AG Neovo GM678 Test Report

Hide thumbs Also See for GM678:
Table of Contents

Advertisement

Quick Links

EMC COMPLIANCE TEST REPORT
Standards
EN 55022: 1998
EN 61000-3-2: 1995 + A1: 1998 + A2: 1998
EN 61000-3-3: 1995
EN 55024: 1998
- IEC 61000-4-2: 2001
- IEC 61000-4-3: 1995
- IEC 61000-4-4: 1995
- IEC 61000-4-5: 1995
- IEC 61000-4-6: 1996
- IEC 61000-4-8: 1993
- IEC 61000-4-11: 1994
No. 81-1, 210 Lane, Pa-de 2
This report shall not be reproduced, except in full, without the written approval of
The client to claim product certification, approval or endorsement by NVLAP, NIST or any agency
LCD Monitor
Trade Name
Model Number
Serial Number
Report Number
Date
Regulations
Prepared for:
Compal Electronics Inc.
No. 581, Jui Kuang Rd., Neihu,
Taipei, (114) Taiwan, R.O.C.
Prepared by:
C&C LABORATORY, CO., LTD.
Taoyuan, Taiwan, R.O.C.
TEL: (03) 324-0332
FAX: (03) 324-5235
C&C LABORATORY, CO., LTD.
of the federal government must not use this report.
Report Number: 030355-E
April 29, 2003
for
:
COMPAL; AG neovo
:
GM678; F-417
:
N/A
:
030355-E
:
April 29, 2003
:
See below
Results (Pass/Fail)
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
nd
Road, Lu-Chu Hsiang,
Page 1 of 58
Rev. 00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM678 and is the answer not in the manual?

Questions and answers

Related Manuals for AG Neovo GM678

Summary of Contents for AG Neovo GM678

  • Page 1 Report Number: 030355-E April 29, 2003 EMC COMPLIANCE TEST REPORT LCD Monitor Trade Name COMPAL; AG neovo Model Number GM678; F-417 Serial Number Report Number 030355-E Date April 29, 2003 Regulations See below Standards Results (Pass/Fail) EN 55022: 1998 PASS...
