  • Page 1 Landmark Cinema L a n d m a r k P r o d u c ts...
  • Page 2 Consumers should inquire from selling dealer as to the nature and extent of the dealer’s warranty, if any. AMX Corporation is not liable for any damages caused by its products or for the failure of its products to perform, including any lost profits, lost savings, incidental damages, or consequential damages.
  • Page 3: Table Of Contents

    Table of Contents Introduction ................ 1 Installing a Landmark Cinema System Landmark Cinema Components PMB-CF2 Mini Cardframe PMB-TCC Television Control Center PMB-RF RF Receiver Viewpoint Wireless Touch Panels Computer Selecting Audio and Video Devices Placing the Devices Mapping Out the Wiring...
  • Page 4 Table of Contents Landmark Cinema Quick Setup Guide...
  • Page 5: Introduction

    Of these components, one of the most important is the surround processor, which handles audio and video switching for the theater system. Landmark Cinema controls this device via an IR emitter. Up to seven additional IR-controlled devices can be controlled by a Landmark Cinema system.
  • Page 6: Landmark Cinema Components

    PLC-MCU Master Control Unit, which is essentially a computer that runs on the Landmark Cinema's PhastLink network. The PLC-MCU runs the project code that is stored in its 2MB on onboard RAM. The other card used in the Landmark Cinema package is the PLC-IROUT IR Output card.
  • Page 7: Pmb-Tcc Television Control Center

    CF2. This indicates that there is communication between the PMB-TCC and the PMB-CF2 cardframe. The IR-OUT LED on the front of the PMB-TCC will blink whenever IR code is sent to an IR emitter from the PMB-TCC. Landmark Cinema Quick Setup Guide Introduction...
  • Page 8: Pmb-Rf Rf Receiver

    Connection to the PMB-CF2 is via a PhastLink cable that plugs into a PhastLink RJ- 45 port on the rear of the unit (Figure 4). Figure 4 PMB-RF RF Receiver (rear view) Figure 5 PMB-RF RF Receiver (front view) Introduction Landmark Cinema Quick Setup Guide...
  • Page 9: Viewpoint Wireless Touch Panels

    Viewpoint Wireless Touch Panels The PHAST Viewpoint Wireless Touch Panel (Figure 6) provides a fully programmable graphical control interface with the Landmark Cinema system. Available with color or grayscale screens, the Viewpoint's graphical interface can be quickly and easily custom tailored for any client's needs, with many possible menu levels and screens.
  • Page 10: Computer

    Once the program has been downloaded to the PLC-MCU card, the computer may be disconnected from the Landmark Cinema system and the program will run from the PLC-MCU card. If programming changes are to be made, the computer must be reconnected to the Landmark Cinema system and the new program downloaded to the PLC-MCU.
  • Page 11: Placing The Devices

    Also allow for running the necessary wires or cables to the devices in a safe and convenient manner. Landmark Cinema Quick Setup Guide Introduction...
  • Page 12: Mapping Out The Wiring

    Place all of the Landmark Cinema devices in the desired locations (or at least as close as possible). It is not necessary for all Landmark Cinema devices to be placed together, although it may be more convenient to group them in a rack or entertainment center.
  • Page 13 Figure 7 Mapping the wiring to the IR emitters Landmark Cinema Quick Setup Guide Introduction...
  • Page 14: Making The Cables

    PIN1 White/Green PIN1 White/Orange Wiring Standard) PIN2 Green PIN2 Orange PIN3 White/Orange PIN3 White/Green PIN4 Blue PIN4 Blue PIN5 White/Blue PIN5 White/blue PIN6 Orange PIN6 Green PIN7 White/Brown PIN7 White/Brown PIN8 Brown PIN8 Brown Introduction Landmark Cinema Quick Setup Guide...
  • Page 15 Landmark Cinema Quick Setup Guide Introduction...
  • Page 16 AMX reserves the right to alter specifications without notice at any time. brussels • dallas • los angeles • mexico city • philadelphia • shanghai • singapore • tampa • toronto • york 3000 research drive, richardson, TX 75082 USA • 469.624.8000 • 800.222.0193 • fax 469.624.7153 • technical support 800.932.6993...
