AG Neovo GM678 Reporting Manual

Hide thumbs Also See for GM678:
Table of Contents

Advertisement

Quick Links

FCC CLASS B COMPLIANCE REPORT
No. 81-1, 210 Lane, Pa-de 2
This report shall not be reproduced, except in full, without the written approval of
The client to claim product certification, approval or endorsement by NVLAP, NIST or any agency
(DoC)
Electromagnetic Emissions
LCD Monitor
Trade Name
Model Number : GM678; F-417
Serial Number : N/A
Report Number : 030355-D
Date
Prepared for¡ G
Compal Electronics Inc.
No. 581, Jui Kuang Rd., Neihu,
Taipei, (114) Taiwan, R.O.C.
Prepared by¡ G
C&C LABORATORY, CO., LTD.
Taoyuan, Taiwan, R.O.C.
TEL: (03) 324-0332
FAX: (03) 324-5235
C&C LABORATORY, CO., LTD.
of the federal government must not use this report.
Report Number: 030355-D
April 29, 2003
for
of
: COMPAL; AG neovo
: April 29, 2003
nd
Road, Lu-Chu Hsiang,
Page 1 of 27
Rev. 00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM678 and is the answer not in the manual?

Questions and answers

Related Manuals for AG Neovo GM678

Summary of Contents for AG Neovo GM678

  • Page 1 FCC CLASS B COMPLIANCE REPORT (DoC) Electromagnetic Emissions LCD Monitor Trade Name : COMPAL; AG neovo Model Number : GM678; F-417 Serial Number : N/A Report Number : 030355-D Date : April 29, 2003 Prepared for¡ G Compal Electronics Inc.

  • Page 2: Table Of Contents

    Report Number: 030355-D April 29, 2003 TABLE OF CONTENTS 1 VERIFICATION OF COMPLIANCE ............3 2 SYSTEM DESCRIPTION................. 4 3 PRODUCT INFORMATION ..............5 4 SUPPORT EQUIPMENT ................6 5 MEASUREMENT PROCEDURE ............7 PRELIMINARY LINE CONDUCTED EMISSION TEST ......7 FINAL LINE CONDUCTED EMISSION TEST..........8 PRELIMINARY RADIATED EMISSION TEST ...........9 FINAL RADIATED EMISSION TEST ............10...

  • Page 3: Verification Of Compliance

    Report Number: 030355-D April 29, 2003 1 VERIFICATION OF COMPLIANCE Equipment Under Test: LCD Monitor Trade Name: COMPAL; AG neovo Model Number: GM678; F-417 Serial Number: Applicant: Compal Electronics Inc. No. 581, Jui Kuang Rd., Neihu, Taipei, (114) Taiwan, R.O.C.

  • Page 4: System Description

    Report Number: 030355-D April 29, 2003 2 SYSTEM DESCRIPTION EUT Test Program: 1. EMI test program was loaded and executed in Windows 98 mode. 2. Data was sent to EUT filling the screen with upper case of “H” patterns. 3. Test program sequentially exercised printer and modem, then sent “H” patterns to them individually.

  • Page 5: Product Information

    Report Number: 030355-D April 29, 2003 3 PRODUCT INFORMATION Housing Type: Plastic EUT Power Rating: 100~240VAC, 50 / 60Hz AC power during Test: 120VAC/ 60Hz AC Power Cord Type: Unshielded, 1.8m (Detachable) OSC/Clock Frequencies: 14.318MHz Hyundai HT17E12-200 LCD Panel Manufacturer: Model: Power Board Manufacturer: COMPAL...

  • Page 6: Support Equipment

    Report Number: 030355-D April 29, 2003 4 SUPPORT EQUIPMENT Model Serial Trade Data Power No. Equipment Name Cable Cord EVO D300 6K1BKF83F18F FCC DoC Compaq Unshielded, 1.8m Computer Modem 2400 94-364-176277 DK467GSM24 Shielded, 1.8m Unshielded, 1.8m Peripherals EPSON Printer STYLUS DW4E130540 FCC DoC EPSON...

  • Page 7: Measurement Procedure

    Report Number: 030355-D April 29, 2003 5 MEASUREMENT PROCEDURE 5.1 PRELIMINARY LINE CONDUCTED EMISSION TEST 1) The equipment was set up as per the test configuration to simulate typical actual usage per the user’s manual. When the EUT is a tabletop system, a wooden table with a height of 0.8 meters is used and is placed on the ground plane as per ANSI C63.4 (see Test Facility for the dimensions of the ground plane used).

  • Page 8: Final Line Conducted Emission Test

    Report Number: 030355-D April 29, 2003 5.2 FINAL LINE CONDUCTED EMISSION TEST 1) EUT and support equipment was set up on the test bench as per step 10 of the preliminary test. 2) A scan was taken on both power lines, Line 1 and Line 2, recording at least the six highest emissions.

  • Page 9: Preliminary Radiated Emission Test

    Report Number: 030355-D April 29, 2003 5.3 PRELIMINARY RADIATED EMISSION TEST 1) The equipment was set up as per the test configuration to simulate typical actual usage per the user’s manual. When the EUT is a tabletop system, a wooden turntable with a height of 0.8 meters is used which is placed on the ground plane as per ANSI C63.4 (see Test Facility for the dimensions of the ground plane used).

  • Page 10: Final Radiated Emission Test

    Report Number: 030355-D April 29, 2003 5.4 FINAL RADIATED EMISSION TEST 1) EUT and support equipment were set up on the turntable as per step 8 of the preliminary test. 2) The Analyzer / Receiver scanned from 30MHz to 1000MHz. Emissions were scanned and measured rotating the EUT to 360 degrees, varying cable placement and positioning the antenna 1 to 4 meters above the ground plane, in both the vertical and the horizontal polarization, to maximize the emission reading level.

  • Page 11: Summary Data

    Report Number: 030355-D April 29, 2003 6 SUMMARY DATA (LINE CONDUCTED TEST) Model Number: GM678 Location: Site # 4 Tested by: Hank Huang Test Mode: Mode 1 Test Results: Passed Temperature: 20°C Humidity: 65%RH (The chart below shows the highest readings taken from the final data) FREQ Q.P.
  • Page 12 Report Number: 030355-D April 29, 2003 SUMMARY DATA (RADIATED EMISSION TEST) Model Number: GM678 Location: Site # 1 Tested by: Hank Huang Polar: Vertical--10m Test Mode: Mode 1 Test Results: Passed Detector Function: Quasi-Peak Temperature: 21°C Humidity: 65%RH (The chart below shows the highest readings taken from the final data) ============================================================== Freq.
  • Page 13 Report Number: 030355-D April 29, 2003 SUMMARY DATA (RADIATED EMISSION TEST) Model Number: GM678 Location: Site # 1 Tested by: Hank Huang Polar: Horizontal--10m Test Mode: Mode 1 Test Results: Passed Detector Function: Quasi-Peak Temperature: 21°C Humidity: 65%RH (The chart below shows the highest readings taken from the final data) ============================================================== Freq.

  • Page 14: Test Facility

    Report Number: 030355-D April 29, 2003 7 TEST FACILITY Location: No. 81-1, 210 Lane, Pa-de 2 Road, Lu-Chu Hsiang, Taoyuan, Taiwan, R. O. C. Description: There are four 3/10m open area test sites and three line conducted labs for final test. The Open Area Test Sites and the Line Conducted labs are constructed and calibrated to meet the FCC requirements in documents ANSI C63.4: 2001 and CISPR 16 requirements.

  • Page 15: Test Equipment List

    Report Number: 030355-D April 29, 2003 8 TEST EQUIPMENT LIST Instrumentation: The following list contains equipment used at C & C Laboratory, Co., Ltd. for testing. The equipment conforms to the CISPR 16-1 / ANSI C63.2-1988 Specifications for Electromagnetic Interference and Field Strength Instrumentation from 9kHz to 1.0 GHz or above. Equipment used during the tests: Open Area Test Site: Open Area Test Site # 1...

  • Page 16: Block Diagram Of Test Setup

    Report Number: 030355-D April 29, 2003 9 BLOCK DIAGRAM OF TEST SETUP SYSTEM DIAGRAM OF CONNECTIONS BETWEEN EUT AND SIMULATORS EUT: LCD Monitor Trade Name: COMPAL Model Number: GM678 Power Cord: Unshielded, 1.8m VGA Cable LCD Monitor 1. PC (EUT) 2.

  • Page 17: Appendix 1 Photographs

    Report Number: 030355-D April 29, 2003 10 APPENDIX 1 PHOTOGRAPHS (TEST SETUP OF LINE CONDUCTED EMISSION TEST) Page 17 Rev. 00...
  • Page 18 Report Number: 030355-D April 29, 2003 LINE CONDUCTED EMISSION TEST Front View Back View Page 18 Rev. 00...

  • Page 19: Appendix 2 Photographs (Test Setup Of Radiated Emission Test)

    Report Number: 030355-D April 29, 2003 11 APPENDIX 2 PHOTOGRAPHS (TEST SETUP OF RADIATED EMISSION TEST) Page 19 Rev. 00...
  • Page 20 Report Number: 030355-D April 29, 2003 RADIATED EMISSION TEST Front View Back View Page 20 Rev. 00...

  • Page 21: Appendix 3 Photographs Of Eut

    Report Number: 030355-D April 29, 2003 12 APPENDIX 3 PHOTOGRAPHS OF EUT Page 21 Rev. 00...
  • Page 22 Report Number: 030355-D April 29, 2003 Front View of EUT Back View of EUT Page 22 Rev. 00...
  • Page 23 Report Number: 030355-D April 29, 2003 Left View of EUT Right View of EUT Page 23 Rev. 00...
  • Page 24 Report Number: 030355-D April 29, 2003 I/O Port of EUT Page 24 Rev. 00...

  • Page 25: Appendix 4 Labeling Requirements

    Report Number: 030355-D April 29, 2003 13 APPENDIX 4 LABELING REQUIREMENTS Page 25 Rev. 00...
  • Page 26 Report Number: 030355-D April 29, 2003 ¡ ± 15.19 Labeling requirements. (a) In addition to the requirements in part 2of this chapter, a device subject to certification, or verification, or verification shall be labeled as follows: (1) Receivers associated with the operation of a licensed radio service, e.g., FM broadcast under part 73 of this chapter, land mobile operation under part 90,etc., shall bear the following statement in a conspicuous location on the device: This device complies with part 15 of the FCC Rules.
  • Page 27 Report Number: 030355-D April 29, 2003 (ii) If a personal computer is authorized based on assembly using separately authorized components, in accordance with ¡ ± 15.101(c) (2)or (c)(3),and the resulting product is not separately tested: (2) Label text information should be in a size of type large enough to be readily legible, consistent with the dimensions of the equipment and the label.
