ADDER AdderLink Infinity Manager User Manual page 23

Receivers > Configure Receiver page
From the View Receivers page, you can configure details for a receiver:
• Click for a receiver.
Note: If the IP address of the receiver is changed, the device will need to reboot
itself.
Login Required
• No: When selected, anyone can use a receiver terminal and connect to a
channel. The channels/permissions displayed to this anonymous user are
those that are set for the "anonymous user" that is defined within the
Dashboard > Settings page.
• Inherit from Receiver Groups: When selected, the requirement for user
login will be determined by the "Login Required" settings within the
Receiver Groups to which this unit belongs:
• If ANY of the receiver groups (to which this receiver belongs) are set as
"Login Required = Yes", this receiver will require login.
• If ANY of the receiver groups (to which this receiver belongs) are set as
"Login Required = Inherit..." and the global setting is "login required =
yes", then this receiver will require login.
• If ALL receiver groups (to which this receiver belongs) are set as "Login
Required = No", then this receiver will NOT require login.
• Yes: When selected, a user will need to login with the username and
password defined in the "Users" section. They will only be allowed to login
if they have been granted permission to access that particular receiver.
Group Membership
To facilitate collective permission-granting for numerous receivers, a receiver can
belong to one or more receiver groups. Any permissions applied to the receiver
group are inherited by all receivers that are included within the receiver group.
For example, multiple receivers can be made available to a user by placing them
all in a receiver group and then granting the user permission to use that receiver
group.
Permissions
This is hidden by default as, by default, all users have access to all receivers. You
can deny access to particular receivers for a user in this section. However, be
aware that users who are included within user groups may have access to the
same receivers via their groups.
Receivers > Add Receiver Group or Configure Group page
From the View Receiver Groups page, you can create a new group or configure
an existing group:
• To create a new group: Click the "Add Receiver Group" option.
• To configure an existing group: Click
The Add and Configure pages are similar in content.
Login Required
• No: When selected, anyone can use a receiver terminal and connect to a
channel. The channels/permissions displayed to this anonymous user are
those that are set for the "anonymous user" defined within the
> Settings page.
• Inherit from global setting: When selected, the requirement for user login
will be determined by the "Login Required" setting within the
Settings page.
• Yes: When selected, a user will need to login with the username and
password defined in the "Users" section. They will only be allowed to login
if they have been granted permission to access devices in the receiver group.
Group Membership
This section allows you to easily include or exclude individual receivers for this
group. All relevant group permissions will be applied to all receivers that are
included within the group. Receivers that are not currently included in this group
within the left list and those receivers that are included within the right list.
To add a receiver to this group: Highlight one or more (use the CTRL key if
selecting more than one) receiver names in the left list and then click
the name(s) to the right list.
To add all receivers to the group: Click
the left to the right list.
To remove a receiver from the group: Highlight one or more (use the CTRL
key if selecting more than one) receiver names in the right list and then click
to move the name(s) back to the left list.
To remove all receivers from the group: Click
from the right to the left list.
Permissions
This is hidden by default because all users have access to all receivers. You
can deny access to the receiver group, however, be aware that users who are
included within user groups may have been given access to the receiver group
via their user groups.
Receivers > Update Firmware
Click this option to go straight to the Dashboard > Updates page. See
Dashboard > Updates page
for more details.
for a group.
Dashboard
Dashboard >
to add
to move all receiver names from
to move all receiver names
22
