NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF
Please visit www.fordracingparts.com for the most current instruction information
! ! ! PLEASE READ ALL OF THE FOLLOWING INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION.
AT ANY TIME YOU DO NOT UNDERSTAND THE INSTRUCTIONS, PLEASE CALL THE FORD RACING
FORD RACING PERFORMANCE PARTS PERFORMANCE ENGINE LIMITED WARRANTY
Ford Racing Performance Parts warrants to the original retail purchaser for 12 months or 12,000 miles,
whichever occurs first, that it will repair or replace, at its option, using new or remanufactured parts, Ford
Racing Performance Parts engine covered part that, after inspection, is found to have failed due to a defect
in factory supplied material or workmanship.
Covered parts include the engine block and cylinder heads, all internally lubricated parts of the engine, including
pistons, piston rings, piston pins, crankshaft and main bearings, connecting rods and rod bearings, camshaft and
camshaft bearings, timing chain, timing chain gears, intake and exhaust valves, valve springs, oil pump, push rods,
rocker arms, valve lash adjusters, hydraulic or mechanical lifters, and valve stem seals, to the extent that the
original engine contains the referenced warranted part. Parts that require normal manufacturers recommended
replacement intervals are not covered under this warranty.
To the extent allowed by law, loss of time, inconvenience, loss of the use of the vehicle, commercial loss, and
incidental and consequential damages are not covered. There is no other express or implied warranty on these
Ford Racing Performance Parts Engines including, but not limited to, any implied warranty of merchantability or
fitness for a particular purpose.
This warranty does not cover:
Parts which are replaced as part of normal maintenance.
Installation or removal costs.
Damage due to improper installation, negligence, alteration, or accident, including use related to racing or
competition, marine or motorcycle applications, or for other non-vehicle usage.
Engines where the vehicle odometer has been disconnected or the mileage has been altered.
Damage caused by lack of proper maintenance, failure to follow maintenance schedule intervals, or failure
to use or maintain proper type and levels of fluids, fuel, oil and lubricants. Proof of proper maintenance is
the owner's responsibility. Keep all receipts and be prepared to make them available if questions arise
about maintenance.
Towing, shipping, rental vehicles, loss of time, inconvenience, loss of use, or other economic loss.
Ford Racing Performance Parts engines installed in vehicles registered and/or normally operated outside
the United States and Canada.
To obtain warranty repair or replacement, please contact Ford Racing Performance Parts at (800) 367-3788 or:
Ford Racing Performance Parts
P.O. Box 490
Dearborn, MI 48121
Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356
Techline 1-800-367-3788
M-6007-XEFMS
340 HP Crate Engine
GUIDE
FORD RACING PERFORMANCE PARTS.
TECHLINE AT 1-800-367-3788 ! ! !
Page 1 of 13
IS-1850-0290

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-6007-XEFMS and is the answer not in the manual?

Questions and answers

Summary of Contents for Ford M-6007-XEFMS

  • Page 1 Ford Racing Performance Parts warrants to the original retail purchaser for 12 months or 12,000 miles, whichever occurs first, that it will repair or replace, at its option, using new or remanufactured parts, Ford Racing Performance Parts engine covered part that, after inspection, is found to have failed due to a defect in factory supplied material or workmanship.
  • Page 2: Engine Installation And Tuning Tips

    Many oil systems only flow one way. Connecting the remote oil filter or oil cooler lines backwards can cause • engine damage/failure. Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356 Techline 1-800-367-3788 FORD RACING PERFORMANCE PARTS. Page 2 of 13...
  • Page 3 Improper timing can damage pistons, rod bearings, head gaskets, and many other engine parts. • Typical total mechanical advance timing at 4000 rpm for Ford Racing Performance Parts crate engines: • 5.0L - 36° to 38° With factory EFI, 14 to 16 degrees initial.
  • Page 4 Installing the wrong flywheel for the balance factor of the engine will cause vibration and eventually damage the engine. Wrong length input shaft or "stack up height" can force the crank forward and damage the engine thrust bearing. Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356 Techline 1-800-367-3788 FORD RACING PERFORMANCE PARTS.
  • Page 5: Engine Oil Recommendations

    Distributor gears installed at the incorrect height and gears made of the wrong material. We have seen this with many remanufactured distributors as well as popular aftermarket manufacturers of distributor assemblies. Use cast iron gears for cast iron flat tappet cams, and steel gears for steel hydraulic roller cams. The M-6007-XEFMS uses a steel camshaft.
  • Page 6: Installation Instructions

    If you have questions regarding your gear selection, please contact the Ford Racing Tech Line at (800) 367-3788. Failure to use the correct gear will lead to premature gear failure. Premature gear failure may also be attributed to improper meshing of the gear teeth between the camshaft and distributor.
  • Page 7 This procedure will confirm that the gear is not being forced down against the support and not being held up off the support in the block. Continue with STEP 8. Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356 Techline 1-800-367-3788 FORD RACING PERFORMANCE PARTS.
  • Page 8: Distributor Installation

    Install distributor hold-down clamp and bolt. Tighten bolt, but leave it loose enough to rotate the distributor. STEP 8: Install distributor cap and wires. Set timing. Tighten hold-down bolt. STEP 9: Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356 Techline 1-800-367-3788 FORD RACING PERFORMANCE PARTS. Page 8 of 13 IS-1850-0290...
  • Page 9: Cooling System

    Install the dial indicator (as shown in Fig. 2). Rotate the crankshaft and mark down the reading. Be sure to push the crankshaft against the thrust bearing for an accurate reading. Maximum runout is .010. Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356 Techline 1-800-367-3788 FORD RACING PERFORMANCE PARTS.
  • Page 10: Ignition System

    Tech Line at (800) 367-3788. IGNITION SYSTEM The M-6007-XEFMS does not include a distributor. The distributor you select must have a steel distributor gear to be compatible with the hydraulic roller camshaft. Distributor gear M-12390-B for carbureted application or F for EFI application recommended.
  • Page 11: Valve Covers

    NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF OIL PANS The M-6007-XEFMS comes with a production 1991-1995 Mustang rear sump oil pan. The oil pan may need to be changed to properly fit and function in your application.
  • Page 12 Double roller timing chain set M-6268-A302 • Rear sump pan fits most Fox body cars • Ford Racing aluminum GT-40 cylinder heads M-6049-X306 with 1.94" intake valves and 1.54" exhaust valves • Roller rocker arms M-6564-B351 • New block, oil and water pumps, oil pan •...
  • Page 13: Quick Info

    Fuel delivery: 600 cfm carburetor, 30 lb injectors EFI • Distributor gear: steel • Crank pulley spacer: M-8510-D351 recommended for most 4-bolt pulley applications • Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356 Techline 1-800-367-3788 FORD RACING PERFORMANCE PARTS. Page 13 of 13 IS-1850-0290...
