The Receivers tab

The Receivers tab shows a paginated table of all receiver devices within the AIM
network.
Click the RECEIVERS tab to view the initial View Receivers page.
The other Receivers pages (e.g. View Receiver Groups, Add Receiver Group, etc.)
are selectable within the blue section located just below the tabs.
Search filters
The key fields (Name, Description and Location) all provide
a search filter to locate particular items within long lists.
Enter a full or partial search string into the appropriate filter
box and then click to start the search. Optionally use the
buttons to invert the order of the listing.
The page will reload with the same pagination/sort order, but with the added
search filter. It's possible to filter by several columns at once (e.g. search for all
entries with "mac" in the name, and "mixed" in the description). Search terms
are case-insensitive. You can re-sort and paginate on filtered results without
losing the filters.
To remove a filter, click the red cross next to the relevant filter, (you can also
empty the search box and click again).
Receivers > View Receivers page
The table shows the following information for each receiver:
• Name
• IP address
• Description & Location
The Manage icons are as follows:
(Note: You can hover your mouse pointer over any icons to reveal additional
information):
Identify unit: Causes the LED lights to flash on the front of the selected
unit. An alert will be shown if the unit cannot be contacted (e.g. if it is
offline)
Reboot device: Allows you to reboot or reset a unit to its factory settings.
A popup will ask which task you wish to carry out. A reboot is useful if a
device enters an unknown state. A reset will return the unit to its factory
default state and reset its IP address (the unit will retain any firmware
updates that have been applied).
Delete device: Confirmation will be requested. You will need to factory-
reset any devices that you wish to re-configure to work with AIM.
Configure device: Displays the
Connect to a channel: A list of available channels is shown, along with
connection modes (view/shared/exclusive). The admin user can thus
remotely change channel on any receiver.
Disconnect: If a receiver is currently connected to a channel, clicking the
disconnect icon will end the connection, regardless of who is connected.
Hovering over the icon will show which user is connected, which channel
they are connected to, and when the connection was created.
• Online status
• Firmware revision of receiver unit
• Manage (admin options - see below)
"Configure Receiver" page.
