Integrated in ICH5R, this motherboard comes with the function of additional RAID 0 and RAID 1 function. Beside RAID 0 and
RAID 1, this motherboard is designed with Promise Serial ATA (PDC20378) controller onboard, which is capable of providing
you additional RAID 0, 1, 0+1 functioned by ATA133 IDE Connector.
f
o
r
P
r
o
m
i
s
e
P
D
f
o
r
P
r
o
m
i
s
e
P
D
C
2
0
3
7
8
C
2
0
3
7
8
Serial ATA Ports
Motherboard
AX4C Max II
Note: Please be noted that "1MHz stepping
AGP/PCI Overclocking" will be automatically
disabled when SATA device is being connected,
for preventing any system instability.
94
O
n
l
i
n
e
M
O
n
l
i
n
e
M
SATA port 2 (ICH5R)
SATA port 1 (ICH5R)
SATA port 3 (PDC20378)
SATA port 4 (PDC20378)
SATA 1 & 2
SATA 3 & 4
RAID 0, 1
RAID 0, 1, 0+1
(With ATA133)
