ADDER AdderLink Infinity Manager User Manual page 15

Hotkey
Allows you to define the default keypress combination that will be used to
access the AIM on-screen display (OSD) menu by each user. If the hotkey
combination is altered, the change will be applied instantly to all receivers.
Anonymous User
Allows you to nominate a profile for an anonymous user that will be applied to
any receivers that do not require login. The channels available to that receiver
will be those available to the user that is selected here. You can create a suitable
standard user profile in the same way as any other user (see
then choose it within this setting.
Rows per Page
Determines how many rows to show per page in any paginated table within the
admin section, e.g. Users, Channels, Receivers, Event/Connection Logs.
AIM IP Address
Defines the IP address to which the AIM server has been set. Connect a display
monitor to the VGA port of the AIM unit to discover its current IP address.
The default AIM server IP address is 169.254.1.3
Note: If the AIM server's IP address is changed, any connected transmitters or
receivers will be rebooted.
Gateway IP Address
Defines the network gateway IP address for the AIM server.
Netmask
Defines the netmask for the AIM server.
DNS Server IP Address
Defines the IP address for a suitable DNS server to use within the AIM network.
Syslog IP Address
Defines the IP address for a suitable syslog server to use within the AIM network.
Multicast IP Base
Defines the base IP address for use in multicast configurations (where multiple
receivers use the output from a single channel). Multicast IP addresses are
assigned in pairs (one for audio, one for video), starting from this lowest IP
address. If you expect to have several multicast/shared connections within your
AIM network, ensure that sufficient IP addresses are available, starting from this
IP address.
Time
NTP Enabled?
If set to No, you will need to enter the date and time manually.
If set to Yes, you need to enter an NTP Server Address, declare your Timezone
Area and your Timezone Location.
Note: For the AIM unit to use NTP it requires access to the Internet, usually via
the second Ethernet connection to the rear of the unit. The IP address for the
second Ethernet connection can be configured within the Settings page.
The Users tab) and
API
Determines whether login is required (and which user profile to use, if login
is made a requirement) when AIM is driven using API scripts from an external
system.
Mail Server
A range of settings to define your email server, so that AIM system backups can
be automatically emailed to you.
Active Directory
If you wish to import user details from an existing LDAP connection, such as
Active Directory, this section allows you to enter all of the necessary details. See
Users > Active Directory for details about using Active Directory links.
14
