Owner's Manual
Model Numbers:
BF362SD
BF392SD
Serial Number
Model Number
Part Number
Valued Customer,
Thank you and congratulations for purchasing a Dimplex
electric fireplace. Over the years, valuable memories
will occur around the warmth and comfort of your
fireplace. Thank you for allowing our product to be the
backdrop for those special moments.
Quality checked by:
7205860100R04
Advertisement
Table of Contents
Related Manuals for Dimplex BF362SD
Summary of Contents for Dimplex BF362SD
- Page 1 Owner’s Manual Model Numbers: BF362SD BF392SD Quality checked by: Serial Number Model Number Part Number Valued Customer, Thank you and congratulations for purchasing a Dimplex electric fireplace. Over the years, valuable memories will occur around the warmth and comfort of your fireplace. Thank you for allowing our product to be the backdrop for those special moments. 7205860100R04...
