On the strength of Broadcom Gigabit LAN controller on board, which is a highly-integrated Platform LAN Connect device, it
provides Gigabits Ethernet for office and home use, the Ethernet RJ45 connector is located on top of USB connectors. The
right-hand side LED indicates the link mode, it blinks in orange whenever linking to network. The left-hand side LED indicates
the Connecting mode, and it lights in green when 100Mbps LAN is connected (never lights while 10Mbps is connected), but
lights in orange when Gigabits LAN is connected. To enable or disable this function, you may simply adjust it through BIOS.
t
L
A
N
o
n
b
o
a
r
d
t
L
A
N
o
n
b
o
a
r
d
58
O
n
l
i
n
e
M
a
n
u
O
n
l
i
n
e
M
a
n
u
Connecting (Left)
Green (100Mbps)
Orange (Gigabit)
Linking (Right)
Orange
