AT-BRKT15 Wall-Mount Bracket Installation Manual
This manual will assist you in the installation of your AT-BRKT15. When
opening this Allied Telesyn product, make sure the package you have
received is complete and free of visible damage from shipping. This pack-
age should include:
• 1 bracket (A)
• 4 #8 x 7/8" self-tapping panhead screws (D)
• 4 "Bantam Plug" #8-10 plastic screw anchors
• Cable tie wraps (C)
The AT-BRKT15 is only designed for use in ATI products.
The AT-BRKT15 is for mounting the ATI repeaters, such as the
AT-MR12x, AT-MR410T and AT-MR810T series, that are housed in the
"slim-line" micro-case.
Installation of the repeater in the mounting bracket requires the follow-
ing tools:
• Mounting screws for your application (shown in Figure 1 as D)
• Hammer
• Drill and 3/16" bit (or equivalent)
• Pencil
• Awl or other punch
The AT-BRKT15 must be mounted in a vertical orientation with the
power supply (as indicated by the power receptacle) up to gain
maximum convection cooling.
PN 613-10353 Rev. A
NOTE
NOTE
Advertisement
Related Manuals for Allied Telesis AT-BRKT15
Summary of Contents for Allied Telesis AT-BRKT15
- Page 1 AT-BRKT15 Wall-Mount Bracket Installation Manual This manual will assist you in the installation of your AT-BRKT15. When opening this Allied Telesyn product, make sure the package you have received is complete and free of visible damage from shipping. This pack- age should include: •...
- Page 2 Installing your Allied Telesyn AT-BRKT15 Refer to Figure 1. 1. Using the bracket as a template, mark the screw holes. 2. Use an awl or other punch to punch pilot holes. 3. Drill the holes. 4. If mounting on wallboard, insert the Bantam plugs into the holes.
- Page 3 6. Mount the repeater in the bracket using the corner screws, but without the rubber feet. 7. Mount the bracket to the wall using the #8 x 7/8" pan head Phillips screws (D). 8. Set aside the rubber feet. They are no longer required. For specific dimensions, please see Figure 2.
- Page 4 Allied Telesyn International 19015 North Creek Parkway, Suite 200 Bothell, WA 98011 U.S. & International Tel: 800/424-4284 Technical Support Tel: 800/428-4835 This document produced using Recycled Materials...
