time of call (diactSessionStartTime) ....................83 Time Call Is/Was Active (diactSessionTime) .....................83 Minutes Until Timeout (diactRemainingIdle) ...................83 Time Left In Session (diactRemainingSession) ..................83 Termination Reason (diactTerminateReason) ...................84...
Page 8 Contents Access Server Administrators’ Reference Guide Bad Packets (diactErrorFrames) .........................92 Physical Layer ..............................92 Connection Modulation (diactModulation) ....................92 Transmit Connection Speed (diactSpeed) ....................93 Receive Connection Speed (diactSpeed) ....................93 Error Correction (diactErrorCorrection) ....................93 Data Compression Protocol (diactCompression) ..................93 Modulation Symbol Rate (diactSymbolRate) ....................93 Locally Initiated Renegotiates (diactLocalRenegotiates) ................93...
Page 9 Access Server Administrators’ Reference Guide Contents V21 (doModemV21Enable) ........................103 Maximum Speed (doModemMaxSpeed) ....................104 Minimum Speed (doModemMinSpeed) ....................104 Guard Tone (doModemGuardTone) ......................104 Carrier Loss Duration (doModemCarrierLossDuration) .................104 Retrain (doModemRetrain) ........................104 Tx Level (doModemTxLevel) ........................104 Protocol (doModemProtocol) .........................104 Compression (doModemCompression) ....................105 Restrict Modification (doModemRestrictMods) ..................105 Dial Out User Statistics window..........................105...
Page 10 Contents Access Server Administrators’ Reference Guide Originating Channel (dractChannel) ......................113 Passed to Link (dractPassLinkIndex) ......................113 Passed to Channel (dractPassChannel) ......................113 Number Dialed (dractNumberDialed) ......................113 Calling Number (dractCallingPhone) ......................113 Session Time (dractSessionTime) ........................113 Remaining Time (dractRemainingSession) ....................113 State (dractState) ............................113 10 Digital Signal Processing (DSP)........................115 Introduction ................................117...
Page 11 Access Server Administrators’ Reference Guide Contents Non-7E Termination (dspNon7ETermination) ..................122 Bad Termination Bits (dspBadTerminationBits) ..................122 System Counts ..............................123 Page Requests(dspPageRequests) ......................123 Spurious Rx Interrupt (dspSpuriousRxInterrupt) ..................123 Spurious Tx Interrupt (dspSpuriousTxInterrupt) ..................123 Command Timeout (dspCommandTimeout) ..................123 Status Buffer Out Of Sync (dspStatusBufferOutOfSynch) ..............123 Command Extended Wait (dspCommandExtendedWait) ..............123...
Page 12 Contents Access Server Administrators’ Reference Guide Destination Mask (filterIpDestinationMask) ....................132 Source Port (FilterIpSourcePort) ........................132 Action (filterIpSourcePortCmp) ........................132 Destination Port (filterIpDestinationPort) ....................133 Action (filterIpDestinationPortCmp) ......................133 Protocol (filterIpProtocol) ..........................133 TCP Established (filterIpTcpEstablished) .....................133 Default for dialin (filterIpDefaultDialin) ......................133 13 Frame Relay..............................135 Introduction ................................137...
Page 13 Access Server Administrators’ Reference Guide Contents DLCI (frCircuitDlci) ............................144 Interface # (FrameIPInterfaceNum) ......................144 State (frCircuitState) .............................144 Committed Burst (bits) (frCircuitCommitedBurst) ..................145 Excess Burst (bits) (frCircuitExcessBurst) ......................145 Throughput (bits) (frCircuitThroughput) .....................145 IP Address (FrameIPAddr) ..........................145 Congestion (frameEnableCongestion) ......................145 Adding DLCIs ..............................145 Configuring IP routing with a Frame Relay Link....................145...
Page 14 Contents Access Server Administrators’ Reference Guide Admin Stat (ifAdminStatus) ..........................157 Operational Status (ifOperStatus) .........................157 Last Change (ifLastChange) ..........................157 Received Octets (ifInOctets) .........................157 Received Unicast Packets (ifUcastPkts) ......................157 Received Non-Unicast Packets (ifNUcastPkts) ....................157 Received and Discarded w/No Errs (ifInDiscards) ..................158 Received Errored Packets (ifInErrors) ......................158 Received w/Unknown Protocol (ifInUnknownProtos) ..................158...
Page 15 Access Server Administrators’ Reference Guide Contents Entry Interface Index (ipAdEntIfIndex) ....................165 Entry Subnet Mask (ipAdEntNetMask) ....................165 Entry Broadcast Address (ipAdEntBcastAddr) ..................165 Entry Reassembly Maximum Size (ipAdEntReasmMaxSize) ..............165 Routing Information ............................166 Destination (ipRouteDest) ..........................166 Mask (ipRouteMask) ............................167 Gateway (RouteGateway) ..........................167 Cost (RouteCost) ............................167 Interface (ipRouteIfIndex) ..........................167...
Page 16 Contents Access Server Administrators’ Reference Guide Back Acknowledge (lineSigBackAck) .......................176 Back Answer (lineSigBackAnswer) ......................176 Minimum Transition Time (lineSigMinTransTime) ................176 Minimum Detection Time (lineSigMinDetectTime) ................176 Protocol Timeout (lineSigProtoTimeout) ....................176 Interregister Signalling............................176 Called Number ............................176 Total Digits (interRegCalledNumDig) ....................176 First and Middle Response Code (interRegCalledNumFirst)............. 176 Last Response Code (interRegCalledNumLast) .................
Page 17 Access Server Administrators’ Reference Guide Contents Authentication Key (rip2IfConfAuthKey) .....................188 Send (rip2IfConfSend) ..........................188 Receive (rip2IfConfReceive) .........................188 Metric (rip2IfConfDefaultMetric) ........................188 Status (rip2IfConfStatus) ..........................189 RIP Version 2 (Statistics).............................189 Subnet IP Address (rip2IfStatAddress) ......................189 Bad Packets (rip2IfStatRcvBadPackets) ......................189 Bad Routes (rip2IfStatRcvBadRoutes) ......................189 Sent Updates (rip2IfStatSentUpdates) ......................189 Status (rip2IfStatStatus) ..........................189...
Page 18 Contents Access Server Administrators’ Reference Guide Authentication Failure Traps (snmpEnableAuthenTraps) ................195 20 System ................................. 197 Introduction ................................199 System main window............................199 CPU ................................200 Percentage CPU Idle (boxidletime) ......................200 Time Slices Fully Utilized (boxCPUcritical) ....................200 Time Slices 90% Utilized (boxCPUWarning) ..................200 SNMP and HTTP ............................200 Version (boxSnmpVersion) ........................200...
Page 19 Access Server Administrators’ Reference Guide Contents Physical Location (sysLocation) .......................204 System Services (sysServices) ........................204 Web Settings (boxBackgroundFlag) ......................204 Monitor Privilege (boxMonitorPrivilege) ....................204 System—Modify window ............................205 SNMP and HTTP ............................205 Version (boxSnmpVersion) ........................205 Super User Password (boxSnmpMasterPassword) ..................206 User Password (boxSnmpMonitorPassword) ...................206 LAN IP .................................206...
Page 20 Contents Access Server Administrators’ Reference Guide Maintenance ..............................214 Maintain Flash Storage (syslogFlashClear) ....................214 System Log—Volatile Memory..........................215 Time (slTick) ..............................215 Message (slMessage) ............................215 System Log—Non-Volatile Memory ........................216 Time (slfTick) ...............................216 Message (slfMessage) .............................216 22 T1/E1 Link..............................217 Introduction ................................220 T1/E1 Link Activity main window ........................221 Link (dsx1LineIndex) ............................221...
Page 21 Access Server Administrators’ Reference Guide Contents Force Yellow Alarm (linkYellowForce) ....................231 Loopback Config (dsx1LoopbackConfig) ....................231 Send Code (dsx1SendCode) ........................232 Error Injection (linkInjectError) ......................232 Line Status—Channel Assignment ........................232 1 through 30(slotIndex) ..........................232 (slotFunction) ...............................232 Near End Line Statistics—Current ........................233 Errored Seconds (dsx1CurrentESs) .......................233 Severely Errored Seconds (dsx1CurrentSESs) ....................233...
Page 22 Contents Access Server Administrators’ Reference Guide Severely Errored Seconds (dsx1FarEnd CurrentSESs) ...................238 Severely Errored Frame Seconds (dsx1FarEndCurrentSEFSs) ...............238 Unavailable Seconds (dsx1FarEndCurrentUASs) ..................238 Controlled Slip Seconds (dsx1FarEndCurrentCSSs) ..................238 Line Errored Seconds (dsx1FarEndCurrentLESs) ..................238 Path Code Violations (dsx1FarEndCurrentPCVs) ..................239 Bursty Errored Seconds (dsx1FarEndCurrentBESs) ..................239 Degraded Minutes (dsx1FarEndCurrentDMs) ....................239...
Page 23 Access Server Administrators’ Reference Guide Contents Total Sent (tcpOutSegs) ..........................245 Total Retransmitted (tcpRetransSegs) ......................245 Total Received in Error (tcpInErrs) .......................245 Total Sent w/RST Flag (tcpOutRsts) ......................245 TCP (Details)..............................246 Local Port (tcpConnLocalPort) ........................246 Remote Address (tcpConnRemAddress) .......................246 Remote Port (tcpConnRemPort) ........................246 State (tcpConnState) .............................246...
Page 24 Contents Access Server Administrators’ Reference Guide...
Page 25: About This Guide
About this guide This guide describes conﬁguring a Patton Electronics access server. This section describes the following: • Who should use this guide (see “Audience”) • How this document is organized (see “Structure”) • Typographical conventions and terms used in this guide (see “Typographical conventions used in this docu- ment”...
Page 26: Typographical Conventions Used In This Document
Model 2960 RAS Getting Started Guide About this guide • Chapter 17 describes conﬁguring the MFR Version 2 window • Chapter 18 describes conﬁguring the RIP Version 2 window • Chapter 19 describes conﬁguring the SNMP window • Chapter 20 describes conﬁguring the System window •...
Page 27: Mouse Conventions
Model 2960 RAS Getting Started Guide About this guide Mouse conventions The following conventions are used when describing mouse actions: Table 2. Mouse conventions Convention Meaning Left mouse button This button refers to the primary or leftmost mouse button (unless you have changed the default conﬁguration).
Page 28 Model 2960 RAS Getting Started Guide About this guide...
Page 29: Introduction
Chapter 1 Introduction Chapter contents Introduction ................................30 Logging into the HTTP/HTML Administration Pages ..................30 HTTP/HTML and SNMP Object Format ......................30 Saving HTTP/HTML Object Changes .........................31...
Page 30: Introduction
HTTP/HTML pages, you must ﬁrst deﬁne the LAN Address Technique, LAN IP Address, and LAN Subnet Mask for the access server. If you have not done so, please refer to the Getting Started Guide that came with your access server.
Page 31: Saving Http/Html Object Changes
Access Server Administrators’ Reference Guide 1 • Introduction Saving HTTP/HTML Object Changes Sometimes you will need to save changes that you have made in the HTTP/HTML pages. Do the following to make changes to read/write variables: Modify 1. Select the appropriate screen.
Page 32 Access Server Administrators’ Reference Guide 1 • Introduction Saving HTTP/HTML Object Changes...
Page 33: Home
Chapter 2 Home Chapter contents Introduction ................................34 Operating Status Variables ............................35 Active Calls (diActive) .............................35 Peak Active Calls (diMaxActive) ........................35 Percentage CPU Idle (boxIdleTime) .......................35 DSPs Not Working (dspFailed) ........................35 Total DRAM Detected (boxDetectedMemory) ....................35 Running Since Last Boot (sysUpTime) ......................35 Immediate Actions ..............................36...
Page 34: Introduction
Conﬁguration Menu pane (see ﬁgure 3). The contains the links to the various access server subsystems, while the conﬁguration/information pane is where you can view status and other information, or make changes to the system conﬁguration. Unlike the Conﬁguration Menu pane, which looks the same no matter which sub- system page you may move to, the conﬁguration/information pane contents will change as you move from one...
Page 35: Operating Status Variables
A DSP may be taken out of service if it fails to respond to the access server CPU. If a DSP isn’t available when a call comes in, the call will simply ring and not be answered.
Page 36: Immediate Actions
Access Server Administrators’ Reference Guide 2 • Home Immediate Actions There are several immediate actions (see ﬁgure 5) which, when in superuser mode, will cause the access server to operate according to the descriptions in the following sections. Figure 5. Immediate Actions buttons •...
Page 37: Import/Export
Chapter 3 Import/Export Chapter contents Introduction ................................38 Export Configuration ............................38 Import Configuration............................40...
Page 38: Introduction
3 • Import/Export Introduction The Import/Export function enables you to make a backup (or export) copy of your access server’s conﬁgura- tion parameters. By exporting the conﬁgurations, the saved ﬁles can quickly be loaded, or imported, into a replacment access server—greatly speeding up the installation process should an access server need replacing.
Page 39 Export Flash Import/Export To export the ﬂash conﬁguration, click on the link on the main page. The access server will display text conﬁguration information resembling that shown in ﬁgure 7. Figure 7. Typical access server ﬂash memory conﬁguration data Export Configuration...
Page 40: Import Configuration
Figure 8. Saving the access server ﬂash memory conﬁguration data as a text ﬁle Import Conﬁguration To import a conﬁguration ﬁle into the access server, type the complete path and ﬁlename for the conﬁguration ﬁle you wish to load or click on the button to select the desired ﬁle, then click on the...
Page 41: Alarms
Chapter 4 Alarms Chapter contents Introduction ................................42 Displaying the Alarms window ..........................42 Alarm Response Outputs ..........................43 Minor Alarm Syslog Priority (minSyslogPriority) ..................44 Major Alarm Syslog Priority (majorSyslogPriority) ..................44 Minor Alarm Trap IP (minorTrapIp) ......................44 Major Alarm Trap IP (majorTrapIp) ......................44 Clear All Alarms ............................44 Alarms ................................44 Alarm ID ..............................44...
Page 42: Introduction
The alarm system can be set to notify if equipment fails (for example, a power supply failure) or if a T1/E1/PRI port malfunctions. There are 11 access server items that can be conﬁgured by the user to generate alerts based on the condition of the access server.
Page 43: Alarm Response Outputs
45) • Modify Alarms—Clicking on this link takes you to a window where you can change how the access server perceives the severity of each alarm (“Modify Alarms—Conﬁguring alarm severity levels” on page 46) Alarm Response Outputs Alarm Response Outputs display the current settings for handling alarm notiﬁcation via SYSLOG/SNMP...
Page 44: Minor Alarm Syslog Priority (Minsyslogpriority)
Alarm Name The alarm items are grouped into two categories: system and WAN trunk alarms. The system group category lists access server temperature and power supply status. The WAN category monitors the T1/E1/PRI ports for yellow and red alarms. Alarm Time Alarm Time column displays the number of seconds the alarm has been activated.
Page 45: Modify Response-Configuring The Alarm Response System
The alarm response outputs only effect external notiﬁcation via SYSLOG/SNMP as the front panel ALARM LED and the web administration pages will always indicate an alarm condition. The following user conﬁgura- tion items can be set to permit external notiﬁcation of access server alarm conditions: Figure 11. Alarm Response System window...
Page 46: Modify Alarms-Configuring Alarm Severity Levels
Access Server Administrators’ Reference Guide 4 • Alarms Modify Alarms—Conﬁguring alarm severity levels The Modify Alarms window (see ﬁgure 12) is where you can set the severity level each alarm condition gener- ates and whether it can be a self-clearing condition.
Page 47 Access Server Administrators’ Reference Guide 4 • Alarms Note For maximum ﬂexibility, deﬁning what constitues a major or minor alarm is left up the administrator. Some examples of typical major and minor include: • Box Over-temperature—Major Alarm • Power Supply Failure—Minor Alarm •...
Page 48 Access Server Administrators’ Reference Guide 4 • Alarms Modify Alarms—Configuring alarm severity levels...
Page 49: Authentication
Chapter 5 Authentication Chapter contents Introduction ................................50 Displaying the Authentication window........................50 The Statistics section .............................51 Validated authentications (auAuthenticationsValidTotal) ................51 Validated via primary server (auAuthenticationsValidPrimary) ...............51 Validated via secondary server (auAuthenticationsValidSecondary) ..............51 Validated via static database (auAuthenticationsValidStatic) ................51 Denied authentications (auAuthenticationsDenied) ..................51 Primary server retries (auPrimaryServerRetrys) ....................51 Secondary server retries (auSecondaryServerRetrys) ..................51 Accounting server retries (auAccountingServerRetrys) ..................51...
Page 50: Introduction
This section describes the authentication parameters. The access server uses static and/or RADIUS authentication to decide which dial-in users can access the system (refer to Appendix A, “Supported RADIUS Attributes”...
Page 51: The Statistics Section
The total number of authentication attempts requested but denied since the last access server reset. Primary server retries (auPrimaryServerRetrys) The number of times the access server needed to make subsequent requests for a call to the primary RADIUS authentication server.
Page 52: Last Response Time
Validation (auValidation) Selects how the access server will authenticate an incoming call. Select from: • No Validation(0)—Select this to allow un-authenticated calls into the access server, and on to your LAN, using the default service. • static Users(1)—Use the access server internal user database only to authenticate. Static users are simply users and passwords entered into the access server’s internal users database.
Page 53: Host Address (Auhostaddress)
(RADIUS). It is used to encrypt an authentication request and to decrypt an incoming reply from the server. The secret on the access server and the RADIUS server must match and must be 15 or fewer print- able, non space, ASCII characters.
Page 54: Nas Identifier (Aunasidentifier)
Accounting Port (auAcctPort) This is the UDP port on the accounting server speciﬁed in Acct Address that the access server should use to transfer accounting information. RFC 2139 calls out the port of 1813 as the standard RADIUS accounting port.
Page 55: Static User Authentication
(see ﬁgure 15). Static users consist of usernames and passwords entered into the access server’s internal users database. You can have up to 111 static users in the access server database. You must have superuser-level access to make changes to the static users database.
Page 56 • dialout—Access server will give a dialout connection. The dialout connection is an AT command set driven connection into one of the access server modems. On line help is provided by typing at help <cr>. • vpn—This option is currently not supported.
Page 57: Service Ip (Suserviceip)
(see “Service (suService)” on page 55). Service Service Port (suServicePort) This is the port number to connect to the service host. If the number is 0, the access server will use the default values for Telnet (port number 23) and RLogin (port number 513). Note...
Page 58 Access Server Administrators’ Reference Guide 5 • Authentication Static User Authentication...
Page 59: Dax
Chapter 6 Chapter contents Introduction ................................60 Configuring the DAX............................60 Circuit Type (daxClockMode) ........................60 Main Reference (daxClockMainRef) .......................61 Fallback Reference (daxClockFallbackRef) ......................61 Clock Status (daxClockFailure) ........................62...
Page 60: Introduction
WAN ports. The access server uses a single clock source for all WAN ports. Therefore, to avoid data loss caused by variations in network timing, each access server should terminate WAN connections from a single timing provider. WAN connections from multiple timing providers can be terminated in the access server if all the providers source their timing from the same stratum clock or if the access server provides the network clock.
Page 61: Main Reference (Daxclockmainref)
Access Server Administrators’ Reference Guide 6 • DAX Main Reference (daxClockMainRef) The main reference parameter determines which WAN link will supply the clock for the system. The following settings are available: • none(0)—No clock selection. This would be used in conjunction with either a secondary or slave circuit.
Page 62: Clock Status (Daxclockfailure)
Access Server Administrators’ Reference Guide 6 • DAX • netref-2(102)—Use to obtain system timing from a slave circuit. • oscillator(200)—Use internal free-run oscillator for the system clock Clock Status (daxClockFailure) The clock status indicates alarm conditions relating to the system clock. If there are no alarms, the DAX page will indicate No Alarms (see ﬁgure 17 on page 60).
Page 63: Dial In
Chapter 7 Dial In Chapter contents Introduction ................................67 Dial In main window ............................68 Active Calls (diActive) .............................68 Peak Active Calls (diMaxActive) ........................68 Total Calls (diTotalCallAttempts) ........................68 Call ID (diactIndex) ............................68 Call ID (diactIndex) ............................68 ML ID (diactMultiIndex) ..........................68 User (diactusername) ............................68 State (diactState) .............................68 Duration (diactSessionTime) ..........................68 Disconnect Reason (diactTerminateReason) ....................69...
Page 64 Access Server Administrators’ Reference Guide 7 • Dial In Frame Check Sequence Size (diConfigFcsSize) ..................76 Compression (diIpConfigCompression) ....................76 MultiLink (diConfigMultilink) .........................76 MultiBox (diConfigMMP) ........................76 Modify Maximum Time ..........................77 Maximum Session Time (min) (diSessionTimeout) ..................77 Maximum Idle Time (min) (diIdleTimeout) .....................77 Time to login (sec) (diLoginTimeout) .......................77...
Page 65 Access Server Administrators’ Reference Guide 7 • Dial In State at termination (diactTerminateState) ....................87 PPP Statistics ..............................87 Bad Address (diStatBadAddresses) ......................88 Bad Controls (diStatBadControls) ......................88 Packets Too Long (diStatPacketTooLongs) ....................88 Bad Frame Check Sequences (diStatBadFCSs) ..................88 LCP Statistics ..............................88 Local MRU (diStatLocalMRU) .........................88 Remote MRU (diStatRemoteMRU) ......................88...
Page 66 Access Server Administrators’ Reference Guide 7 • Dial In Locally Initiated Renegotiates (diactLocalRenegotiates) ................93 Locally Initiated Retrains (diactLocalRetrains) ..................93 Remote Initated Renegotiates (diactRemoteRenegotiates) .................93 Remote Initated Retrains (diactRemoteRetrains) ..................93...
Page 67: Introduction
Access Server Administrators’ Reference Guide 7 • Dial In Introduction The Dial In main window (see ﬁgure 19) is where you can change or view items that are associated with the user dialing in—including call statistics, type of service used, modem speciﬁc statistics, as well as conﬁguration parameters for login, service, domain name service, login attempts, conﬁguration of link, maximum time, and...
Page 68: Dial In Main Window
The Dial In window displays statistics for individual users. This window shows currently attached users, the users state, and time that the user has been on access server. This window can also display recently disconnected sessions. The following sections explain the meaning of each statistic.
Page 69: Disconnect Reason (Diactterminatereason)
Access Server Administrators’ Reference Guide 7 • Dial In Disconnect Reason (diactTerminateReason) The reason a call was disconnected. Modulation (diactModulation) The modulation of the link: • unknown(0) • v21(1)—V.21 modulation • v22(2)—V.22 modulation • v32(3)—V.32 modulation • v34(4)—V.34 modulation •...
Page 70: Dial In Details
Scroll down the window to view additional Dial In access server parameters. To modify the Dial In access server parameters, click on the Modify… link. For more information about modifying Dial In settings, refer to “Dial In Modify window” on page 71.
Page 71: Dial In Modify Window
Link compression, MRUs, MultiLink, and MultiBox access server parameters (see “Modify Conﬁguration” on page 75) • Time-out access server parameters for the session idle time to login and the MIB data linger time (see “Modify Maximum Time” on page 77) •...
Page 72: Modify Login
The system will go directly to PPP processing. The dial-up user must be conﬁgured for PAP authen- tication. Note If the user trying to connect to the access server is not conﬁgured for PAP he will be disconnected. •...
Page 73: Username Prompt (Diusernameprompt)
Access Server Administrators’ Reference Guide 7 • Dial In • textORchapORpap(6)—This setting enables clear text logins or PPP calls using PAP or CHAP authentication. Username Prompt (diUsernamePrompt) This is what will be displayed when the user ﬁrst connects after the Initial Banner is displayed. The string can be up to 39 characters.
Page 74: Default Service Port (Diserviceport)
All packets received on the speciﬁed dial-up link will be forwarded to the speciﬁed gateway. The gateway must be on the same network at the remote access server. This is the default setting that will be used if the setting is not overridden by the RADIUS response for that particular user.
Page 75: Modify Attempts
Access Server Administrators’ Reference Guide 7 • Dial In Modify Attempts This portion of the Dial In Modify window (see ﬁgure 22) describes modifying the login attempts parameters for dial in users. Figure 22. Dial In Modify window (modify Attempts, Conﬁguration, and Maximum Time objects) Failure Banner (diFailureBanner) This deﬁnes a message of up to 254 characters in length that will be displayed to a user if authentication fails.
Page 76: Link Compression (Dilinkcompression)
MultiBox enables a user to have multiple connections even if the subsequent call for an additional channel is on a different access server from the originating channel (bundlehead). MultiBox is useful when a single num- ber called by a user accesses multiple T1/E1s and subsequently different access servers.
Page 77: Modify Maximum Time
MultiBox option. Setting the param- eter to disable(0) disables the MultiBox option. If MultiBox is disabled, then acquiring an additional channel will fail if the bundlehead is not on the same access server. Modify Maximum Time This portion of the Dial In Modify window (see ﬁgure 22 on page 75) describes modifying the time-out values...
Page 78: Modify Modem Configuration
Access Server Administrators’ Reference Guide 7 • Dial In Modify Modem Conﬁguration This portion of the Dial In Modify window (see ﬁgure 23) describes modifying modem conﬁguration access server parameters for dial in users. Figure 23. Dial In Modify window (modify Modem Conﬁguration objects) V34 (diModemV34Enable) Allow V.34, K56 Flex, and V.90 options up to 56 kbps.
Page 79: V21(Dimodemv21Enable)
Access Server Administrators’ Reference Guide 7 • Dial In • enableBell212(2)—Enable Bell 212 modulation V21(diModemV21Enable) Allow V.21 or Bell 103 modulations. The following options are available: • disable(0)—Neither option is enabled • enableV21(1)—Enable V.21 modulation • enableBell103(2)—Enable Bell 103 modulation MaxSpeed (diModemMaxSpeed) This variable assigns the fastest data rate that will be negotiated.
Page 80: Protocol (Dimodemprotocol)
Access Server Administrators’ Reference Guide 7 • Dial In Note Larger numbers mean less transmit power is being output (in other words, a setting of 20 will result in less power than a setting of 12). Protocol (diModemProtocol) Assigns the error correction protocol to use with the modem. The following options are available: •...
Page 81: Dial In User Statistics Window
Link, shown in ﬁgure 24, pertain to the unique time slot deﬁned for each of these links. For speciﬁc details on the function of access server parameters deﬁned under these sections, refer to each under the access server Con- ﬁguration Menu.
Page 82: Call Identification
Ringing—The call has been recognized by the access server and is in the process of going off hook • Connecting—The access server has assigned a DSP to the incoming call and is now in the process of nego- tiating the type of modulation (V.34, V.32, ISDN, or 56K).
Page 83: Security Level (Diactaccesslevel)
The physical DSP chip that the user’s call is on. This is a number from 0 to 59. Interface Link (diactIFIndex) Virtual interface in the PPP multiplexer inside the access server that accepts packets from the Ethernet port for the connected dial-in user.
Page 84: Termination Reason (Diactterminatereason)
• notPapReq(24)—The access server is waiting for a PAP request packet containing the username/password for a call but the packet received was not a PAP request packet.
Page 85 • exceedsMultiLinkLimit(64)—Exceeds multilink channel limit set either on the remote access server or in the user entry on the RADIUS server •...
Page 86 Connection timed out because the remote side did not respond on the connection in a timely manner. The following are internal access server errors. Please contact technical support if you see these termination reasons: •...
Page 87: State At Termination (Diactterminatestate)
Access Server Administrators’ Reference Guide 7 • Dial In • dspBadPrimitive(48) • tcpNoBuffers(68) • udpOpenErr(75) • udpBindErr(76) • l2tpOpenErr(77) • l2tpLinkErr(78) • reLinkErr(79) State at termination (diactTerminateState) Indicates the value of diactState when the call was terminated. PPP Statistics This portion of the Dial In User Statistics window (see ﬁgure 25) shows PPP statistics (as 32-bit variables) of the current user selected.
Page 88: Bad Address (Distatbadaddresses)
Access Server Administrators’ Reference Guide 7 • Dial In Bad Address (diStatBadAddresses) The number of packets received with an incorrect address ﬁeld. Bad Controls (diStatBadControls) The number of packets received on this link with an incorrect control ﬁeld. Packets Too Long (diStatPacketTooLongs) The number of received packets that have been discarded because their length exceeded the maximum receive unit (MRU).
Page 89: Acc Map (Distatlocaltopeeraccmap)
Access Server Administrators’ Reference Guide 7 • Dial In • tacacs(5)—not currently implemented • edp(6) • ShivaPap(7)—not currently implemented ACC Map (diStatLocalToPeerACCMap) The current value of the ACC Map used for sending packets from the local modem to the remote modem. The local modem sends this character map to the remote peer modem to ensure that the data being transferred is interpreted correctly.
Page 90: Transmit Frame Check Seq. Size (Distattransmitfcssize)
Remote Max Slot ID (diIpRemoteMaxSlotId) The Max-Slot-Id access server parameter that the remote node has announced and that is in use on the link. If vjTCP header compression is not in use on the link, the value of this object will be 0. The range is from 0 to 255.
Page 91: Local Max Slot Id (Diiplocalmaxslotid)
Local Max Slot ID (diIpLocalMaxSlotId) The Max-Slot-Id access server parameter that the local node has announced and that is in use on the link. If vjTCP header compression is not in use on the link, the value of this object will be 0. The range is from 0 to 255.
Page 92: Number Called (Diactnumberdialed)
Access Server Administrators’ Reference Guide 7 • Dial In Number Called (diactNumberDialed) The phone number that was used to dial into the access server. Number Called From (diactCallingPhone) The user’s phone number—this is a caller ID feature. Data This portion of the Dial In User Statistics window (see ﬁgure 26 on page 91) describes the amount of PPP data sent and received by this user.
Page 93: Transmit Connection Speed (Diactspeed)
Access Server Administrators’ Reference Guide 7 • Dial In • v90(7)—V.90 modulation • v110(8)—V.110 modulation (not currently implemented) • isdn64(9)—ISDN 64 modulation • isdn56(10)—ISDN 56 modulation (not currently implemented) • 12tp(11)—12tp tunnelled multilink call Transmit Connection Speed (diactTxSpeed) The connected speed of the modem link (for example, 28.8 bps). These values, in bits per second, range from 300–33,600.
Page 94 Access Server Administrators’ Reference Guide 7 • Dial In Dial In User Statistics window...
Page 95: Dial Out
Chapter 8 Dial Out Chapter contents Introduction ................................97 Dial Out Main Window............................97 Total Active Calls (doActive) ..........................97 User (doactUsername) .............................97 State (doactState) ............................98 Session Time (doactSessionTime) ........................98 Disconnect Reason (doactTerminateReason) ....................98 Dial Out Details window ............................99 Dial Out Modify window............................100 Modify Login ..............................100 TCP Port (doTcpPort) ..........................100 TCP Type (doServiceType) ........................100...
Page 96 Access Server Administrators’ Reference Guide 8 • Dial Out Restrict Modification (doModemRestrictMods) ..................105 Dial Out User Statistics window..........................105 Unique ID ..............................106 Current Progress (doactState) ........................106 DSP Link (doactDSPIndex) ........................106 WAN Link (doactLinkIndex) ........................106 Time Slot (doactSlotIndex) ........................107 Session ................................107 Time Call Is/Was Active (doactSessionTime) ..................107 Minutes Until Timeout (doactRemainingIdle) ..................107...
Page 97: Introduction
This Dial Out main window (see ﬁgure 27) is where you can change items that are associated with making dial out connections from the access server to remote locations—including login, maximum time, session, physical layer, and outgoing modem conﬁguration information.
Page 98: State (Doactstate)
Dial-out link. • sessionTimeout(66)—The length of the connection exceeds the session time limit allowed The following are internal access server errors. Please contact technical support if you see these termination reasons: •...
Page 99: Dial Out Details Window
Dial Out Details window The Dial Out Details window (see ﬁgure 28) shows the active Dial Out conﬁguration of the access server. Scroll down the window to view additional Dial Out access server parameters.You can modify Dial Out Modify parameters by clicking on the …...
Page 100: Dial Out Modify Window
Access Server Administrators’ Reference Guide 8 • Dial Out Dial Out Modify window The Dial Out Modify window (see ﬁgure 29) is where you can make changes to the following: • Login settings (see “Modify Login”) • Maximum number of login attempts and the authentication failure banner (see “Modify Attempts” on page 101) •...
Page 101: Restrict To Lan (Dorestricttolan)
Access Server Administrators’ Reference Guide 8 • Dial Out Restrict to Lan (doRestrictToLan) Enabling the restriction to LAN will stop dialout attempts from originating at any port other than the LAN port. The options are deﬁned below: • disable(1) •...
Page 102: Modify Maximum Time
Access Server Administrators’ Reference Guide 8 • Dial Out Modify Maximum Time This portion of the Dial Out Modify window (see ﬁgure 30) describes conﬁguring the maximum session time, idle time, time to login, and call history timeout settings. Figure 30. Dial Out Modify window (Maximum Time, Modem Conﬁguration) Maximum Session Time (doSessionTimeout) This is the maximum time (in minutes) that a connection is allowed to be maintained.
Page 103: Time To Login (Sec) (Dologintimeout)
Access Server Administrators’ Reference Guide 8 • Dial Out Time to Login (sec) (doLoginTimeout) This is the maximum time (in seconds) that a user is given to log in. This only applies to the time before the user is authenticated. This setting should take into account any time delays incurred when querying a remote authentication server (such as a RADIUS).
Page 104: Maximum Speed (Domodemmaxspeed)
Access Server Administrators’ Reference Guide 8 • Dial Out • enableV21(1)—V.21 modulation is enabled • enableBell103(2)—Bell 103 modulation is enabled Maximum Speed (doModemMaxSpeed) This setting determines the fastest data rate that will be negotiated. Minimum Speed (doModemMinSpeed) This setting determines the slowest data rate that will be negotiated.
Page 105: Compression (Domodemcompression)
Access Server Administrators’ Reference Guide 8 • Dial Out Compression (doModemCompression) Assigns the data compression protocol to use with the modem. This setting is in effect only when V.42bis error correction (see “Protocol (doModemProtocol)”) is active. • Direct(0)—No compression will be used.
Page 106: Unique Id
Access Server Administrators’ Reference Guide 8 • Dial Out Figure 31. Dial Out User Statistics window (Unique ID, Session, Phone) State To view individual user statistics, select an active user in the column on the Dial Out main window (see “Dial Out Main Window”...
Page 107: Time Slot (Doactslotindex)
Access Server Administrators’ Reference Guide 8 • Dial Out Time Slot (doactSlotIndex) Indicates which time slot the current call is using. Session This portion of the Dial Out User Statistics window (see ﬁgure 31 on page 106) contains activity time for the current or most recent session.
Page 108: Octets Sent (Doactsentoctets)
Access Server Administrators’ Reference Guide 8 • Dial Out Octets Sent (doactSentOctets) The number of octets sent on this call. Octets Received (doactReceivedOctets) The number of octets received on this call. Physical Layer This portion of the Dial Out User Statistics window (see ﬁgure 32) contains statistics about the modem con- nection.
Page 109: Data Compression Protocol (Doactcompression)
Access Server Administrators’ Reference Guide 8 • Dial Out Data Compression Protocol (doactCompression) The compression technique used on this call. • unknown(0) • none(1) • v42bis(2) • mnp5(3) • stac(4) Modulation Symbol Rate (doactSymbolRate) The symbol rate of the call (modem only).
Page 110 Access Server Administrators’ Reference Guide 8 • Dial Out Dial Out User Statistics window...
Page 111: Drop And Insert
Chapter 9 Drop and Insert Chapter contents Introduction ................................112 Drop and Insert main window..........................112 Session Timeout (drSessionTimeout) ......................112 Call History Timeout (drLingerTime) ......................112 Active Calls (drActive) ..........................112 Session ID (dractIndex) ..........................112 Originating Link (dractLinkIndex) .......................112 Originating Channel (dractChannel) ......................113 Passed to Link (dractPassLinkIndex) ......................113 Passed to Channel (dractPassChannel) ......................113 Number Dialed (dractNumberDialed) ......................113 Calling Number (dractCallingPhone) ......................113...
Page 112: Introduction
9 • Drop and Insert Introduction The Drop and Insert window (see ﬁgure 33) contains setup objects associated with using the access server as a drop and insert box to an upstream or downstream location. Figure 33. Drop and Insert window Drop and Insert Conﬁguration Menu...
Page 113: Originating Channel (Dractchannel)
Access Server Administrators’ Reference Guide 9 • Drop and Insert Originating Channel (dractChannel) Which channel this call originated on. Passed to Link (dractPassLinkIndex) Which link this call was passed to. Passed to Channel (dractPassChannel) Which channel this call was passed to.
Page 114 Access Server Administrators’ Reference Guide 9 • Drop and Insert Drop and Insert main window...
Page 115: Digital Signal Processing (Dsp)
Chapter 10 Digital Signal Processing (DSP) Chapter contents Introduction ................................117 DSP Settings main window ..........................117 DSP Detected (dspDetected) ........................117 DSP Available (dspAvailable) ........................117 DSP Failed (dspFailed) ..........................117 DSP Fail Mask (dspFailMask) ........................117 DSP Configuration (dspConfiguration) ......................118 DSP Index (dspIndex) ...........................118 DSP State (dspState) .............................118 Admin State (dspDesiredState) ........................119 DSP Use (dspUse) ............................119...
Page 116 Access Server Administrators’ Reference Guide 10 • Digital Signal Processing (DSP) Spurious Tx Interrupt (dspSpuriousTxInterrupt) ..................123 Command Timeout (dspCommandTimeout) ..................123 Status Buffer Out Of Sync (dspStatusBufferOutOfSynch) ..............123 Command Extended Wait (dspCommandExtendedWait) ..............123 Bad Rx Pointers (dspBadRxPointers) ......................124 Receive Buffer Overflow (dspReceiveBufferOverflow) ................124 Tx Interrupt When Not Online (dspTxInterruptWhenNotOnline) ............124...
Page 117: Introduction
10 • Digital Signal Processing (DSP) Introduction The access server uses between 12 and 30 digital signal processors (DSPs) to pass digital information. The DSP main window (see ﬁgure 34) displays the current state of the DSPs (see “DSP Settings main window”).
Page 118: Dsp Configuration (Dspconfiguration)
Access Server Administrators’ Reference Guide 10 • Digital Signal Processing (DSP) DSP Conﬁguration (dspConﬁguration) Note This parameter applies to Model 2800 Series Remote Access Servers only. Sets the capabilities of the DSPs. The following options are available: • allPrimary(1)—DSPs can accept analog or digital calls.
Page 119: Admin State (Dspdesiredstate)
Access Server Administrators’ Reference Guide 10 • Digital Signal Processing (DSP) Admin State (dspDesiredState) The state of the DSP desired by the administrator—this state may be different than its actual state (refer to “DSP State (dspState)” on page 118). DSP Use (dspUse) This variable identiﬁes the current state that the DSP is in.
Page 120: Dsp Information Window
Access Server Administrators’ Reference Guide 10 • Digital Signal Processing (DSP) DSP information window This is where you can view and modify parameters for a single DSP. Figure 35. DSP information window (Status and Call Statistics) Status This portion of the DSP information window (see ﬁgure 35) shows information about the overall status of the DSP.
Page 121: Used By: (Dspuse)
Access Server Administrators’ Reference Guide 10 • Digital Signal Processing (DSP) When the DSP reboots itself or the administrator reboots the DSP manually, it can go through the following states: • halting(7) • booting(2) • corralingViaKick(11) • corralingViaInt(12) • corralingViaJump(13) •...
Page 122: Successful Connects (Dspsuccessfulconnects)
Access Server Administrators’ Reference Guide 10 • Digital Signal Processing (DSP) Successful Connects (dspSuccessfulConnects) The number of calls that successfully connected. Failed Connects (dspFailedConnects) The number of calls that failed to complete the connection. Local Halts (dspLocalHalts) The number of times the modem is shutdown when it is incorrectly in the connected state.
Page 123: System Counts
Access Server Administrators’ Reference Guide 10 • Digital Signal Processing (DSP) Figure 36. DSP information window (System Counts and Debug Statistics) System Counts This portion of the DSP information window (see ﬁgure 36) shows statistics for the the code that maintains the DSP.
Page 124: Bad Rx Pointers (Dspbadrxpointers)
Access Server Administrators’ Reference Guide 10 • Digital Signal Processing (DSP) Bad Rx Pointers (dspBadRxPointers) The number of bad receive buffer pointers. Receive Buffer Overﬂow (dspReceiveBufferOverﬂow) The number of times the receive buffer overﬂowed. Tx Interrupt When Not Online (dspTxInterruptWhenNotOnline) The number of transmit interrupts when not online.
Page 125: Ethernet
Chapter 11 Ethernet Chapter contents Introduction ................................126 Ethernet statistics..............................126 Alignment Errors (dot3StatsAlignmentErrors) ....................126 FCS Errors (dot3StatsFCSErrors) .........................126 Single Collision Frames (dot3StatsSingleCollision Frames) ................126 Multiple Collision Frames (dot3StatsMultipleCollisionFrames) ..............126 SQE Test Errors (dot3StatsSQETestErrors) ....................126 Deferred Transmissions (dot3StatsDeferredTransmissions) ................126 Late Collisions (dot3StatsLateCollisions) ......................127 Excessive Collisions (dot3StatsExcessiveCollisions) ..................127 Other Errors (dot3StatsInternalMacTransmitErrors) ..................127 Carrier Sense Errors (dot3StatsCarrierSenseErrors) ..................127...
Page 126: Introduction
11 • Ethernet Introduction Ethernet The access server provides management and statistical information in the window (see ﬁgure 37). Detailed information regarding the SNMP MIB II variables may be downloaded from RFC 1643, Deﬁnitions of Managed Objects for the Ethernet-like Interface Types.
Page 127: Late Collisions (Dot3Statslatecollisions)
Access Server Administrators’ Reference Guide 11 • Ethernet Late Collisions (dot3StatsLateCollisions) The number of times that a collision is detected later than 512 bit-times into the transmission of a packet. Five hundred and twelve bit-times corresponds to 51.2 microseconds on a 10 Mbps system.
Page 128: Collision Stats Per Interface
Access Server Administrators’ Reference Guide 11 • Ethernet Figure 38. Collision Stats Per Interface section Collision Stats Per Interface Note This following sections apply to Model 2800 Series Remote Access Servers only. Collision Count Bin (dot3CollCount) A histogram cell that represents the number of collisions that occured before an ethernet frame was sent successfully.
Page 129: Filter Ip
Chapter 12 Filter IP Chapter contents Introduction ................................130 Defining a filter ..............................130 Name (filterIpName) ............................131 Direction (filterIpDirection) .........................131 Action (filterIpAction) ..........................132 Source IP (filterIpSourceIp) ..........................132 Source IP Mask (filterIpSourceMask) ......................132 Destination IP (filterIpDestinationIp) ......................132 Destination Mask (filterIpDestinationMask) ....................132 Source Port (FilterIpSourcePort) ........................132 Action (filterIpSourcePortCmp) ........................132 Destination Port (filterIpDestinationPort) ....................133 Action (filterIpDestinationPortCmp) ......................133...
Page 130: Introduction
The access server enables 20 separate ﬁlters to be deﬁned, of which up to 10 can used during a single user con- nection. A single ﬁlter can be assigned to a user via the Static Users Authentication. Multiple ﬁlters can be assigned by using the RADIUS Filter-Id attribute.
Page 131: Name (Filteripname)
Speciﬁes the direction of the ﬁlter (that is, whether it applies to data packets inbound or outbound from the access server). The ﬁlter only applies to dial in users, users on other interfaces (that is, Ethernet, Frame Relay, and so on) are not affected. The following options are available: •...
Page 132: Action (Filteripaction)
0’s will be ignored. Thus, a setting of 0.0.0.0 will have the effect of disabling destination IP address comparison. Source Port (FilterIpSourcePort) Speciﬁes the source port number (TCP or UDP) that the access server compares. The source port action will determine how the source port is treated. Action (ﬁlterIpSourcePortCmp) Speciﬁes the Action (ﬁlterIpSourcePortCmp) that the access server compares.
Page 133: Destination Port (Filteripdestinationport)
• greaterThan(3)—The port in the destination IP packet is greater than Action (ﬁlterIpDestinationPortCmp) Speciﬁes the action (TCP or UDP) which the access server compares. The destination action will determine how the destination port is treated. • noCompare(0)—No Comparison to the destination port in the IP packet.
Page 134 Access Server Administrators’ Reference Guide 12 • Filter IP Defining a filter...
Page 135: Frame Relay
Chapter 13 Frame Relay Chapter contents Introduction ................................137 Configuring a Frame Relay link...........................137 Line Configuration ............................137 WAN Channel Assignment main screen .......................138 Configuring Frame Relay link parameters......................139 The Frame Relay main window ...........................139 Link: X Status (framerelStatus) ........................139 HDLC Statistics on Link ..........................140 Transmit (Bits/Sec) (framerelTxOctets) ....................140 Receive (Bits/Sec) (framerelRxOctets) .....................140 No Buffers Available (framerelRxNoBufferAvailable) ................140...
Page 136 Access Server Administrators’ Reference Guide 13 • Frame Relay Throughput (bits) (frCircuitThroughput) .....................145 IP Address (FrameIPAddr) ..........................145 Congestion (frameEnableCongestion) ......................145 Adding DLCIs ..............................145 Configuring IP routing with a Frame Relay Link....................145 Adding a route ..............................146 Link Status and the IP Forwarding ........................147...
Page 137: Introduction
A Frame Relay network consists of endpoints (the access server), frame relay access equipment (bridges, rout- ers, hosts, frame relay access devices) and network devices (switches, network routers, T1/E1 multiplexers). The most popular application is to use the access server as a PoP-in-a-box with a Frame Relay IP connection to the Internet backbone.
Page 138: Wan Channel Assignment Main Screen
7. Click Submit. At this point, the access server’s front panel LEDs should now be showing signs that the line is active. If the phone company line is not connected to the access server, the error indicator will glow red for that line/ connection.
Page 139: Configuring Frame Relay Link Parameters
Frame Relay network. Clicking on the link displays the DLCI window (see “DLCI window” on page 143) that enables you to conﬁgure PVCs on the access server. Link: X Status (framerelStatus) This speciﬁes LMI Link Status. If the management DLCI (either DLCI 0 or 1023) is established, then the sta- DOWN.
Page 140: Hdlc Statistics On Link
Access Server Administrators’ Reference Guide 13 • Frame Relay HDLC Statistics on Link The HDLC statistics on the link are deﬁned as follows: Transmit (Bits/Sec) (framerelTxOctets) This statistic shows the transmit rate in bits-per-second. Receive (Bits/Sec) (framerelRxOctets) This statistic shows the receive rate in bits-per-second.
Page 141: Dlmi Window
13 • Frame Relay DLMI window Each Frame Relay instance with the access server is known as the Data Link Management Interface or DLMI. The access server software currently supports one Frame Relay Link, or DLMI, on each of the T1/E1 WAN ports.
Page 142: Data Link Protocol
STATUS ENQUIRY messages and waits for a STATUS reply from the Network. The USER setting is correct if the access server is a DCE connecting to a Frame Relay network. It is possible to conﬁgure an access server to DLMI window...
Page 143: Bidirectional Polling
“look” like a Frame Relay Network. By setting the LMI Interface to NETWORK, you can connect another Frame Device directly to the access server. This is also the setting if you were to connect two access servers back-to-back without the beneﬁt of an established Frame Relay network.
Page 144: Dlci (Frcircuitdlci)
To conﬁgure a DLCI you will need the DLCI number and the IP address of the far-end router. If you have connected your access server to your provider’s Frame Relay network, you may automatically see one or more DLCIs on the screen. These DLCIs will simply need an IP address to identify the next hop.
Page 145: Committed Burst (Bits) (Frcircuitcommitedburst)
IP Address (FrameIPAddr) As all of the interfaces on the access server run in un-numbered mode, the IP address to enter is that of the far end router. This is not the IP address of the access server. After the IP address is entered, it will appear as a point-to-point link in the IP routing table with this address.
Page 146: Adding A Route
Frame Relay link to the device with the IP address of 192.168.1.3. Adding a route To add a route, do the following: To access the IP routing table in the access server: Conﬁguration Menu 1. Click on under the to to display the window (see ﬁgure 49 on page 161).
Page 147: Link Status And The Ip Forwarding
Access Server Administrators’ Reference Guide 13 • Frame Relay 3. Type in the Destination network (see ﬁgure 44). This number must correspond to the mask speciﬁed. (For example, if you wish to forward a C class address you would leave the last octet as 0.) Figure 44.
Page 148 Access Server Administrators’ Reference Guide 13 • Frame Relay Link Status and the IP Forwarding...
Page 149: Icmp
Chapter 14 ICMP Chapter contents Introduction ................................150 Modify ICMP redirect action ..........................150 Block ICMP redirects (boxBLockIcmpRedirects) ..................150 ICMP Receive/Send Messages window........................150 Total Received/Sent (icmpInMsgs, imcpOutMsgs) ..................151 w/Errors (icmpInErrors, icmpOutErrors) ......................151 Destinations Unreachable (IcmpInDestUnreachs, IcmpOutDestUnreachs) ..........151 Times Exceeded (icmpInTimeExcds, icmpOutTimeExcds) ................151 Parameter Problems (icmpInParmProbs, icmpOutParmProbs) ..............151 Source Quenchs (icmpInSrcQuenchs, icmpOutSrcQuenchs) ...............151 Redirects (icmpInRedirects, icmpOutRedirects) ...................152...
Page 150: Introduction
ICMP statistics. Modify ICMP redirect action This section is where you conﬁgure how the access server handles ICMP redirects. Enabling the access server to receive redirected messages is generally considered a security breach. Block ICMP redirects (boxBLockIcmpRedirects) The following options are available: •...
Page 151: Total Received/Sent (Icmpinmsgs, Imcpoutmsgs)
The source quench message is a request to reduce the rate at which the source is sending trafﬁc. If the access server receives a source quench, it will wait for acknowledg-...
Page 152: Redirects (Icmpinredirects, Icmpoutredirects)
The number of ICMP echo request messages received/send. The ICMP echo is used whenever one uses the diagnostic tool ping. Ping is used to test connectivity with a remote host by sending regular ICMP echo request packets and then waiting for a reply. Received echos (icmpInEchos) will increment when the access server is pinged.
Page 153: Interfaces
Chapter 15 Interfaces Chapter contents Introduction ................................154 Interfaces main window............................154 Number (ifIndex) ............................154 Type (ifType) ..............................155 Admin Stat (ifAdminStatus) ..........................155 Operational Status) ............................155 Interface Details ..............................156 Description (ifDescr) ............................156 Type (ifType) ..............................156 Max Transfer Unit (ifMTU) .........................157 Speed (ifSpeed) .............................157 Physical Address (ifPhysAddress) ........................157 Admin Stat (ifAdminStatus) ..........................157 Operational Status (ifOperStatus) .........................157...
Page 154: Introduction
The Interfaces window (see ﬁgure 47) shows the quantity of incoming and outgoing trafﬁc, as well as errors Inter- that cause frames to be discarded for each of the local interfaces. The statistics listed on the access server faces page comprise those contained in RFC 1213—Management Information Base for Network Management of TCP/IP-based internets: MIB-II.
Page 155: Type (Iftype)
Access Server Administrators’ Reference Guide 15 • Interfaces Type (ifType) The type of interface, distinguished according to the physical/link protocol(s) immediatly “below” the network layer in the protocol stack. The following valid interface options are available: • other(1) • ethernet-csmacd(6) •...
Page 156: Interface Details
Access Server Administrators’ Reference Guide 15 • Interfaces Interface Details Details When you click on a link, the type and description of the interface, speed, status, maximum size of pro- tocol data units (PDUs), and physical address display (see ﬁgure 48). The SNMP variables for this table are ref- erenced through the SNMP MIB interfaces table.
Page 157: Max Transfer Unit (Ifmtu)
Access Server Administrators’ Reference Guide 15 • Interfaces • slip(28) • frame-relay(32) Max Transfer Unit (ifMTU) The size of the largest protocol data unit which can be sent/received on the interface, speciﬁed in octets. For interfaces that are used for transmitting network protocol data units, this is the size of the largest network pro- tocol data unit that can be sent on the interface.
Page 158: Received And Discarded W/No Errs (Ifindiscards)
Access Server Administrators’ Reference Guide 15 • Interfaces Received and Discarded w/No Errs (ifInDiscards) The number of inbound packets which were chosen to be discarded even though no errors had been detected to prevent their being deliverable to a higher layer protocol. One possible reason for discarding such a packet could be to free up buffer space.
Page 159 Chapter 16 Chapter contents Introduction ................................161 IP main window ..............................161 Forwarding (ipForwarding) ...........................162 Default Time-To-Live (ipDefaultTTL) ......................162 Total Datagrams Received (ipInReceives) .....................162 Discarded for Header Errors (ipInHdrErrors) ....................162 Discarded for Address Errors (ipInAddrErrors) .....................162 Forwarded Datagrams (ipForwDatagrams) ....................162 Discarded for Unknown Protos (ipInUnknownProtos) .................162 Discarded w/No Errors (ipInDiscards) ......................162 Total Deliveries (ipInDelivers) ........................163 Out Requests (ipOutRequests) ........................163...
Page 160 Access Server Administrators’ Reference Guide 16 • IP Advanced… ..............................167 O/S forwarding table window..........................168 Destination (ipRouteDest) ..........................168 Mask (ipRouteMask) ............................168 Next Hop (ipRouteNextHop) ........................168 Interface (ipRouteIfIndex) ..........................168 Type (ipRouteType) .............................168 Protocol (ipRouteProto) ..........................169 Info (ipRouteInfo) ............................169 IP Routing Destination window ..........................170 Route Destination (ipRouteDest) .........................170...
Page 161: Introduction
Access Server Administrators’ Reference Guide 16 • IP Introduction The IP (Internet Protocol) window lists IP conﬁguration statistics and parameters, and enables you to modify IP settings. Figure 49. IP main window Conﬁguration Menu Click on under the to to display the window.
Page 162: Forwarding (Ipforwarding)
Access Server Administrators’ Reference Guide 16 • IP Forwarding (ipForwarding) The indication of whether this entity is acting as an IP gateway in respect to the forwarding of datagrams received by, but not addressed to, this entity. IP gateways forward datagrams, IP hosts do not (except those source-routed via the host).
Page 163: Total Deliveries (Ipindelivers)
Access Server Administrators’ Reference Guide 16 • IP Note The Discarded w/No Errors counter does not include any datagrams discarded while awaiting re-assembly. Total Deliveries (ipInDelivers) The total number of input datagrams successfully delivered to IP user-protocols (including ICMP). Out Requests (ipOutRequests) The total number of IP datagrams which local IP user-protocols (including ICMP) supplied to IP in requests for transmission.
Page 164: Fragmented Ok (Ipfragoks)
Access Server Administrators’ Reference Guide 16 • IP # Fragmented OK (ipFragOKs) The number of IP datagrams that have been successfully fragmented at this entity. # Fragmented Failed (ipFragFails) The number of IP datagrams that have been discarded because they required fragmenting at this entity, but were not fragmented because their Don’t Fragment option was set.
Page 165: Addressing Information
Access Server Administrators’ Reference Guide 16 • IP Addressing Information The IP addressing Information window (see ﬁgure 51) is where you can view the default address for outgoing IP datagrams, the local or loopback address of the box, and the IP address of the box as deﬁned in Chapter 20, “System”.
Page 166: Routing Information
Access Server Administrators’ Reference Guide 16 • IP Routing Information The IP Routing Information window (see ﬁgure 53) displays information required to route IP datagrams, including the IP address, subnet mask, next-hop router, and interface for each network interface deﬁned in the access server.
Page 167: Mask (Iproutemask)
Access Server Administrators’ Reference Guide 16 • IP Mask (ipRouteMask) Indicates the mask to be logical-ANDed with the destination address before being compared to the value in the ipRouteDest ﬁeld. For those systems that do not support arbitrary subnet masks, an agent constructs the value of the ipRouteMask by determining whether the value of the corresponding ipRouteDest ﬁeld belongs to a...
Page 168: O/S Forwarding Table Window
Access Server Administrators’ Reference Guide 16 • IP O/S forwarding table window The O/S forwarding table window lists forwarding information for all routes. Figure 54. IP Routing Forwarding Table Destination (ipRouteDest) The destination IP address of this route. An entry with a value of 0.0.0.0 is considered a default route. Multiple routes to a single destination can appear in the table, but access to such multiple entries is dependent on the table-access mechanisms deﬁned by the network management protocol in use.
Page 169: Protocol (Iprouteproto)
• unknown(0) • local(1)—Added by the access server to support an interface. For example, adding a route for a new dial-in user. • user(2)—Added by an administrator on the IP Routing Information table or via SNMP management tools.
Page 170: Ip Routing Destination Window
• unknown(0) • local(1)—Added by the access server to support an interface. For example, adding a route for a new dial-in user. • user(2)—Added by an administrator on the IP Routing Information table or via SNMP management tools.
Page 171: Seconds Since Updated (Iprouteage)
Access Server Administrators’ Reference Guide 16 • IP Seconds Since Updated (ipRouteAge) The number of seconds since this route was last updated or otherwise determined to be correct. Tag (RouteTag) An identiﬁer associated with the route. This can have different meanings depending on the protocol. For exam- ple, this gives the tag that was passed with a learned RIP route.
Page 172: Net Address (Ipnettomedianetaddress)
Access Server Administrators’ Reference Guide 16 • IP Net Address (ipNetToMediaNetAddress) The IP address corresponding to the media-dependent physical address. Physical (ipNetToMediaPhysAddress) The media-dependent physical address. Type (ipNetToMediaType) The type of mapping. Setting this object to the value invalid(2) has the effect of invalidating the corresponding entry in the ipNetToMediaTable.
Page 173: Mfr Version 2
Chapter 17 MFR Version 2 Chapter contents Introduction ................................175 MFR Version 2 main window ..........................175 Line Signalling ..............................175 Country (lineSigCountry) ........................175 Idle Code (lineSigIdleCode) ........................175 Forward Seize (lineSigForwardSeize) .......................176 Back Acknowledge (lineSigBackAck) .......................176 Back Answer (lineSigBackAnswer) ......................176 Minimum Transition Time (lineSigMinTransTime) ................176 Minimum Detection Time (lineSigMinDetectTime) ................176 Protocol Timeout (lineSigProtoTimeout) ....................176 Interregister Signalling............................176...
Page 174 Access Server Administrators’ Reference Guide 17 • MFR Version 2...
Page 175: Introduction
The MFR Version 2 window (see ﬁgure 57) contains objects for networks that use Signalling System R2. (To set up R2 Signalling in the access server, refer to Recommendations Q.400—Q.490 and to the host country’s PTT for national signalling speciﬁcations).
Page 176: Forward Seize (Linesigforwardseize)
Access Server Administrators’ Reference Guide 17 • MFR Version 2 Forward Seize (lineSigForwardSeize) Code to indicate there is a desire to use a line. Back Acknowledge (lineSigBackAck) Code to indicate there is an agreement to use a line. Back Answer (lineSigBackAnswer) Code to indicate a call has been completed.
Page 177: Mfr Version 2-Modify
Line Signalling This portion of the MFR Version 2—Modify window contains information described in the following sec- tions. Set the access server objects based upon codes that pertain to Idle, Seized, Answered, Clear-back, Release, and Blocked conditions. Note Line Signalling setup codes are country-speciﬁc. Please refer to Rec- ommendation Q.400 -Q.490 and to the host country’s PTT for...
Page 178: Country (Linesigcountry)
Access Server Administrators’ Reference Guide 17 • MFR Version 2 Country (lineSigCountry) Specifying a particular country or itu Standard deﬁnes the values of the remaining ﬁelds based on the specs. Custom allows for any values in the following ﬁelds (Line Signalling objects are country-speciﬁc. Please refer to the host country’s PTT for national signalling speciﬁcations).
Page 179: Forward Seize (Linesigforwardseize)
Access Server Administrators’ Reference Guide 17 • MFR Version 2 Forward Seize (lineSigForwardSeize) Code to indicate there is a desire to use a line. • abcd-0000(0) • abcd-0001(1) • abcd-0010(2) • abcd-0011(3) • abcd-0100(4) • abcd-0101(5) • abcd-0110(6) • abcd-0111(7) •...
Page 180: Back Answer (Linesigbackanswer)
The Interregister Signalling parameters are end-to-end 2-out-of-6 in-band code signals that use backward and forward-compelled signalling. Set the access server objects based upon codes that pertain to Forward Line Sig- nals, Forward Register Signals, Backward Line, and Backward Register Signals.
Page 181: Called Number
Access Server Administrators’ Reference Guide 17 • MFR Version 2 Note Interregister Signalling setup codes are country-speciﬁc. Please refer to Recommendation Q.400 -Q.490 and to the host country’s PTT for national signalling speciﬁcations. Called Number Total Digits (interRegCalledNumDig). The number of digits expected for the called number.
Page 182: Calling Number
Access Server Administrators’ Reference Guide 17 • MFR Version 2 • a10(10) • a11(11) • a12(12) • a13(13) • a14(14) • a15(15) Calling Number Total Digits (interRegCallingNumDig). The number of digits expected for the calling number. First and Middle Response Code (interRegCallingNumFirst). The code specifying what is done after every digit is sent except the last for the calling number.
Page 183 Access Server Administrators’ Reference Guide 17 • MFR Version 2 • a6(6) • a7(7) • a8(8) • a9(9) • a10(10) • a11(11) • a12(12) • a13(13) • a14(14) • a15(15) MFR Version 2—Modify...
Page 184 Access Server Administrators’ Reference Guide 17 • MFR Version 2 MFR Version 2—Modify...
Page 185: Rip Version 2
Chapter 18 RIP Version 2 Chapter contents Introduction ................................186 RIP Version 2 main window..........................186 Route Changes Made (rip2GlobalRouteChanges) ..................186 Responses Sent (rip2GlobalQueries) ......................186 Adding a RIP address ............................186 RIP Version 2—Configuration..........................187 Address (rip2IfConfAddress) .........................187 Domain (rip2IfConfDomain) ........................187 Authentication Type (rip2IfConfAuthType) ....................188 Authentication Key (rip2IfConfAuthKey) .....................188 Send (rip2IfConfSend) ..........................188 Receive (rip2IfConfReceive) .........................188...
Page 186: Introduction
Adding a RIP address Do the following: 1. Enter the IP network address of the interface on the access server that you want to enable RIP. This is not the IP address of the device you want to direct RIP packets to.
Page 187: Rip Version 2-Configuration
Access Server Administrators’ Reference Guide 18 • RIP Version 2 2. Enter the protocol version to be used for sending RIP packets. The following choices are available: – doNotSend (1) – ripVersion1 (2)—ripVersion 1 implies sending RIP updates compliant with RFC 1058 –...
Page 188: Authentication Type (Rip2Ifconfauthtype)
Access Server Administrators’ Reference Guide 18 • RIP Version 2 Authentication Type (rip2IfConfAuthType) The type of Authentication used on this interface. • noAuthentication (1) • simplePassword (2) Authentication Key (rip2IfConfAuthKey) The value to be used as the Authentication Key whenever the corresponding instance of rip2IfConfAuthType has a value other than authentication.
Page 189: Status (Rip2Ifconfstatus)
Access Server Administrators’ Reference Guide 18 • RIP Version 2 Status (rip2IfConfStatus) Writing invalid has the effect of deleting this interface. • valid (1) • invalid (2) RIP Version 2 (Statistics) The RIP Version 2 Status window (see ﬁgure 61) displays routing and update information for each subnet address.
Page 190 Access Server Administrators’ Reference Guide 18 • RIP Version 2 RIP Version 2 (Statistics)
Page 191: Snmp
Chapter 19 SNMP Chapter contents Introduction ................................192 SNMP window..............................192 In ..................................192 Packets (snmpInPkts) ............................192 Bad Version (snmpInBadVersions) .......................192 Bad Community Names (snmpInBadCommunityNames) ................193 Bad Community Uses (snmpInBadCommunity) ..................193 ASN ParseErrors (snmpInASNParseErrs) ......................193 Error Status “Too Big” (snmpInTooBigs) .....................193 No Such Names (snmpInNoSuchNames) .....................193 Bad Values (snmpInBadValues) ........................193 Error Status “Read Only”...
Page 192: Introduction
19 • SNMP Introduction The access server provides management and statistical information on SNMP. Detailed information on the SNMP MIB variables may be downloaded from the RFC. Select SNMP from the access server Conﬁguration SNMP Conﬁguration Menu Menu to monitor SNMP statistics. Click on...
Page 193: Bad Community Names (Snmpinbadcommunitynames)
Access Server Administrators’ Reference Guide 19 • SNMP Bad Community Names (snmpInBadCommunityNames) The total number of SNMP Messages delivered to the SNMP protocol entity which used a SNMP community name not known to said entity. Bad Community Uses (snmpInBadCommunity) The total number of SNMP messages delivered to the SNMP protocol entity which represented an SNMP operation which was not allowed by the SNMP community named in the message.
Page 194: Get Next Requests (Snmpingetnexts)
Access Server Administrators’ Reference Guide 19 • SNMP Get Next Requests (snmpInGetNexts) The total number of SNMP Get-Next PDUs that have been accepted and processed by the SNMP protocol entity. Set Requests (snmpInSetRequests) The total number of SNMP Set-Request PDUs that have been accepted and processed by the SNMP protocol entity.
Page 195: Get Responses (Snmpoutgetresponses)
Access Server Administrators’ Reference Guide 19 • SNMP Get Responses (snmpOutGetResponses) The total number of SNMP Get-Response PDUs that have been generated by the SNMP protocol entity. Traps (snmpOutTraps) The total number of SNMP Trap PDUs that have been generated by the SNMP protocol entity.
Page 196 Access Server Administrators’ Reference Guide 19 • SNMP...
Page 197: System
Chapter 20 System Chapter contents Introduction ................................199 System main window............................199 CPU ................................200 Percentage CPU Idle (boxidletime) ......................200 Time Slices Fully Utilized (boxCPUcritical) ....................200 Time Slices 90% Utilized (boxCPUWarning) ..................200 SNMP and HTTP ............................200 Version (boxSnmpVersion) ........................200 Super User Password (boxSnmpMasterPassword) ..................200 User Password (boxSnmpMonitorPassword) ...................200 LAN IP .................................200 How to Obtain Address (boxIPAddressTechnique) .................200...
Page 198 Access Server Administrators’ Reference Guide 20 • System System Manager (sysContact) ........................203 Box Name (sysName) ..........................204 Physical Location (sysLocation) .......................204 System Services (sysServices) ........................204 Web Settings (boxBackgroundFlag) ......................204 Monitor Privilege (boxMonitorPrivilege) ....................204 System—Modify window ............................205 SNMP and HTTP ............................205 Version (boxSnmpVersion) ........................205 Super User Password (boxSnmpMasterPassword) ..................206...
Page 199: Introduction
Access Server Administrators’ Reference Guide 20 • System Introduction The System main window (see ﬁgure 63) contains general setup information about the access server. System parameters are Patton Enterprise MIB object identiﬁers, though some are contained in RFC 1213, Manage- System ment Information Base for Network Management of TCP/IP-based internets: MIB-II.
Page 200: Cpu
Access Server Administrators’ Reference Guide 20 • System This section describes certain CPU utilization parameters. This portion of the System main window contains information described in the following sections. Percentage CPU Idle (boxidletime) This indicates what percentage of the I960 CPU processing power is not being utilized (see ﬁgure 63 on page 199).
Page 201: Manufacturer
This portion of the System main window contains information described in the following sections. Packet Holding Message Blocks... Buffer usage of access server message blocks based upon message block sizes (see ﬁgure 63 on page 199). Total (boxMsgBlksConﬁgured) The total number of message blocks on the system (see ﬁgure 63 on page 199).
Page 202: Operating System Heap Memory
Access Server Administrators’ Reference Guide 20 • System Figure 64. System main window (Operating System Heap Memory, Enclosure System, Payable Features, Instal- lation, and Other) Operating System Heap Memory This portion of the System main window contains information described in the following sections.
Page 203: Enclosure System
This portion of the System main window contains information described in the following section. Country (installCountry) Speciﬁes the country that the access server is installed in so it can be conﬁgured in accordance with local laws (see ﬁgure 64 on page 202).
Page 204: Box Name (Sysname)
IP, T1/E1, Frame Relay, System, and System Log links. • writeUserlpWanSystemUpload(498)—The monitor user can change all parameters—except passwords— under authentication, drop-and-insert, dial-in, IP, T1/E1, Frame Relay, System, and System Log links. The monitor user can also load ﬁrmware updates into the access server. System main window...
Page 205: System-Modify Window
Access Server Administrators’ Reference Guide 20 • System System—Modify window The System—Modify window (see ﬁgure 65) is where you can change SNMP and HTTP, LAN IP, payable features, country of installation, and other parameters. Figure 65. System—Modify window SNMP and HTTP This portion of the System—Modify window contains information described in the following sections.
Page 206: Super User Password (Boxsnmpmasterpassword)
This indicates how to obtain the LAN IP address (see ﬁgure 65 on page 205). The following options are avail- able: • disable(0)—Ethernet port is disabled (access server T1 to T1 usage only) • static(1)—LAN IP address is obtained from EIA-232 port and stored in Flash memory •...
Page 207: Country (Installcountry)
Access Server Administrators’ Reference Guide 20 • System Country (installCountry) Speciﬁes the country that the access server is installed in so it can be conﬁgured in accordance with local laws. The following options are available: • other(0) • unitedStates(1) •...
Page 208: Buffer Size (Boxbuffersize)
Access Server Administrators’ Reference Guide 20 • System Figure 66. Packet Holding Message Blocks window Buffer Size (boxbuffersize) The size in bytes of the buffer. No. of Buffers (boxbuffercount) The number of buffers this size which are currently free for use No.
Page 209: System Log
Chapter 21 System Log Chapter contents Introduction ................................210 System Log Main Window ..........................210 System Log—Modify ............................211 Daemons ..............................211 SysLog Daemon IP Address(syslogDaemonIP) ..................211 SNMP Trap Daemon IP Address (syslogTrapIP) ..................211 Priority .................................211 Min Priority for SysLog Daemon (syslogDaemonPriority) ..............212 Min Priority for Console RS-232 (syslogConsolePriority) ...............212 Min Priority for Flash Storage (syslogFlashPriority) ................212 Min Priority for SNMP Trap Daemon (syslogTrapPriority) ..............212 Min Priority for RAM (SyslogTablePriority) ...................213...
Page 210: Introduction
Access Server Administrators’ Reference Guide 21 • System Log Introduction The System Log window (see ﬁgure 67) displays the results from the system-wide error reporting utility. The object parameters in the system log are all Patton Enterprise MIB object identiﬁers.
Page 211: System Log-Modify
Access Server Administrators’ Reference Guide 21 • System Log System Log—Modify The System Log—Modify window (see ﬁgure 68) displays syslog and SNMP trap daemon locations, priority and maintenance information. Figure 68. System Log—Modify window Daemons This portion of the System Log—Modify window contains information described in the following sections.
Page 212: Min Priority For Syslog Daemon (Syslogdaemonpriority)
Access Server Administrators’ Reference Guide 21 • System Log Min Priority for SysLog Daemon (syslogDaemonPriority) System messages which have a priority equal to or greater than this setting will be sent to the syslog daemon deﬁned by syslogDaemonIP • prioritySystem(80) •...
Page 213: Min Priority For Ram (Syslogtablepriority)
Access Server Administrators’ Reference Guide 21 • System Log • prioritySystem(80) • priorityDisable(1000) Min Priority for RAM (SyslogTablePriority) System messages which have a priority equal to or greater than this setting will appear in System Log—Volatile Memory. The lower the number next to the priority listed below, the more details system logging will provide.
Page 214: Call Trace (Syslogcalltrace)
Access Server Administrators’ Reference Guide 21 • System Log • local5(21) • local6(22) • local7(23) Call Trace (syslogCallTrace) Enabling this will activate the call tracing utility. This is a powerful debugging utility which will log every sin- gle function call and return. At the death of a box the call trace will be printed out and can be sent to tech sup- port.
Page 215: System Log-Volatile Memory
Access Server Administrators’ Reference Guide 21 • System Log System Log—Volatile Memory The System Log—Volatile Memory window (see ﬁgure 69) displays timestamp and stored system log message information. Figure 69. System Log—Volatile Memory window Time (slTick) The time stamp in 10 ms intervals of the stored message.
Page 216: System Log-Non-Volatile Memory
Access Server Administrators’ Reference Guide 21 • System Log System Log—Non-Volatile Memory The System Log—Non-Volatile window (see ﬁgure 70) displays non-volatile RAM messages for each 10 ms time stamp. Figure 70. System Log—Non-Volatile Memory window Time (slfTick) The time stamp in 10 ms intervals of the stored message.
Page 217: T1/E1 Link
Chapter 22 T1/E1 Link Chapter contents Introduction ................................220 T1/E1 Link Activity main window ........................221 Link (dsx1LineIndex) ............................221 Type (dsx1LineType) ............................221 Circuit ID (dsx1CircuitIdentifier) .........................222 Line Status (dsx1LineStatus)..........................222 Failure States ..............................222 Far End Alarm Failure ..........................222 Alarm Indication Signal (AIS) Failure .....................223 Loss Of Frame Failure ..........................223 Loss Of Signal Failure ..........................223 Loopback Pseudo-Failure ........................223...
Page 218 Access Server Administrators’ Reference Guide 22 • T1/E1 Link 1 through 30(slotIndex) ..........................232 (slotFunction) ...............................232 Near End Line Statistics—Current ........................233 Errored Seconds (dsx1CurrentESs) .......................233 Severely Errored Seconds (dsx1CurrentSESs) ....................233 Severely Errored Frame Seconds (dsx1CurrentSEFSs) ...................233 Unavailable Seconds (dsx1CurrentUASs) ......................234 Controlled Slip Seconds (dsx1CurrentCSSs) ....................234 Path Code Violations (dsx1CurrentPCVs) ....................234...
Page 219 Access Server Administrators’ Reference Guide 22 • T1/E1 Link Path Code Violations (dsx1FarEndCurrentPCVs) ..................239 Bursty Errored Seconds (dsx1FarEndCurrentBESs) ..................239 Degraded Minutes (dsx1FarEndCurrentDMs) ....................239 Far End Line Statistics—History .........................239 Far End Interval (dsx1FarEndIntervalNumber) ....................239 Errored Seconds (dsx1FarEndIntervalESs) ....................239 Severely Errored Seconds (dsx1FarEndIntervalSESs) ..................240 Severely Errored Frame Seconds (dsx1FarEndIntervalSEFSs) ................240...
Page 220: Introduction
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Introduction The T1/E1 Link Activity window (see ﬁgure 71) shows the conﬁguration of the T1/E1 Interface, and reports statistics on the quality of the T1/E1 connection. The statistics listed in this section comprise those contained in RFC 1406—Deﬁnitions of Managed Objects for the DS1 and E1 Interface Types.
Page 221: T1/E1 Link Activity Main Window
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Near End Line Statistics—Current… • link—clicking on this link takes you to the page that displays line statis- tics for the current 15-minute interval. For more information about this page, refer to “Near End Line Sta- tistics—Current”...
Page 222: Circuit Id (Dsx1Circuitidentifier)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link • dsx1E1-MF—Based on CCITT/ITU G.704 with TS16 multiframing, without CRC • dsx1E1-CRC-MF—Based on CCITT/ITU G.704 with TS16 multiframing, with CRC Circuit ID (dsx1CircuitIdentiﬁer) This is the transmission vendor’s circuit identiﬁer. Knowing the circuit ID can be helpful during troubleshooting.
Page 223: Alarm Indication Signal (Ais) Failure
Access Server Administrators’ Reference Guide 22 • T1/E1 Link For ESF links, the Far End Alarm failure is declared if the Yellow Alarm signal pattern occurs in at least 7 out of 10 contiguous 16-bit pattern intervals. The alarm is cleared when the Yellow Alarm signal pattern has not occured for 10 contiguous 16-bit signal pattern intervals.
Page 224: Snmp Mib Definition
Access Server Administrators’ Reference Guide 22 • T1/E1 Link SNMP MIB deﬁnition The SNMP MIB is deﬁned as follows: dsx1LineStatus OBJECT-TYPE SYNTAX INTEGER (1..8191) ACCESS read-only STATUS mandatory DESCRIPTION “This variable indicates the Line Status of the interface. It contains loopback, failure, received ‘alarm’...
Page 225: Line Status-Configuration
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Line Status—Conﬁguration Clicking on the Line Status—Conﬁguration link in the T1/E1 Link Activity window displays the WAN Cir- cuit Conﬁguration window (see ﬁgure 73). This window contains general information about the DS1 inter- face, including the type of line (D4 Superframe or Extended Superframe), and kind of line coding (B8ZS or AMI).
Page 226: Time Elapsed (Dsx1Timeelapsed)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Note If you are conﬁguring a Model 28XX-series remote access server, the Transmit Clock Source loopTiming Line Inter- setting will appear in the face Settings WAN Circuit Conﬁguration portion of the window.
Page 227: Wan Circuit Configuration-Modify
Access Server Administrators’ Reference Guide 22 • T1/E1 Link WAN Circuit Conﬁguration—Modify Clicking on the Conﬁguration link in the T1/E1 Link Activity window displays the WAN Circuit Conﬁgura- tion—Modify window (see ﬁgure 75). From this window, you can change line interface settings, signalling set- tings, test settings, and change the T1/E1 pulse shapes.
Page 228: Line Interface Settings
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Note If you are conﬁguring a Model 28XX-series remote access server, the Transmit Clock Source loopTiming Line Inter- setting will appear in the face Settings WAN Circuit Conﬁguration portion of the window.
Page 229: Line Coding (Dsx1Linecoding)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link • dsx1E1(4)—Based on CCITT/ITU G.704 without CRC • dsx1E1-CRC(5)—Based on CCITT/ITU G.704 with CRC • dsx1E1-MF(6)—Based on CCITT/ITU G.704 with TS16 multiframing, without CRC • dsx1E1-CRC-MF(7)—Based on CCITT/ITU G.704 with TS16 multiframing, with CRC...
Page 230: Line Build Out (Linklinebuildout)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Line Build Out (linkLineBuildOut) This variable is used in T1 applications to adjust the T1 pulse shape at the cross connect point. Select the pulse strength needed to minimize distortion at the remote T1 receiver end. The default is t1pulse0dB, which should be adequate for most situations.
Page 231: Message-Oriented Switch Type (Linkisdnswitchtype)
• linkTaiwanR1(8) Message-Oriented Switch Type (linkIsdnSwitchType) This object allows the selection of the ISDN variations on the ISDN protocol, depending on the brand of switch to which the access server is connected. • ni1(0)—National ISDN-1 • dms(1)—Northern Telecom •...
Page 232: Send Code (Dsx1Sendcode)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Send Code (dsx1SendCode) This variable indicates what type of code is being sent across the DS1 interface by the device. The values mean: • dsx1SendNoCode—Sending looped or normal data • dsx1SendLineCode—Sending a request for a line loopback •...
Page 233: Near End Line Statistics-Current
Access Server Administrators’ Reference Guide 22 • T1/E1 Link • off(0)—Do not signal on this channel in response to the central ofﬁce. The access server will generate an idle signal. • dialin(1)—Used for dial-in. • ppp(2)—Not currently implemented. • frameRelay(3)—64 k frame relay connection •...
Page 234: Unavailable Seconds (Dsx1Currentuass)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Unavailable Seconds (dsx1CurrentUASs) The number of unavailable seconds encountered by a DS1 interface in the current 15-minute interval. Controlled Slip Seconds (dsx1CurrentCSSs) The number of Controlled Slip Seconds encountered by a DS1 interface in the current 15-minute interval.
Page 235: Near End Line Statistics-History
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Near End Line Statistics—History Click on Near End Line Statistics—History to display line statistics for the previous 15-minute interval (see ﬁgure 79). Figure 79. History of Near End Performance window Interval (dsx1IntervalNumber) A number between 1 and 96, where 1 is the most recently completed 15-minute interval and 96 is the least recently completed 15-minutes interval (assuming that all 96 intervals are valid).
Page 236: Controlled Slip Seconds (Dsx1Intervalcsss)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Controlled Slip Seconds (dsx1IntervalCSSs) The number of controlled slip seconds encountered by a DS1 interface in one of the previous 96, individual 15-minute, intervals. Path Code Violations (dsx1IntervalPCVs) The number of path coding violations encountered by a DS1 interface in one of the previous 96, individual 15-minute, intervals.
Page 237: Severely Errored Seconds (Dsx1Totalsess)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Severely Errored Seconds (dsx1TotalSESs) The number of severely errored seconds encountered by a DS1 interface in the previous 24-hour interval. Severely Errored Frame Seconds (dsx1TotalSEFSs) The number of severely errored framing seconds encountered by a DS1 interface in the previous 24-hour interval.
Page 238: Far End Line Statistics-Current
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Far End Line Statistics—Current Click on Near End Line Statistics—Current to display far-end statistics for the current 15-minute interval (see ﬁgure 81). Figure 81. Current Far End Performance window Time Elapsed (dsx1FarEndTimeElapsed) The number of seconds that have elapsed since the beginning of the far-end current error-measurement period.
Page 239: Path Code Violations (Dsx1Farendcurrentpcvs)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Path Code Violations (dsx1FarEndCurrentPCVs) The number of far-end path coding violations reported via the far-end block error count encountered by a DS1 interface in the current 15-minute interval. Bursty Errored Seconds (dsx1FarEndCurrentBESs) The number of far-end bursty errored seconds (BESs) encountered by a DS1 interface in the current 15- minute interval.
Page 240: Severely Errored Seconds (Dsx1Farendintervalsess)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Severely Errored Seconds (dsx1FarEndIntervalSESs) The number of far-end severely errored seconds encountered by a DS1 interface in one of the previous 96, individual 15-minute, intervals. Severely Errored Frame Seconds (dsx1FarEndIntervalSEFSs) The number of far-end severely errored framing seconds encountered by a DS1 interface in one of the previous 96, individual 15-minute, intervals.
Page 241: Far End Line Statistics-Totals
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Far End Line Statistics—Totals Click on Far End Line Statistics—Totals to display the total statistics of errors that occurred during the previ- ous 24-hour period (see ﬁgure 83). Figure 83. Far End Performance window Errored Seconds (dsx1FarEndTotalESs) The number of far-end errored seconds encountered by a DS1 interface in the previous 24-hour interval.
Page 242: Bursty Errored Seconds (Dsx1Farendtotalbess)
Access Server Administrators’ Reference Guide 22 • T1/E1 Link Bursty Errored Seconds (dsx1FarEndTotalBESs) The number of far-end bursty errored seconds (BESs) encountered by a DS1 interface in the previous 24-hour interval. Degraded Minutes (dsx1FarEndTotalDMs) The number of far-end degraded minutes (DMs) encountered by a DS1 interface in the previous 24-hour interval.
Page 243: Tcp
Chapter 23 Chapter contents Introduction ................................244 TCP main window ..............................244 Retransmit-Timeout Algorithm (tcpRtoAlgorithm) ..................244 Retransmit-Timeout Minimum (tcpRtoMin) ....................244 Retransmit-Timeout Maximum (tcpRtoMax) ....................244 Maximum Connections (tcpMaxConn) ......................245 Active Opens (tcpActiveOpens) ........................245 Passive Opens (tcpPassiveOpens) ........................245 Attempt/Fails (tcpAttemptFails) ........................245 ESTABLISHED Resets (tcpEstabResets) ......................245 Current ESTABLISHED (tcpCurrEstab) .....................245 Total Received (tcpInSegs) ..........................245 Total Sent (tcpOutSegs) ..........................245...
Page 244: Introduction
Access Server Administrators’ Reference Guide 23 • TCP Introduction Transmission Control Protocol (TCP) is the most widely used protocol among the TCP/IP suite. The access server provides management and statistical information on TCP. Detailed information regarding the SNMP MIB variables may be downloaded from RFC1213: Management Information Base for Network Management of TCP/IP-based internets: MIB-II.
Page 245: Maximum Connections (Tcpmaxconn)
Access Server Administrators’ Reference Guide 23 • TCP Maximum Connections (tcpMaxConn) The limit on the total number of TCP connections the entity can support. In entities where the maximum number of connections is dynamic, this object should contain the value -1.
Page 246: Tcp (Details)
Access Server Administrators’ Reference Guide 23 • TCP TCP (Details) From this screen you can view port details for remote and local TCP connections (see ﬁgure 85). You must enable the Facility Data Link (FDL) object in the T1/E1 Link section to read remote TCP port connectons. To reach this screen, click on the Details link from the TCP main window.
Page 247 Access Server Administrators’ Reference Guide 23 • TCP • established(5) • ﬁnWait1(6) • ﬁnWait2(7) • closeWait(8) • lastAck(9) • closing(10) • timeWait(11) • deleteTCB(12) TCP (Details)
Page 248 Access Server Administrators’ Reference Guide 23 • TCP TCP (Details)
Page 249: Udp
Chapter 24 Chapter contents Introduction ................................250 Handling of NETBIOS UDP Broadcasts (boxNetbiosUdpBridging) ............250 Received (udpInDatagrams) ..........................250 Received With No Ports (udpNoPorts) ......................250 Others Received with No Delivery (udpInErrors) ..................250 Sent (udpOutDatagrams) ..........................250 Listener Table (udpTable) ..........................251 Local Address (udpLocalAddress) ........................251 Local Port (udpLocalPort) ..........................251...
Page 250: Introduction
Access Server Administrators’ Reference Guide 24 • UDP Introduction User Datagram Protocol (UDP) is supported by the access server. Detailed information regarding the SNMP management information base (MIB) variables can be found in RFC1213: Management Information Base for Network Management of TCP/IP-based internets: MIB-II.
Page 251: Listener Table (Udptable)
Access Server Administrators’ Reference Guide 24 • UDP Listener Table (udpTable) A table containing UDP listener information. Local Address (udpLocalAddress) The local IP address for this UDP listener. In the case of a UDP listener that is willing to accept datagrams for any IP interface associated with the node, the value 0.0.0.0 is used.
Page 252 Access Server Administrators’ Reference Guide 24 • UDP Introduction...
Page 253: About
Chapter 25 About Chapter contents Introduction ................................254 Patton Electronics Company contact information ....................254...
Page 254: Introduction
Access Server Administrators’ Reference Guide 25 • About Introduction About link displays Patton Electronics Company contact information (see “Patton Electronics Company About Conﬁguration Menu About contact information”). Click on under the to display the main window (see ﬁgure 87). Figure 87. About window...
Page 255: License
Chapter 26 License Chapter contents Introduction ................................256 End User License Agreement ..........................256 1. Definitions: ...............................256 2. Title: .................................257 3. Term: ................................257 4. Grant of License: ............................257 5. Warranty: ..............................257 6. Termination: .............................257...
Page 256: Introduction
Access Server Administrators’ Reference Guide 26 • License Introduction License License link presents the End User License Agreement for the access server software. Click on Conﬁguration Menu License under the to display the main window (see ﬁgure 88). Figure 88. License window By opening the access server, operating the Designated Equipment or downloading the Program(s) electroni- cally, the End User agrees to the conditions in the “End User License Agreement”...
Page 257: Title
Access Server Administrators’ Reference Guide 26 • License 2. Title: Title to the Program(s), all copies of the Program(s), all patent rights, copyrights, trade secrets and proprietary information in the Program(s), worldwide, remains with Patton Electronics Company or its licensors.
Page 258 Access Server Administrators’ Reference Guide 26 • License End User License Agreement...
Page 259: A Supported Radius Attributes
Appendix A Supported RADIUS Attributes Chapter contents Access-Accept Attributes............................260 Access-Request Attributes ............................260 Accounting-Start Attributes..........................261 Accounting-Stop Attributes ..........................262...
Page 260: Access-Accept Attributes
Access Server Administrators’ Reference Guide A • Supported RADIUS Attributes Access-Accept Attributes Service-Type Framed-Protocol Framed-IP-Address Framed-Netmask Framed-Route Filter-Id Framed-MTU Framed-Compression Login-IP-Host Login-Service Login-Port Reply-Message Callback-Number State Class Session-Timeout Idle-Timeout Termination-Action Port-Limit Force-Next-Hop Access-Request Attributes User-Password CHAP-Password NAS-IP-Address NAS-Port Service-Type Framed-Protocol...
Page 261: Accounting-Start Attributes
Access Server Administrators’ Reference Guide A • Supported RADIUS Attributes Accounting-Start Attributes User-Name NAS-IP-Address NAS-Port Service-Type Framed-Protocol Class Called-Station-Id Calling-Station-Id NAS-Identiﬁer Account-Status-Type Account-Delay-Time Account-Session-Id Account-Authentic Account-Multiple-Session-Id NAS-Port-Type Data-Rate(RX) Xmit-Rate(TX) Accounting-Start Attributes...
Page 262: Accounting-Stop Attributes
Access Server Administrators’ Reference Guide A • Supported RADIUS Attributes Accounting-Stop Attributes User-Name NAS-IP-Address NAS-Port Service-Type Framed-Protocol Framed-IP-Address Class Called-Station-Id Calling-Station-Id NAS-Identiﬁer Account-Status-Type Account-Delay-Time Account-Input-Octets Account-Output-Octets Account-Session-Id Account-Authentic Account-Input-Packets Account-Output-Packets Account-Multiple-Session-Id NAS-Port-Type Data-Rate(RX) Xmit-Rate(TX) Accounting-Stop Attributes...

Patton electronics Access Server Administrator's Reference Manual

About this Guide

Introduction

Home

Import/Export

Alarms

Chapter 5 Authentication

Chapter 6 DAX

Dial in

Chapter 7 Dial in

Dial out

Chapter 8 Dial out

Drop and Insert

Digital Signal Processing (DSP)

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Patton electronics Access Server

Summary of Contents for Patton electronics Access Server
