Patton electronics EtherBITS 2285 Specifications

Control, monitor, and collect data from all your serial devices over the local network or Internet. Patton's Model 2285 universal single-port
device server is cost-effective and feature-rich, linking virtually any serial RS-485/422/232 device to any IP network over a secure connection.
User Selectable RS-485/422/232
Control, access, and monitor your asynchronous
serial terminals and devices over the LAN
Secure Communication
Security features include static key based RC4
data encryption, SSL, HTTPS, and IP filtering
COM Port Redirector Software Included
Windows®—Tactical COM Port Redirector
Linux-vtty drivers
Standard TCP/IP Protocols Supported
ARP, ICMP, TCP, Raw TCP, UDP, DHCP,
Telnet/SSH, HTTPS, DNS, Dynamic DNS, SNMP
v1, & v2, SSL
Connects Directly to the LAN
10/100Base-TX LAN connection
via RJ-45 connects to any hub/switch
Free Software Updates
Download new software via Patton's FTP
site to internal FLASH memory
Special Rates Available
Call for Details
Device Servers
EtherBITS™ RS-485/422/232
Universal Device Server
Model 2285
U
se Patton's Model 2285 universal
single-port device server to control,
access, inter-connect, and manage
RS-485/422/232 devices from any remote
location as if you were there. Patton's device
servers provide a new level of efficiency and
affordability to a variety of application envi-
ronments including industrial automation,
health care, security, transportation, retail,
and many others.
With built-in DHCP the Model 2285 automat-
ically obtains an IP address and a subnet
mask from the master server. With the IP
address identified and the serial port
attached, the Model 2285 can pass tranpar-
ently pass data end-to-end using Telnet over
TCP. Users can access management features
over telnet, serial console, or the web.
Security features include static key based
RC4 data encryption, SSL to provide a
secure connection between client and server,
Built-in Patton know-how. We
have been building interface
conversion devices since 1984!
Locking style barrel
connector provides secure
power connection
10/100Base-TX LAN port
connects to Ethernet hub/switch
EtherBITS... Connect with confidence.
HTTPS for secure data transfer over the net-
work, and IP filter, which limits and controls
access to the serial device. COM Port
Redirector is included with Patton's 2285
enabling users to use their existing
COM/TTY-based software, preventing the
hassle and expense of investing in additional
software.
The Patton Model 2285 provides physical-
layer connectivity by a user selectable RS-
485/422/232 serial port and 10/100Base-TX
Ethernet port. Configure the serial port's data
rate, ranging from 75 bps to 230 kbps, and
choose from a variety of connector types
including DB9 or DB25 male or female.
Easily and cost effectively bring serial
devices onto one global or local area net-
work!
Visit www.patton.com for more informa-
tion.
Serial connector:
• DB-9 male or female
• DB-25 male or female via cable
LEDs for monitoring Ethernet
link and activity
User-selectable serial RS-485/422/232
with async data rates up to 280 kbps
