Summary of Contents for AG Neovo X-174
-
Page 2: Table Of Contents
Precautions...2 Warning on installation...2 Warning on power connection...2 Warning on tilt ...2 Warning on Maintenance ...3 Warning on transportation ...3 Package Contents ... 4 Identify the Parts and Controls ...5 Setup ...7 Customizing Your Monitor ... 10 Introducing the On-Screen Display System ... 10 OSD Menus...11 Display Adjust ...11 Color Temperature...11... -
Page 3: Precautions
Warning on installation Ÿ Do not cover or block the ventilation holes in the case. Ÿ Do not install the monitor near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, excessive dust, mechanical vibration or shock. Warning on power connection Ÿ... -
Page 4: Warning On Maintenance
Ÿ Clean the cabinet, glass, and controls with a soft cloth lightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder or solvent, such as alcohol or benzene. Ÿ Do not rub, touch, or tap the surface of the screen with sharp or abrasive items such as a pen or screwdriver. -
Page 5: Package Contents
Before using this monitor, check the following items are included in your carton box: Ÿ Monitor (*1) Ÿ Power adapter (*1) Ÿ Power cord (*1) Ÿ D-sub 15-pin signal cable (*1) Ÿ Digital DVI signal cable (*1) Video cable (Mini-din 8-pin to S-VHS and CVBS) (*1) (Optional) Ÿ... -
Page 6: Identify The Parts And Controls
Power switch Turns the monitor on or off. AUTO button Adjust the picture position and performance automatically. You are recommended to press the button the first time you use the monitor or every time you change the resolution and/or refresh rate of the input signal. UP button Activates the On-Screen Display menu. - Page 7 Ÿ DC +12V Power inlet Provides +12V DC power to the monitor. Ÿ VGA-In D-sub 15-pin connector for VGA signal. Ÿ VIDEO-In (Optional) Mini-dim 8- pin connector for S-Video or CVBS signal. Ÿ Digital DVI-D connector for digital signal input Ÿ...
-
Page 8: Setup
Please follow the steps one by one to setup your monitor. Split the dust-proof plastic sheet Split the dust-proof plastic sheet from the screen surface of monitor. Connect the monitor to the computer (if you are using a video source, please skip this step.) There are two kinds of signal formats that are digital and analog. - Page 9 Connect the monitor to the video source (DVD, VCD, VCR, etc.) (If you are using a computer, please skip this step.) (Optional) This monitor can support both S-Video and CVBS jack. Depending on the signal output port of your video source, you may need to use different signal cable and to connect into different port of the monitor.
- Page 10 Use 1280x1024 resolution and press you are not using a computer, please skip this step.) Before starting to work, you are recommended to adjust the resolution Ø of video signal from your computer to 1280x1024 at 60Hz for best picture performance.
-
Page 11: Customizing Your Monitor
Introducing the On-Screen Display System Most adjustments are made use of On-Screen Display menu. To activate the Automatic Adjustment Ø automatically.Doing this can solve most of the issues. You are recommended to activate the Automatic Adjustment function Ø the first time you use the monitor or every time you change the resolution and/or refresh rate of the input signal. -
Page 12: Osd Menus
OSD Menus Display Adjust Color Temperature OSD Adjust Input Select... -
Page 13: Misc Adjust
Brightness & Contrast Select Brightness and Contrast in the Display Adjust menu. Push display at the bottom of the OSD window. Push AUTO to save changes and go back to the main menu. Horizontal & Vertical Position Select H-position and V-position in the Display Adjust menu. Push display at the bottom of the OSD window. -
Page 14: White Balance
White Balance Select White Balance in the Display Adjust menu. Push Push AUTO to save changes and go back to the main menu. Selecting Color Temperature We recommend you to select different color temperature options for different purposes as shown below. Option 9300K 6500K... -
Page 15: Transparency Osd
Select Transparency OSD in the OSD Adjust menu to adjust the transparency of OSD window. Push Push AUTO to save changes and go back to the main menu. Selecting a Language Select Language in the OSD Adjust menu to choose a desired language of the OSD. -
Page 16: Fullscreen
Select “Off” to display 1:1 1024 x 768 picture if input resolution is 1024 x 768; select “1” to display H-position picture full screen; select “2” to display V-position picture full screen Mode Text/Graphic If you want to choose sharpest automatic display, set Mode Text/Graphic. Push Push AUTO Attention! For optimal performance of your LCD panel, set mode to TEXT when the resolution is... -
Page 17: Warning Messages And Troubleshooting
Warning Messages and Troubleshooting Warning Messages If the message appears on the screen CAN NOT DISPLAY THIS INPUT SIGNAL NO SIGNAL INPUT NO VIDEO SIGNAL FROM ANALOG INPUT No signal input is detected from ANALOG port. NO VIDEO SIGNAL FROM DIGITAL INPUT No signal input is detected from DIGITAL port. NO VIDEO SIGNAL FROM S-VIDEO-IN Check the items The input signal is not acceptable by the monitor. - Page 18 NO VIDEO SIGNAL FROM VIDEO-IN MAIN CONTROL MENU LOCKED MAIN CONTROL MENU UNLOCKED WAIT FOR AUTOMATIC ADJUSTMENT properly to S-VIDEO port at the rear of monitor. Check that the S-Video signal cable is connected · properly to the video source. Ensure that no pins are bent or pushed in the ·...
-
Page 19: Troubleshooting
Symptom No picture The “AGneovo” power indicator is not lit No picture The “AGneovo” power indicator is · orange color The texts are not solid Screen image is not centered properly. Some lines are missing · There are red, green, blue or black tiny dots on the screen. -
Page 20: Technical Features And Specifications
Power Saving Function This monitor meets the power-saving guidelines set by VESA and Energy Star, as well as the more stringent NUTEK. If the monitor is connected to a computer that is VESA DPMS (Display Power Management Signaling) compliant, the monitor will automatically reduce power consumption in the three stages as shown below. -
Page 21: Specifications
Electrical characteristics Screen size Pixel format Horizontal frequency Vertical frequency Maximum pixel clock Connections Physical characteristics Weight Tilt angle Temperature Humidity 17.4” (44cm) diagonal 1280 x 1024 vertical stripe 30kHz – 80kHz 50Hz – 75Hz 135MHz Power: 3-Pin AC Plug Net: 7.0Kg (15.4 lb) 0º... -
Page 22: Regulation
FCC compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 23: Tco'95
TCO'95 Congratulations! You have just purchased a TCO'95 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. - Page 24 TCO’95 is a co-operative project between TCO (The Swedish Confederation of Professional Employees), Naturskyddsforeningen (The Swedish Society for Nature Conservation) and NUTEK (The National Board for Industrial and Technical Development in Sweden). Environmental requirements Brominated flame retardants Brominated flame retardants are present in printed circuit boards, cables, wires, casings and housings. In turn, they delay the spread of fire.
