Speco CVC637EX Specifications

MINIATURE COLOR BULLET CAMERA
WITH BUILT-IN 3.6MM LENS
EXTREME LOW LIGHT SENSITIVITY
FRONT VIEW
1"(W)

GENERAL FEATURES

.EXTREMELY LOW POWER CONSUMPTION
.1/3" SONY SUPER HAD CCD
.LOW ILLUMINATION
.TURBO AGC
.COMPACT AND LIGHTWEIGHT

SPECIFICATIONS

MODEL NO
IMAGE SENSOR
TV SYSTEM
NO.OF PIXELS
SCANNING SYSTEM
SYNC SYSTEM
RESOLUTION
MINIMUM ILLUMINATION
S/N RATIO
GAMMA CHARACTERISTIC
VIDEO OUTPUT
ELECTRONIC SHUTTER
POWER CONSUMPTION
LENS
OPERATIONAL TEMPERATURE
STORAGE TEMPERATURE
DIMENSIONS
WEIGHT
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
MODEL:CVC637EX/CVC637EXW
SIDE VIEW
2.7"(L)
CVC637EX/CVC637EXW
1/3" SONY SUPER HAD CCD
NTSC
NTSC=768(H) * 494(V)
2:1 INTERLACED
INTERNAL SYNC
540TV LINES
0.1 LUX
MORE THAN 50dB
0.45
1.0 Vp-p 75 ohm COMPOSITE
NTSC=1/60 - 1/120,000 Sec
12VDC 150mA
3.6mm
RH95% MAX(14 deg F to 122 deg F)
RH95% MAX(-4 deg F to 140 deg F)
2.7"(L) x 1"(W) x 1"(H)
APPX.3.8oz
REAR VIEW
SEE"A"
.HIGH RESOLUTION
.BUILT IN ELECTRONIC AUTO IRIS
.BUILT IN BACK LIGHT COMPENSATION
.PRE-SET AUTO EXPOSURE SETTINGS
.LOW SMEAR LEVEL
SEE"A"
DC 12V INPUT:RED
VIDEO OUTPUT:YELLOW
