Ford 1998 Escort Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Before driving
Starting and driving
Starting
Servicing
All rights reserved. Reproduction by any means, electronic or mechanical
including photocopying, recording or by any information storage
and retrieval system or translation in whole or part is not permitted without
written authorization from Ford Motor Company.
Copyright
1997 Ford Motor Company
Contents
Elemental Chlorine Free
2
3
17
47
80
87
104
123
180
187
188
1

Advertisement

Table of Contents
loading

Related Manuals for Ford 1998 Escort

Summary of Contents for Ford 1998 Escort

  • Page 1 All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Copyright 1997 Ford Motor Company...

  • Page 2: Introduction

    1 600 km (1 000 miles). INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation.

  • Page 3: Instrumentation

    Instrumentation...
  • Page 4 Instrumentation Foglamp control * (pg. 28) Headlamp/turn signal control (pg. 26) MIRROR Power side view mirrors (pg. 17) Instrument panel dimmer switch (pg. 17) Instrument cluster FUEL FILL FUEL Speed control (pg. 28) (pg. 6) THEFT 0 0 0 1 1 3 Driver side air (pg.

  • Page 5: Climate Controls

    Windshield wiper/washer control (pg. 34) SEEK TRACK SCAN TUNE DISCS PUSH ON SIDE 1-2 Passenger side air bag (pg. 58) TAPE PREMIUM SOUND DOLBY B NR COMP SHUF Climate controls (pg. 18) Instrumentation BASS TREB FADE R.DEF Electronic sound system; refer to Audio Guide (pg.

  • Page 6: Warning Lights And Chimes

    Instrumentation WARNING LIGHTS AND CHIMES Base instrument cluster FUEL FILL SERVICE ENGINE SOON FUEL BRAKE Sport instrument cluster FUEL FILL SERVICE ENGINE SOON FUEL BRAKE 60 70 0 0 0 0 0 0 0 0 km/h 60 70 0 0 0 0 0 0 0 0 km/h –...

  • Page 7: Service Engine Soon

    ZX2 coupe instrument cluster FUEL FILL FUEL – BRAKE CHECK SERVICE COOLANT ENGINE SOON Low fuel Illuminates when the fuel tank has approximately eight liters (two gallons) remaining. The lamp will also illuminate when the ignition key is turned to ON and the engine is off.
  • Page 8 Instrumentation position to check the bulb. If it comes on after the engine is started, one of the engine’s emission control systems may be malfunctioning. The light may illuminate without a driveability concern being noted. The vehicle will usually be drivable and will not require towing.
  • Page 9 additional vehicle service is required. If the Service Engine Soon light remains on, have your vehicle serviced at the first available opportunity. Light is blinking: Engine misfire is occurring which could damage your catalytic converter. You should drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced at the...
  • Page 10 Instrumentation Brake system warning Momentarily illuminates when the ignition is turned ON and the engine is off. Also illuminates when BRAKE the parking brake is engaged. Illumination after releasing the parking brake indicates low brake fluid level. Anti-lock brake system (ABS) (If equipped) Momentarily illuminates when the ignition is turned on and the...
  • Page 11 Instrumentation Charging system Momentarily illuminates when the ignition is turned ON and the engine is off. The light also illuminates when the battery is not charging properly, requiring electrical system service. Engine oil pressure Illuminates when the oil pressure falls below the normal range. Switch off the engine immediately.
  • Page 12 Instrumentation For information on the safety belt warning chime, refer to the Seating and safety restraints chapter. Supplemental restraint system (SRS) warning chime For information on the SRS warning chime, refer to the Seating and safety restraints chapter. Key-in-ignition warning chime Sounds when the key is left in the ignition in the OFF/LOCK or ACC position and either front door is...
  • Page 13 GAUGES Base instrument cluster gauges FUEL FILL SERVICE ENGINE SOON BRAKE Sport instrument cluster gauges FUEL FILL SERVICE ENGINE SOON FUEL BRAKE ZX2 coupe instrument cluster gauges FUEL FILL FUEL – BRAKE CHECK SERVICE COOLANT ENGINE SOON 60 70 0 0 0 0 0 0 0 0 km/h 60 70...
  • Page 14 Instrumentation Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion. The ignition should be in the OFF position while the vehicle is being refueled.

  • Page 15: Trip Odometer

    Speedometer Indicates the current vehicle speed. Odometer Registers the total kilometers (miles) of the vehicle. Trip odometer Registers the kilometers (miles) of individual journeys. To reset, depress the control. Instrumentation 0 0 0 0 0 km/h 0 0 0 0 0 0 0 0 0 km/h 0 0 0 0 0 0 0 0 0...
  • Page 16 Instrumentation Tachometer (if equipped) Indicates the engine speed in revolutions per minute. THEFT Driving with your tachometer pointer in the red zone may RPMx1000 damage the engine.

  • Page 17: Controls And Features

    PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel. Rotate left to brighten. Rotate right to dim. POWER SIDE VIEW MIRRORS To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. 2.
  • Page 18 Controls and features AUDIO SYSTEM Refer to the “Audio Guide” for instructions on how to operate the audio system. CLIMATE CONTROL SYSTEM Heater only system (if equipped)
  • Page 19 Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. On heater-only systems, the air cannot be cooled below the outside temperature. Mode selector control Controls the direction of the airflow to the inside of the vehicle.
  • Page 20 Controls and features ducts. It can be used to clear ice or fog from the windshield. Operating tips In humid weather, select before driving. This will help to prevent your windshield from fogging. After a few minutes, select any desired position.
  • Page 21 Controls and features Manual heating and air conditioning system (if equipped) Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode selector control Controls the direction of the airflow to the inside of the vehicle.
  • Page 22 Controls and features even after you have stopped the vehicle. Under normal conditions, your vehicle’s climate control system should be left in any position other than MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” through the outside air inlet duct.
  • Page 23 Controls and features through the instrument panel registers and the floor ducts. Heating and air conditioning capabilities are provided in this mode. For added customer comfort, when the temperature control knob is anywhere in between the full hot and full cold positions, the air distributed through the floor ducts will be slightly warmer...
  • Page 24 Controls and features -Distributes outside air through the windshield defroster ducts. It can be used to clear ice or fog from the windshield. If the temperature is about 10°C (50°F) or higher, the air conditioner will automatically dehumidify the air to prevent fogging.
  • Page 25 Then operate your air conditioner as you would normally. When placing objects on top of your instrument panel, be careful to not place them over the defroster outlets. These objects can block airflow and reduce your ability to see through your windshield. Also, avoid placing small objects on top of your instrument panel.
  • Page 26 Controls and features POSITIONS OF THE IGNITION 1. LOCK, locks the steering wheel, gearshift lever (automatic transaxle only) and allows key removal. On vehicles with a manual transaxle push the key in while turning to lock. 2. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running.
  • Page 27 The Daytime Running Light (DRL) system will not illuminate the tail lamps and parking lamps. Turn on your headlamps at dusk. Failure to do so may result in a collision. High beams Push forward to activate. Flash to pass Pull toward you to activate and release to deactivate.
  • Page 28 Controls and features FOGLAMPS (IF EQUIPPED) Rotate forward to activate. SPEED CONTROL (IF EQUIPPED) To turn speed control on Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
  • Page 29 To turn speed control off Press OFF or Turn off the vehicle ignition. Once speed control is switched off, the previously programmed set speed will be erased. To set a speed Press SET ACC/SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph).
  • Page 30 Controls and features If your vehicle slows down more than 16 km/h (10 mph) below your set speed on an uphill, your speed control will disengage. This is normal. Pressing RES/RSM/RESUME will re-engage Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
  • Page 31 Controls and features To set a lower set speed Press and hold CST/COAST. Release the control when the desired speed is reached or Press and release CST/COAST. Each press will decrease the set speed by 1.6 km/h (1 mph) or Depress the brake pedal.
  • Page 32 Controls and features To disengage speed control Depress the brake pedal or Depress the clutch pedal (if equipped) Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed.
  • Page 33 To return to a previously set speed Press RES/RSM/RESUME. For RES/RSM/RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph). TILT STEERING (IF EQUIPPED) Pull the tilt steering control down to move the steering wheel up or down.
  • Page 34 Controls and features WINDSHIELD WIPER AND WASHER For intermittent wiping, move the control down one position and rotate the wiper switch to the desired position. For low speed wiping, move the control down two positions. For high speed wiping, move the control down three positions.
  • Page 35 Rear window wiper/washer controls (if equipped) For rear wiper operation, rotate the rear wiper and washer control to the desired position. To turn rear wipers on, rotate the rear wiper/washer control upward to the ON position. To turn rear wipers off, rotate the rear wiper/washer control downward to the OFF position.
  • Page 36 Controls and features INTERIOR LAMPS Dome lamp (if equipped) The dome lamp is located overhead between the driver and passenger seats. The dome lamp will stay on if the control is moved to the ON position. When the control is moved to the DOOR position, the lamp will only come on if a door is opened.
  • Page 37 POWER WINDOWS (IF EQUIPPED) Press and hold the rocker switches to open and close windows. Press the top portion of the rocker switch to close. Controls and features...
  • Page 38 Controls and features Press the bottom portion of the rocker switch to open. Express down To make the driver window open fully without holding the window control, press the driver window control completely down and release quickly. Depress again to stop window operation.
  • Page 39 FUEL PUMP SHUT-OFF SWITCH Refer to the Roadside emergencies chapter for instructions on how to operate the fuel pump shut-off switch. CARGO COVER (IF EQUIPPED) Your vehicle may be equipped with a cargo area shade that covers the luggage compartment of your vehicle.
  • Page 40 Controls and features The all-door remote entry system allows you to: lock or unlock all vehicle doors without a key. arm and disarm the anti-theft system. (For more information on the anti-theft system, refer to Anti-theft system in this chapter.) open the trunk.
  • Page 41 Controls and features Locking the doors Press this control to lock all doors (and liftgate on wagons). On vehicles equipped with the driver’s door only remote entry system, only the driver’s door will lock. To confirm doors are closed and locked, press the lock control a second time within five seconds.
  • Page 42 Controls and features Sounding a panic alarm Press this control to activate the alarm. To deactivate the alarm, press the control again or turn the ignition to ACC or ON. This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada.
  • Page 43 1. Twist a thin coin between the two halves of the transmitter. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART. 2. Place the positive (+) side of new batteries down. Refer to the diagram inside the transmitter unit. 3.
  • Page 44 Controls and features All transmitters must be programmed at the same time. Illuminated entry Interior lamps will illuminate when UNLOCK is pressed. The lamps will illuminate for approximately 20 seconds or until the key is inserted in the ignition and turned to ON or until LOCK is pressed.
  • Page 45 If the system is arming with the doors open, the THEFT light will stay illuminated until all the doors are closed and then illuminate for 30 seconds and begin flashing. When an unauthorized entry occurs, the activated system will: flash the parking lamps and the THEFT light sound the horn The flashing parklamps and the...
  • Page 46 Controls and features Disarming a triggered anti-theft system Press either the unlock or panic control to disarm the system. A triggered system may also be disarmed by inserting the key and turning the ignition to ACC or ON.

  • Page 47: Seating And Safety Restraints

    SEATING Adjustable head restraints (if equipped) The head restraints can be moved up and down. Push control to lower head restraint. Front seats Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop.
  • Page 48 Seating and safety restraints Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Lift handle to move seat forward or backward. Pull lever up to adjust seatback.
  • Page 49 Driver seat memory recliner (if equipped) Pull control to adjust seatback. To retain selected seatback position, release seatback by moving memory recliner control forward to release seatback. Push seatback rearward until the seatback latches. This will be the first position selected. Seating and safety restraints...
  • Page 50 Seating and safety restraints Folding rear seats (if equipped) Folding down the rear seats If your vehicle is equipped with a built-in child seat, the seatback cannot be folded down unless the built-in child seat is fully stowed. See Built-in child seats in this chapter for more information.
  • Page 51 SAFETY RESTRAINTS Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To prevent the risk of injury, make sure children sit where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving.
  • Page 52 Seating and safety restraints Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only.
  • Page 53 2. To unfasten, push the red release button and remove the tongue from the buckle. The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front and rear seat passenger outboard safety belts have two types of locking modes described below: Automatic locking mode...
  • Page 54 Seating and safety restraints How to use the automatic locking mode Buckle the combination lap and shoulder belt. Grasp the shoulder portion and pull downward until the entire belt is extracted. Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
  • Page 55 Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height control down.
  • Page 56 Seating and safety restraints Insert the tongue into the correct buckle. To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle. To tighten the belt, pull the loose end of the belt through the tongue until it fits snugly across the hips.
  • Page 57 belt extension only if the safety belt is too short for you when fully extended. Do not use extensions to change the fit of the shoulder belt across the torso. Safety belt warning light and indicator chime The seat belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten...
  • Page 58 (if equipped), child safety seat tether bracket assemblies (if equipped), and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was minor...
  • Page 59 Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to: work with the safety belt to protect the driver and right front passenger reduce certain upper body injuries Failure to follow these instructions will affect the performance of the safety belts and increase the risk of personal injury.
  • Page 60 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer. Children and air bags For additional important safety information, read all information on safety restraints in this guide.
  • Page 61 How does the air bag supplemental restraint system work? The SRS is designed to activate when the vehicle sustains sufficient longitudinal deceleration. The fact that the air bags did not inflate in a collision does not mean that something is wrong with the system.
  • Page 62 Seating and safety restraints If the air bag is inflated, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision. The SRS consists of: driver and passenger air bag modules (which include the...
  • Page 63 A difficulty with the system is indicated by one or more of the following: The readiness light will either flash or stay lit. The readiness light will not illuminate immediately after ignition is turned on. A series of five beeps will be heard.
  • Page 64 Seating and safety restraints them in safety seats made especially for children. Check your local and state or provincial laws for specific requirements regarding the safety of children in your vehicle. Never let a passenger hold a child on his or her lap while the vehicle is moving.
  • Page 65 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all Federal motor vehicle safety standards.
  • Page 66 Put the safety belt in the automatic locking mode. Refer to Automatic locking mode. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage.
  • Page 67 Attaching safety seats with tether straps. Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.
  • Page 68 Seating and safety restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
  • Page 69 Seating and safety restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
  • Page 70 Tether anchorage hardware kits (part number 613D74) including instructions, may be obtained at no charge from any Ford or Lincoln-Mercury dealer. All vehicles built for sale in Canada include a tether anchor hardware kit. Be sure to follow the child safety...
  • Page 71 Tether anchorage hardware kits including instructions, may be obtained at no charge from any Ford or Lincoln-Mercury dealer. All vehicles built for sale in Canada include a tether anchor hardware kit. Be sure to follow the child safety seat manufacturer’s instructions.
  • Page 72 Seating and safety restraints Tighten the anchor according to specifications. Otherwise, the safety seat may not be properly secured and the child may be injured in a sudden stop or collision. 1. Install the child safety seat in the rear right, rear left or rear center seat position.
  • Page 73 Seating and safety restraints BUILT-IN CHILD SEATS Built-in child safety seat (if equipped) The rear seat may include a built-in child seat. This child seat conforms to all Federal and local motor vehicle safety standards. Read the labels located on the child seat cushion and shoulder belt for information on the built-in child seat.
  • Page 74 Seating and safety restraints Placing your child in the built-in child seat Failure to follow all of the instructions on the use of this child restraint system can result in your child striking the vehicle’s interior during a sudden stop or crash. Never use the Built-In Child Seat as a booster cushion with the adult safety...
  • Page 75 Seating and safety restraints 3. Read all information and warnings on the child seat cushion and shoulder safety belt. Make sure the child is not too large for the child seat. 4. If connected, squeeze the top and the bottom of the right half of the chest clip and pull to separate both halves.
  • Page 76 Seating and safety restraints 6. Insert either the left or the right safety belt tongue into the single opening of the crotch safety belt buckle (it doesn’t matter which tongue is inserted first). Insert other tongue. The color green must appear in the indicator window on the crotch safety belt buckle when buckled.
  • Page 77 Seating and safety restraints 7. Fasten both halves of the chest clip below the child’s shoulders and adjust it to comfortably hold the shoulder belts in place on the child’s chest. The color green must appear in the indicator window when fastened.
  • Page 78 Seating and safety restraints Removing your child from the built-in child seat 1. Squeeze the tabs on the top and the bottom of the chest clip and pull the halves apart to open the chest clip. 2. Press the release button on the crotch safety belt buckle.
  • Page 79 Interlocks and attaching hardware should be inspected by a qualified technician after any collision. If the child seat was in use during a collision, Ford recommends replacing it. Built-in child restraints not in use during a collision should be inspected and replaced if either damage or improper operation is noted.

  • Page 80: Starting

    Starting PREPARING TO START YOUR VEHICLE Engine starting is controlled by the spark ignition system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
  • Page 81 Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle...
  • Page 82 Starting Make sure the parking brake is set. Make sure the gearshift is in P (Park). If starting a vehicle with a manual transaxle: Make sure the parking brake is set.
  • Page 83 Push the clutch pedal to the floor. 3. Turn the key to 3 (ON) without turning the key to 4 (START). FUEL FILL FUEL – BRAKE CHECK SERVICE COOLANT ENGINE SOON Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced.
  • Page 84 Starting If the driver’s safety belt is fastened, the light ( illuminate. STARTING THE ENGINE 1. Turn the key to 4 (START) without pressing the accelerator pedal and release as soon as the engine starts. The key will return to 3 (ON). 2.
  • Page 85 For best results, plug the heater in at least three hours before starting the vehicle. Using the heater for longer than three hours will not harm the engine, so the heater can be plugged in the night before starting the vehicle. To prevent electrical shock, do not use your heater with ungrounded...
  • Page 86 Starting Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least 2.5 cm (one inch). Adjust the heating or air conditioning (if equipped) to bring in fresh air.

  • Page 87: Driving

    Driving BRAKES Your brakes are self-adjusting. Refer to the “Service Guide” for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
  • Page 88 Driving vehicle has continuous vibration or shudder while braking, felt mainly in the steering wheel, the vehicle most likely needs service. The ABS operates by detecting the onset of wheel lock up during brake applications and compensating for this tendency. The front wheels are prevented from locking even when the brakes are firmly applied.
  • Page 89 enable you to avoid obstacles and bring the vehicle to a controlled stop. We recommend that you familiarize yourself with this braking technique. However, avoid taking any unnecessary risks. Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, pull the handle up.
  • Page 90 Driving Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park) (automatic transaxle) or in 1 (First) (manual transaxle). Push the control on the end of the parking brake and push the handle down to release the brake.
  • Page 91 2. Hold down the brake pedal. 3. Depress the clutch pedal. 4. Turn the ignition key to 4 (START), then let the engine idle for a few seconds. 5. Release the brake pedal, then slowly release the clutch pedal while pressing down slowly on the accelerator pedal.
  • Page 92 Driving Upshifts when cruising (recommended for best fuel economy) Parking your vehicle 1. Apply the brake and shift into the neutral position. 2. Set the parking brake. 3. Shift into 1 (First). Sedan/Wagon 18 km/h (11 mph) 32 km/h (20 mph) 46 km/h (29 mph) 61 km/h (38 mph)
  • Page 93 4. Turn engine off and remove the key. Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Reverse Make sure that your vehicle is at a complete stop before you shift into R (Reverse).
  • Page 94 Driving into R (Reverse) when you downshift from 5 (Fifth). Automatic transaxle (if equipped) Hold the brake pedal down while you move the gearshift lever from position to position. If you do not hold the brake pedal down, your vehicle may move unexpectedly and injure someone.
  • Page 95 R (Reverse) With the gearshift in R (Reverse), the vehicle will move backward. You should always come to a complete stop before shifting in and out of R (Reverse). N (Neutral) With the gearshift in the N (Neutral) position, the vehicle can be started and is free to roll.
  • Page 96 Driving (Overdrive) The overdrive position is the normal driving position for an automatic overdrive transaxle. It works the same way as D (Drive) but shifts to a fourth gear-an overdrive gear-when your vehicle cruises at a constant speed for any length of time.
  • Page 97 L (Low) Use L (Low) when added engine braking is desired or when descending steep hills. The automatic transaxle will shift into the proper gear to ascend any grade without any need to shift to L (Low). Do not go faster than 61 km/h (38 mph) when in this gear.
  • Page 98 Driving Base Curb Weight: Weight of the vehicle including any standard equipment, fluids, lubricants, etc. It does not include passengers or aftermarket equipment. Payload: Combined maximum allowable weight of cargo, passengers and optional equipment. The payload equals the gross vehicle weight rating minus base curb weight.
  • Page 99 Maximum Trailer Weight Rating: Maximum weight of a trailer the vehicle is permitted to tow. The maximum trailer weight rating equals the vehicle curb weight for each engine/transmission combination, any required option weight for trailer towing and the weight of the driver from the GCWR for the towing vehicle.
  • Page 100 Driving a higher weight limit than the originals do not increase the GVWR and GAWR limitations. TRAILER TOWING Your vehicle is capable of towing a trailer up to 454 kg (1 000 lbs.) gross trailer weight with a maximum tongue load of 45 kg (100 lbs.).
  • Page 101 Hitches Do not use hitches that clamp onto the vehicle bumper. Use a load carrying hitch. You must distribute the load in your trailer so that 10 – 15% of the total weight of the trailer is on the tongue. Safety chains Always connect the trailer’s safety chains to the vehicle.
  • Page 102 Driving dealer or trailer rental agency for proper instructions and equipment for hooking up trailer lamps. Driving while you tow Do not drive faster than 88 km/h (55 mph) when towing a trailer. Speed control may shut off if you are towing on long, steep grades.
  • Page 103 The trailer tongue weight should be 10–15% of the loaded trailer weight. After you have traveled 80 km (50 miles), thoroughly check your hitch, electrical connections and trailer wheel lug nuts. When stopped in traffic for long periods of time in hot weather, place the gearshift in P (Park) and increase idle speed.

  • Page 104: Roadside Emergencies

    Roadside emergencies HAZARD FLASHER Use only in an emergency to warn traffic of vehicle breakdown, approaching danger, etc. The hazard flashers can be operated when the ignition is off. Slide the hazard flasher control to the right to activate the hazard flashers simultaneously.
  • Page 105 Roadside emergencies If your vehicle is a coupe, the fuel pump shut-off switch is located on the right side of the trunk behind the trunk liner. If your vehicle is a sedan or wagon, the fuel pump shut-off switch is located in the driver’s foot well, behind the kick panel.
  • Page 106 Roadside emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Always replace a fuse with one that has the specified amperage rating.
  • Page 107 Coupe The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating HAZARD ROOM ENGINE RADIO DOOR LOCK HORN AIR COND Roadside emergencies P. Window (C.B.) (DRL) (DOOR LK) STOP HAZARD HORN TAIL (AIR COND) (SUN ROOF) ROOM ENGINE METER (ASC) –...
  • Page 108 Roadside emergencies Fuse/Relay Fuse Amp Location Rating METER WIPER STOP TAIL SUN ROOF P. WINDOW 30A CB CIGAR AIR BAG AUDIO FUEL INJ. BLOWER 30A CB Sedan/Wagon The fuses are coded as follows: Description Backup Lamps, Engine Coolant Level Switch, Instrument Cluster, Rear Window Defrost, Shift Lock, Warning Chime, Turn Signal Switch...
  • Page 109 Fuse/Relay Fuse Amp Location Rating R.WIPER HAZARD ROOM ENGINE MIRROR DOOR LOCK HORN AIR COND Roadside emergencies P. Window (C.B.) R. WIPER (DOOR LK) STOP HAZARD HORN TAIL – (AIR COND) ROOM ENGINE METER (ASC) – MIRROR WIPER CIGAR AIR BAG Description Daytime Running Lamps, Liftgate Wiper/Washer...
  • Page 110 Roadside emergencies Fuse/Relay Fuse Amp Location Rating METER WIPER STOP TAIL CIGAR AIR BAG AUDIO FUEL INJECTOR P. WINDOW 30A CB BLOWER 30A CB Coupe The high-current fuses are coded as follows. Description Backup Lamps, Engine Controls, Instrument Cluster, Rear Window Defrost, Shift Lock, Warning Chime, Turn Signal Switch Wiper/Washer, Blower Relay...
  • Page 111 HEADLAMP USE THE DESIGNATED FUSES ONLY Fuse/Fuse Link Fuse Amp Cartridge Rating Location FUEL INJ. 30A* DEFOG 30A* MAIN 100A* 40A* 60A* COOLING FAN 40A* OBD-II 10A* FUEL PUMP 20A** HEAD RH 10A** HEAD LH 10A** * Fuse Link Cartridge **Fuse Roadside emergencies RELAY HEAD LH 10A...
  • Page 112 Roadside emergencies Sedan/Wagon The high-current fuses are coded as follows. HEADLAMP Fuse/Fuse Link Fuse Amp Cartridge Rating Location FUEL INJ. 30A* DEFOG 30A* RELAY HEAD LH 10A USE THE DESIGNATED FUSES ONLY Description Air Bags, Engine Controls, Generator Rear Window Defrost OBD-II 10A FUEL PUMP 30A HEAD RH 10A...
  • Page 113 Fuse/Fuse Link Fuse Amp Cartridge Rating Location MAIN 100A* 40A* 60A* COOLING FAN 40A* OBD-II 10A** FUEL PUMP 30A** HEAD RH 10A** HEAD LH 10A** * Fuse Link Cartridge ** Fuse Relays Relays are located in the power distribution box and should be replaced by qualified technicians.
  • Page 114 Roadside emergencies Temporary spare tire information The temporary spare tire for your vehicle is labeled as such. It is smaller than a regular tire and is designed for emergency use only. If you use the temporary spare tire continuously or do not follow these precautions, the tire could fail, causing you to lose control of the vehicle,...
  • Page 115 use the wheel for any other type of vehicle Tire change procedure 1. Park on a level surface, activate hazard flashers and set the parking brake. When one of the front wheels is off the ground, the transaxle alone will not prevent the vehicle from moving or slipping off the jack, even if the vehicle is in P (Park)
  • Page 116 Roadside emergencies block the diagonally opposite wheel. Automatic Manual 3. Remove the jack, jack handle and spare tire.
  • Page 117 Roadside emergencies 4. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. 5. Put the jack in the jack notch next to the door of the tire you are changing.
  • Page 118 Roadside emergencies 9. Remove the jack and fully tighten the lug nuts in the order shown. 10. Put flat tire, jack and lug wrench away. Make sure the jack is fastened so it does not rattle when you drive. Unblock the wheels. JUMP STARTING YOUR VEHICLE The gases around the...
  • Page 119 2. Do not disconnect the battery of the disabled vehicle as this could damage the vehicle’s electrical system. 3. Park the booster vehicle close to the hood of the disabled vehicle making sure they do not touch. Set the parking brake on both vehicles and stay clear of the engine cooling fan and other moving parts.
  • Page 120 Roadside emergencies 5. Make sure that the jump leads are clear of moving parts of the engine. Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped. A spark may cause an explosion of the gases that surround the battery.
  • Page 121 When calling for a tow truck, tell the operator what kind of vehicle you have. A towing manual is available from Ford Motor Company for all authorized tow truck operators. Have your tow truck driver refer to this manual for proper hook-up and towing procedures for your vehicle.
  • Page 122 Roadside emergencies TOWING BEHIND ANOTHER VEHICLE Do not tow your vehicle behind another vehicle, such as an RV, unless front wheel dollies are used. Your vehicle cannot be flat towed with all wheels on the ground.

  • Page 123: Maintenance And Care

    SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a “Service Guide” which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide necessary parts and service.
  • Page 124 Maintenance and care Do not work on a vehicle with the engine running in an enclosed space, unless you are sure you have enough ventilation. Keep all lit cigarettes, open flames and other lit material away from the battery and all fuel related parts.
  • Page 125 ensure the gearshift is securely latched in P (Park). 2. Turn off the engine and remove the key. 3. Block the wheels to prevent the vehicle from moving unexpectedly. Manual transaxle: 1. Set the parking brake, Maintenance and care...
  • Page 126 Maintenance and care depress the clutch and place the gearshift in 1 (First). 2. Turn off the engine and remove the key. 3. Block the wheels to prevent the vehicle from moving unexpectedly. Working with the engine on Automatic transaxle: 1.
  • Page 127 ensure the gearshift is securely latched in P (Park). 2. Block the wheels to prevent the vehicle from moving unexpectedly. Do not start your engine with the air cleaner removed and do not remove it while the engine is running. Manual transaxle: 1.
  • Page 128 Maintenance and care depress the clutch and place the gearshift in N (Neutral). 2. Block the wheels to prevent the vehicle from moving unexpectedly. Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1.
  • Page 129 Maintenance and care 3. Lift the hood and secure it with the prop rod.
  • Page 130 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.0L SOHC engine 1. Engine oil dipstick 2. Brake fluid reservoir 3. Transmission fluid dipstick (automatic transaxle only) 4. Battery 5. Air filter assembly 6. Engine oil fill cap 7. Power steering fluid reservoir 8.
  • Page 131 Maintenance and care 2.0L DOHC Zetec engine 1. Transmission fluid dipstick (automatic transaxle only) 2. Battery 3. Air filter assembly 4. Engine oil fill cap 5. Engine oil dipstick 6. Power steering fluid reservoir 7. Engine coolant reservoir 8. Windshield washer fluid reservoir 9.
  • Page 132 Maintenance and care ENGINE OIL Checking the engine oil Check the engine oil each time you fuel your vehicle. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
  • Page 133 2.0L DOHC Zetec engine 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. If the oil level is between the ADD and FULL marks, the oil level is acceptable. DO NOT ADD OIL. If the oil level is below the ADD mark, add enough oil to raise the level within the ADD-FULL range.
  • Page 134 F in FULL mark on the dipstick. Engine oil recommendations Look for this certification mark. Ford oil specification is WSS-M2C153-G. Use SAE 5W-30 motor oil certified for gasoline engines by the American Petroleum Institute.
  • Page 135 Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, startup engine noises or knock may be experienced.
  • Page 136 Visually inspect the fluid level. If necessary, add brake fluid until the level reaches MAX. Do not fill above this line. Use only a DOT 3 brake fluid certified to meet Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter.
  • Page 137 CLUTCH FLUID (IF EQUIPPED) The clutch master cylinder and brake master cylinder are part of the same system; both are refillable through the brake master cylinder with brake fluid. During normal operation, the fluid level in the brake fluid reservoir will rise slowly.
  • Page 138 Maintenance and care ENGINE COOLANT Coupe Sedan/Wagon Check the level of the coolant in the reservoir at least once a month. Be sure to read and understand Precautions when servicing your vehicle in this chapter. If the engine coolant has not been checked for a long period of time, the engine coolant reservoir may eventually empty.
  • Page 139 to Adding engine coolant in this chapter. Automotive fluids are not interchangeable; do not use engine coolant, antifreeze or windshield washer fluid outside of its specified function and vehicle location. Adding engine coolant Do not put engine coolant in the container for the windshield washer fluid.
  • Page 140 ESE-M97B44–A. Ford Premium Engine Coolant is an optimized formula that will protect all metals and rubber elastomers used in Ford cooling systems for four years or 80,000 km (50,000 miles). Do not use alcohol or methanol antifreeze or any engine coolants mixed with alcohol or methanol antifreeze.
  • Page 141 Ford and Lincoln-Mercury dealers use recycled engine coolant produced by Ford-approved processes. Not all coolant recycling processes produce coolant which meets Ford specification ESE-M97B44–A, and use of such coolant may harm engine and cooling system components. Always dispose of used automotive fluids in a responsible manner.
  • Page 142 Maintenance and care such that the coolant will not freeze at the temperature level in which you drive during winter months. Never increase the engine coolant concentration above 60%. Leave a 50/50 mixture of engine coolant and water in your vehicle year-round in non-extreme climates.
  • Page 143 Maintenance and care center of the NORMAL band). 2. While the engine idles, turn the steering wheel left and right several times. 3. Turn the engine off. 4. Check the fluid level in the reservoir. It should be between the MIN and MAX lines.
  • Page 144 Maintenance and care fluid at least twice a year. The fluid level should be checked if the transmission is not working properly, i.e., if the transaxle slips or shifts slowly or if you notice some sign of fluid leakage. Transmission fluid should be checked at normal operating temperatures 66°C-77°C (150°F-170°F) on a level surface.
  • Page 145 Maintenance and care 6. Remove the dipstick and inspect the fluid level. The fluid level should be between the notches on the dipstick. 7. If necessary, add fluid in .25L (1/2 pint) increments through the filler tube until the level is correct. 8.
  • Page 146 Maintenance and care tap water to the battery, as long as you do not use hard water (water with a high alkali content). If possible, however, try to only fill the battery cells with distilled water. If the battery needs water often, have the charging system checked.
  • Page 147 neutral position (manual transaxles), turn off all accessories and start the vehicle. 2. Let the engine idle for at least one minute. 3. The relearning process will automatically complete as you drive the vehicle. If you do not allow the engine to relearn its idle, the idle quality of your vehicle may be adversely affected until the idle is...
  • Page 148 Maintenance and care AIR FILTER To replace your air filter, release the clamp locking clip on the front portion of the air filter housing, then swing the left side open and remove the air filter. When installing the air filter, ensure the nubs on the air filter and the air filter housing are aligned.
  • Page 149 Maintenance and care make replacing the wipers easy, turn the ignition to ACC, then turn the wipers on. When the wipers reach the vertical position, turn the ignition to LOCK. To replace the wiper blades: 1. Pull the wiper arm away from the windshield and lock into the service position.
  • Page 150 Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear The treadwear grade is a...
  • Page 151 The traction grade assigned to this tire is based on braking (straight ahead) traction tests and does not include cornering (turning) traction. Temperature A B C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a...
  • Page 152 Maintenance and care SERVICING YOUR TIRES Checking the tire pressure Use an accurate tire pressure gauge. Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
  • Page 153 Four tire rotation Replacing the tires Replace the tires when the wear band is visible through the tire treads. Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier to lose control and roll over. Tires that are larger or smaller than your vehicle’s original tires may also affect the accuracy of...
  • Page 154 Maintenance and care SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
  • Page 155 Remove the tire chains when they are no longer needed. Do not use tire chains on dry roads. The suspension insulation and bumpers will help prevent vehicle damage. Do not remove these components from your vehicle when using snow tires and chains.
  • Page 156 Maintenance and care Observe the following guidelines when handling automotive fuel: Extinguish all smoking materials and any open flames before fueling your vehicle. Always turn off the vehicle before fueling. Automotive fuels can be harmful or fatal if swallowed. If fuel is swallowed, call a physician immediately, even if no symptoms are immediately...
  • Page 157 Maintenance and care Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based compounds containing MMT. Vehicles certified to California emission standards (indicated on the underhood Vehicle Emissions Control Information label) are designed to operate on California reformulated gasolines.
  • Page 158 Cleaner air Ford approves the use of gasolines to improve air quality, including reformulated gasolines that contain oxygenates up to 10% ethanol or 15% MTBE.
  • Page 159 Maintenance and care affect on modern powertrain components. You may need to crank the engine several times before the system starts to pump fuel from the tank to the engine. If you run out of fuel, your Service Engine Soon light may come on.
  • Page 160 Guide” are required because they are considered essential to the life and performance of your vehicle and to its emissions system. If other than Ford, Motorcraft or Ford authorized parts are used for maintenance replacements or for service of components affecting...
  • Page 161 Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Watch for fluid leaks, strange odors, smoke, loss of oil pressure, the charging system warning light, the “Service Engine Soon”...
  • Page 162 Maintenance and care Please consult your “Warranty Guide” for complete emission warranty information. Readiness for inspection/maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostic (OBD-II) system. If your “check engine/service engine soon”...
  • Page 163 Once started, do not turn off the engine until the above driving cycle is complete. EXTERIOR BULBS It is a good idea to check the operation of the following lights frequently: Headlamps Turn signals Foglamps (if equipped) Coupe Sedan/wagon High-mount brake lamp Tail lamps Brake lamps Backup lamps...
  • Page 164 Maintenance and care Sedan Wagon Coupe Hazard flashers Interior overhead lamps Do not remove lamp bulbs unless they will be replaced immediately. If a bulb is removed for an extended period of time, contaminants may enter the lamp housings and affect performance.
  • Page 165 Handle a halogen bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass; the oil from your hand could cause the bulb to break the next time that the headlamps are operated.
  • Page 166 Maintenance and care 3. Remove the protective dust shield from the housing by turning the dust shield counterclockwise (when viewed from the rear). 4. Disconnect the electrical connector from the bulb by pulling it straight out. 5. Remove the bulb retaining ring by rotating it counterclockwise (when viewed from the rear).
  • Page 167 Maintenance and care 10. Replace the protective dust shield and lock the shield by rotating it clockwise until it locks into position. 11. Reconnect the headlamp wiring socket to the in-line connector. Foglamps (if equipped) To change the foglamp bulbs: 1.
  • Page 168 Maintenance and care Coupe Sedan Wagon 1. Remove the push pins and cover from the package tray. 2. Detach the socket from the housing and remove the bulb. 3. Replace the bulb and ease the socket back into the housing.
  • Page 169 Maintenance and care 4. Replace the housing cover and secure with the push pins. Tail lamps/Backup lamps The tail lamp assemblies and the backup bulb assemblies are located in the same portion of the vehicle rear, one just below the other. Follow the same steps to replace either bulb.
  • Page 170 Maintenance and care Wagon 1. Open trunk to expose the tail lamp assembly. Remove the two screws from the front of the lamp. 2. The tail lamp has hidden fasteners which can be disengaged by hitting the lamp, with the side of your hand, toward the side of the vehicle.
  • Page 171 Maintenance and care License plate lamps To change the license plate bulbs: 1. Carefully remove screws and pull the license plate lamp assembly from the rear bumper. 2. Carefully pull the lamp lens from the assembly. 3. Remove the bulb to be replaced and install a new bulb.
  • Page 172 Maintenance and care Using the right bulbs Function Front park/turn lamps Foglamps (if equipped) Headlamps-aero high and low beam Rear license plate lamps High-mount brake lamp Backup lamps Brake lamps Interior overhead lamp Warning lights Instrument panel gauge Map lamps For bulb replacement, see a qualified service technician or your dealer.
  • Page 173 Maintenance and care included in the vertical indication. Therefore, vertical and horizontal headlamp adjustment should be performed only when the beam direction appears to be incorrect. You will need one 4 mm wrench or socket with ratchet to make the adjustments.
  • Page 174 Maintenance and care headlamp refer to the directional change (left or right) of the horizontal aim. 3. Use a 4 mm wrench or socket to turn the horizontal adjusting screw until the forward edge of the knurled portion of the screw is aligned with the “0”...
  • Page 175 Repeat the above process to the other headlamp, if necessary. CLEANING AND CARING FOR YOUR VEHICLE Refer to the “Customer Assistance Guide” for a list of Ford-approved cleaners, polishes and waxes. Washing your vehicle Wash your vehicle regularly with cold or lukewarm water. Never use strong detergents or soap.
  • Page 176 Repairing paint chips Minor scratches or paint damage from road debris may be repaired with touch-up, paint repair foil or aerosol paint spray from the Ford accessory line. Observe the application instructions on the products. Remove particles such as bird...
  • Page 177 high pressure fluid could penetrate the sealed parts and cause damage. Do not spray with cold water to avoid cracking the engine block or other engine components. Cover the highlighted areas to prevent water damage when cleaning the engine. Never wash or rinse the engine while it is running;...
  • Page 178 Maintenance and care Cleaning the exterior lamps Wash with the same detergent as the exterior of your vehicle. Use glass cleaner or tar remover if necessary. To avoid scratching the lamps, do not use a dry paper towel, chemical solvents or abrasive cleaners.
  • Page 179 Maintenance and care Cleaning and maintaining the safety belts Clean the safety belts with a mild soap solution recommended for cleaning upholstery or carpets. Do not bleach or dye the belts, because these actions may weaken the belt webbing. Check the safety belt system periodically to make sure there are no nicks, wear or cuts.

  • Page 180: Capacities And Specifications

    No. 3 and 4 have a F suffix. If a spark plug needs to be replaced, use only spark plugs with the same service part number suffix letter “FE” as shown on the engine decal. REFILL CAPACITIES Ford Part Fluid Name Brake fluid...
  • Page 181 Ford Part Fluid Name Engine oil Motorcraft 5W30 (includes filter Super Premium change) Motor Oil Fuel tank capacity Power steering Motorcraft fluid MERCON ATF Transmission fluid Motorcraft MERCON ATF Windshield Ultra-Clear washer fluid Windshield Washer Concentrate LUBRICANT SPECIFICATIONS Ford Part...
  • Page 182 Capacities and specifications Ford Part Fluid Name or Equivalent Lock cylinder Penetrating lubricant Automatic Motorcraft transmission MERCON ATF Manual Motorcraft transmission MERCON ATF Engine oil Motorcraft 5W30 Super Premium Motor Oil Constant CV Joint Grease velocity joints (High Temp.) Engine coolant...
  • Page 183 Engine Compression ratio VEHICLE DIMENSIONS Vehicle Coupe mm (in) Sedan mm (in) Wagon mm dimensions (1) Overall 4 451.0 (175.2) length (2) Overall 1 712.0 (67.4) width (3) Overall 1 328.4 (52.3) height (4) Wheelbase 2 499.0 (98.4) (5) Track - 1 435.1 (56.5) Front (5) Track - Rear 1 435.1 (56.5)
  • Page 184 Capacities and specifications Coupe model Sedan model...
  • Page 185 Wagon model Wagon model Capacities and specifications...

  • Page 186: Vehicle Identification Number

    (if so equipped). MFD. BY FORD MOTOR CO. IN U.S.A. DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.

  • Page 187: Reporting Safety Defects

    National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a...

  • Page 188: Index

    Index Air bag supplemental restraint system ...58 and child safety seats ...60 description ...59 disposal ...63 indicator light ...62 passenger air bag ...61 Air cleaner filter ...148 Air conditioning manual heating and air conditioning system ...21,24 Anti-lock brake system (ABS) description ...88 Anti-theft system ...44 arming the system ...44...
  • Page 189 High beams indicator light ...10 Hood release lever ...128 Ignition positions of the ignition ...26 Instrument panel lighting up panel and interior ...17 Jump-starting your vehicle ...118,120 attaching cables ...119 disconnecting cables ...120 Keys key in ignition chime ...12 Lamps dome lamps ...36,171 fog lamps ...167 headlamps ...165...
  • Page 190 Index Sliding moon roof (see Moonroof) ...35 Speed control ...28 canceling a set speed ...32 resuming a set speed ...33 tap up/tap down ...30,31 turning off ...29 Speedometer ...15 Starting your vehicle ...80,81,84 Tachometer mechanical cluster ...16 Tilt steering wheel ...33 Tires ...149,152 checking the pressure ...152 replacing ...153...

  • Page 191: Filling Station Information

    Automatic transmission capacity Manual transmission capacity Unleaded fuel only - 87 octane 48.5L (12.8 gallons) Use Motorcraft 5W30 Super Premium Motor Oil, Ford Specification WSS-M2C153-G Refer to Tire Pressure Decal on passenger’s door panel Pull handle under the left side of the instrument panel Sedan/wagon-3.8L (4.0 quarts)
