  • Page 1 USER MANUAL MODEL 2715RC NetLink-E1: E1/Fractional E1 NTU Rack Mount Card SALES OFFICE Part# 07M2715RC Doc# 08607U2-001 (301) 975-1000 Rev. C TECHNICAL SUPPORT Revised 1/22/08 (301) 975-1007 An ISO-9001 http://www.patton.com Certified Company...
  • Page 2 3.2 Configuring the 1000RCM13348C Rear Card 4.0 Installation ................11 4.1 The Model 1001R14 rack Chassis 4.1.1 The Rack Power Supply 4.2 Installing the Model 2715RC Into the Chassis 4.3 V.35 Terminal Connection 4.4 Connecting the Network and the V.35 Interfaces 4.4.1 Network Interface Connection 5.0 Operation ................14...

  • Page 4: Ce And Telecommunication Approvals

    NOTE: Packages received without an RMA number will not be accepted. Patton Electronics' technical staff is also available to answer any questions that might arise concerning the installation or use of your Model 2715RC. Technical Service hours: 8AM to 5PM EST, Monday through Friday.

  • Page 6: Front Card Configuration

    Figure 2 shows the orientation of the DIP switches with respect to the “ON” and “OFF” positions. Front Panel Figure 2. Close up of the configuration switches NOTE: The ON position is oriented toward the front of the Model 2715RC.
  • Page 7 DIP Switches S1 - S8 The configuration switches on S1 - S8 may be set to allow config- uration for a wide range of applications. Default settings of S1 through S8 are shown in the table below. Descriptions of each switch follow the table.
  • Page 8 MF. Otherwise, the one using CRC-4 MF will detect loss of sync. In unframed mode, SW3 is used along with SW4 to determine the clock mode. In unframed mode, the model 2715RC can be set to Network, internal, or external clock mode.

  • Page 9: Clock Modes

    External Clock Transmitter timing is derived from the local DTE device. Note: When using the 2715RC as a high-speed short range modem, one unit of the link must be configured in either internal or external clock, and the other end must be configured for network clock mode.
  • Page 10 NOTE: When the data rate is set to 2.048Mb/s, then the unit is in G.703 mode, and it transmits user data on all 32 timeslots. There is no framing information; therefore, the CAS MF (SW2) is ignored and SW3 defaulted to clock mode. In all other rate settings, the unit employs G.704 framing;...

  • Page 11: Sgnd & Frgnd (Jb4)

    FRGND & V.35 PIN A (FRGND) (JB3) In the connected position, this strap links Frame Ground of the 2715RC and Pin A (Frame Ground) of the V.35 connector. In the open position, signal ground is disconnected from frame ground. Position 1&2 = FRGND and V.35 Pin A Connected (default) Position 2&3 = FRGND and V.35 Pin A Not Connected...

  • Page 12: The Rack Power Supply

    4.0 INSTALLATION This section describes the functions of the Model 1001R14 rack chassis, tells how to install front and rear Model 2715RC cards into the chassis, and provides diagrams for wiring the interface connections correctly. 4.1 THE MODEL 1001R14 RACK CHASSIS The Model 1001R14 Rack Chassis (Figure 6, below) has fouteen device card slots, plus its own power supply.

  • Page 13: Terminal Connection

    4.2 INSTALLING THE MODEL 2715RC INTO THE CHASSIS The Model 2715RC is comprised of a front card and a rear card. The two cards meet inside the rack chassis and plug into each other by way of mating 50 pin card edge connectors. Use the following...
  • Page 14 (TX) Transmit (Tip) Shield No connection No connection Figure 5. Model 2715RC twisted pair line interface. Notice! Any modular twisted pair cable connected to the rear card must be shielded cable, and the outer shield must be properly terminated to a shielded modular plug...

  • Page 15: Led Status Monitors

    Model 2715RC when its card-edge connector makes contact with the chassis’ mid-plane socket, and when the chas- sis’ power supply is turned on. Note: The Model 2715RC is a “hot swappable” card—it will not be damaged by plugging it in or removing it while the rack is powered up.
  • Page 16 The Loss of Sync LED lights when the unit loses synchronization with the incoming signal. This may happen when there is a framing mismatch or a loss of signal. In unframed mode, the LOS LED monitors the status of the transmit clock. The alarm LED indicates the presence of a AIS or RAI, or Out of Frame condition.
  • Page 17 The Local Loopback (LL) test checks the operation of the local Model 2715RC, and is performed separately on each unit. Any data sent to the local Model 2715RC in this test mode will be echoed (returned) back to the user device (i.e., characters typed on the key- board of a terminal will appear on the terminal screen).
  • Page 18 5.4 BIT ERROR RATE (V.52) DIAGNOSTICS The Model 2715RC offers a QRSS V.52 Bit Error Rate (BER) test pattern. This test pattern may be invoked along with the LAL and RDL tests to evaluate the unit(s) and the communication links.

  • Page 19: Specifications

    Up to 90% non-condensing Temperature: 0 to 50 Dimensions: 12.2 x 5.3 x 1.3 cm (4.8 x 2.1 x .5 in), ⁄ lb (.11kg) Model 2715RC Distance Table - Km (Miles) Data Rates Wire Gauge (kbps) .7mm (22) .5mm (24) 2048 1.2 (.76)

  • Page 21: Interface Pin Assignments

    APPENDIX C PATTON MODEL 2715RC INTERFACE PIN ASSIGNMENTS M/34 Connector, Terminal Interface Pin # Signal GND (Earth Ground/Shield) SGND (Signal Ground) CTS (DCE Source) DSR (DCE Source, Always On) CD (DCE Source) LL (Local Loop, DTE Source) TM (Test Mode Indicator (DCE Source)
  • Page 24 Dear Valued Customer, Thank you for purchasing Patton Electronics products! We do appreciate your business. I trust that you find this user manual helpful. We manufacture one of the widest selections of data communications products in the world including CSU/DSU's, network termination units, powered and self-powered short range modems, fiber optic modems, interface converters, baluns, electronic data switches, data-line surge protectors, multiplexers, transceivers, hubs, print servers and much more.
