- Page 1 FUSION ™ 4-Drive Serial ATA Rackmount Disk Enclosure with Quad Interface User’s Guide Windows...
-
Page 2: Enclosure Specifications
Fusion R400QR5 Specifications and Features Drive Presence LED Drive Presence LED Drive Presence LED Drive Presence LED (Bay 1) (Bay 2) (Bay 3) (Bay 4) Ready Indicator Power LED Drive Module Drive Module Drive Module Drive Module (Bay 1) (Bay 2) - Page 3 DEGRADE SYSTEM RELIABILITY AND PERFORMANCE. Check the Sonnet Web site for the latest list of qualified hard drives. • Do not expose the device to rain, use it near water or containers...
-
Page 4: Drive Installation And Enclosure Setup
(Figure 5). 6. Repeat steps 4 and 5 for the remaining drives. push lever until it clicks 7. Install the Fusion R400QR5 into the rack or onto the desktop on which it will reside. push tray in until the lever... - Page 5 Drive Installation and Enclosure Setup Change Drive Configuration The drives included with Fusion R400QR5 are configured as a RAID 5 Detectin Disks –Re—Init? group and Mac OS Extended-formatted. If you need to change the configuration or set it up for use with an operating system other than Mac OS X, change the configuration of the R400QR5 drives following these steps.
- Page 6 Mac OS Users’ Instructions 10. Depending on how you configured the RAID group, it may 1. Assuming your computer is on, after the Fusion R400QR5 already be available to the system. Once the RAID group has configures the drives a Disk Insertion window will appear been formatted and finishes building, it is ready to use.
- Page 7 – Fusion R5 v1.0 –Menu Figure 8 View the Error Statistics The Fusion R400QR5 enclosure displays statistics Fusion R5 v1.0 –Menu for minor (recoverable) and major (persistent) read/write errors for each of the drives. 1. Press the button under Menu twice; RAID Mode appears (Figure 9).
- Page 8 The S.M.A.R.T. feature keeps track and reports the status of SATA drive health using certain parameters recorded by the drives. The Fusion R400QR5 displays two possibilities: good, or failing. Drives marked as Failing should be replaced.
- Page 9 Menus View Drive Temperatures SATA hard drives monitor their own temperature and report it to the Fusion R5 v1.0 –Menu Fusion R400QR5. 1. Press the button under Menu four times; Disk Temp appears (Figure 11). RAID Mode Drive:1: 37 –Next Go–...
-
Page 10: Hot Swapping
