Speco CVC-635N Installation Instructions

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Color Weatherproof Bullet Camera
with Sunshield
Features
Weatherproof . . . . . . . . . . . . . . . . . . .
Snap-on Sunshield . . . . . . . . . . . . . . . .
Universal Mounting System. . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . . . .
Resolution . . . . . . . . . . . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . . . . . . . . . .
Image Device . . . . . . . . . . . . . . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lens Options . . . . . . . . . . . . . . . . . . . . . . . .
Auto Iris . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Temperature . . . . . . . . . . . . . . . . . .
Video Output Level . . . . . . . . . . . . . . . . . . . .
Video S/N Ratio . . . . . . . . . . . . . . . . . . . . . .
White Balance . . . . . . . . . . . . . . . . . . . . . . .
Automatic Gain Control . . . . . . . . . . . . . . . . .
Housing . . . . . . . . . . . . . . . . . . . . . . . . . . .
Current Consumption . . . . . . . . . . . . . . . . . . .
Back Light Compensation . . . . . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . . . . . . . . . .
Operating Voltage Range . . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CVC-635N Camera
12V DC Regulated Power Supply
Mounting Screws
For more information contact us at:
CVC-635N
Benefits
Use indoors or outdoors
Eliminates glare from the sun or strong
sources of light
Mount on wall, ceiling or parapet
Perfect pictures in all lighting conditions
420 lines
1.0 lux
1/4" color CCD image sensor
2.9mm
3.6, 6, 8 and 12mm
Auto 1/60 - 1/100,000 seconds
-14˚F to 122˚F
1.0 Vp-p, 75 ohm
Greater than 48 dB
AWB
AGC on
Black metal
120 mA
BLC on
Regulated 12V DC power supply included
(UL and CSA listed)
DC +8~15V
1.2"W x 1.2"H x 3.7"D/
30mmW x 30mmH x 94mmD
4oz (approx. 120gr)
Package Includes:
Installation Instructions
Universal Mounting Bracket
